Side 1/8
Manual
SL-LD160RC-F
SL-LD160RC-R
OFF
ON
Press and hold
ENG
Design Pat. Pending
Copyright© 2020 CATEYE Co., Ltd.
SLLD160RCF/R-200313
3
WARNING!!!
• Before your trip, make sure the light is securely
attached and lights up.
Do not use a damaged rubber band.
• Always pay attention to the remaining battery
power by checking the indicator periodically while
using the light.
CAUTION!
• Stop your bicycle to operate the switch.
• Keep the light away from children.
•
Make sure the light is securely attached to the band.
Failure to do so may decrease the light’s resistance
to rain or cause the light to fall off during use.
• This device is rated IPX4 based on JIS C0920.
Do not immerse the device in water. Doing so may
cause a malfunction. Wipe off any moisture after
using the device in rainy weather.
LITHIUM-ION BATTERIES
When charging for the first time or after a
prolonged period of disuse
The voltage of the rechargeable battery may drop
during a long period of storage due to self-discharge.
Charge the battery prior to use.
Cautions on recharging
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 41°F and 104 °F (5 and 40°C).
• Before charging, be sure that no dust or other
foreign objects are attached to the USB plug.
• Do not subject the light to vibrations while
charging.
• Once charging is complete, be sure to disconnect
the USB plug.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable battery
to deteriorate faster.
Do not place the light inside a vehicle or near a
heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service life.
Dispose of the used rechargeable battery
according to local regulations.
Cautions on storage
Cool and dry storage is recommended. For long
period storage, it is important to charge the battery
30 minutes every 6 months.
Cautions for disposal
When disposing of the light unit, dispose of it
according to local regulations.
1
BEFORE INITIAL USE / HOW TO CHARGE
3
SWITCH OPERATION
2
HOW TO MOUNT
Before using the light, read this manual
thoroughly and keep it for future
reference.
5442811
Rubber band and hook
(SL-LD160-F)
5442810
Rubber band and hook
(SL-LD160-R)
5342730
USB cable
(MICRO USB)
SPARE/OPTIONAL PARTS
LIMITED WARRANTY
2-year Warranty: Light unit only
(excludes battery deterioration)
CatEye products are warranted to be free of
defects from materials and workmanship for a
period of 2 years from original purchase. If the
product fails to work during normal use, CatEye
will repair or replace the defect at no charge.
Service must be performed by CatEye or an
authorized retailer. To return the product, pack it
carefully and enclose the warranty certificate
(proof of purchase) with instruction for repair.
Please write or type your name and address
clearly on the warranty certificate. Insurance,
handling and transportation charges to CatEye
shall be borne by person desiring service.
For UK and REPUBLIC OF IRELAND consumers,
please return to the place of purchase. This does
not affect your statutory rights.
SPECIFICATIONS
Battery Lithium-ion polymer battery
3.7 V - 70 mAh
Charge Micro USB plug
Operating time SL-LD160RC-F / SL-LD160RC-R
• Constant : Approx. 3 h / 2.5 h
• Rapid flashing : Approx. 6.5 h / 5 h
• Slow flashing : Approx. 6.5 h / 5 h
* Average runtime at 20˚C.
Standard charging time
Approx. 3.5 hours (0.5 A)
Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight
Ø1-1/16" x 1-1/16" (Ø27 x 27 mm) / 0.9 oz (25 g)
*
The specifications and design are subject to change without notice.
Before Initial Use
Be sure to charge it before use, according to the
instructions “HOW TO CHARGE” and “Cautions on
recharging”.
To PC or USB battery charger
Rubber gasket
Open
Close
USB cable
Approx. h 3.5
(
0.5 A
)
Standard charging time
Charging
Charging is completed
Switch (lens)
Indicator
Constant
Rapid flashing
Slow flashing
Click
Click
Click
Attach securely in the mounting position.
Rubber band and hook
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan
Attn: CATEYE Customer Service Section
Phone : (06)6719-6863 E-mail : support@cateye.co.jp
Fax : (06)6719-6033 URL : https://www.cateye.com
CO
.,LTD.
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200, Boulder CO
80301-5494 USA
Phone : 303.443.4595 Toll Free : 800.5.CATEYE
Fax : 303.473.0006 E-mail : service@cateye.com
