SL-WA100
Always charge the product before use.
Automatic battery-saving function :
When the remaining battery power is low, the lighting mode changes to slow flashing.
Charge the light as soon as possible.
Manual
Standard
charging time
Approx.
2 h
(
USB 2.0
)
ENG
HOW TO CHARGE
SWITCH OPERATION
1
HOW TO MOUNT
2
3
Light unit
+ Clip bracket
USB cable
(MICRO USB)
Rubber band
and hook
Before using the light, read this manual
thoroughly and keep it for future refer-
ence.
WARNING!!!
• Check periodically to ensure that the light
unit is attached securely.
Do not use a damaged rubber band.
• Always attention to the remaining battery
power by checking the indicator periodically
while using.
CAUTION!
• Stop your bicycle to operate the switch.
• Do not place it within children’s reach.
• This unit is not totally waterproof.
Please wipe and dry it completely after using
in rain. Otherwise, it may cause failure.
• If the light unit or parts become dirty with
mud, etc., clean with a soft cloth which is
moistened with mild soap. Never apply paint
thinner, benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mAh (USB2.0)
USB battery charger.
•
Avoid charging in direct sunlight or in a
vehicle parked under direct sunlight, and
make sure to charge only when the ambient
temperature is between 5 and 40°C.
•
Before charging, be sure that no dust or
other foreign objects attach to the USB plug.
• Do not subject the light to vibrations while
charging.
• When your PC is in sleep state, the unit
cannot be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging and lighting times are approxi-
mate values, and will vary by environmen-
tal and user conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place
the light inside a vehicle or near a heater.
• If the illumination time is significantly
reduced even after proper charging, the
rechargeable battery may be nearing the
end of its service life. Dispose of the battery
as described in “Cautions for dispose”.
Cautions on storage
Cool and dry storage is recommended. For
long period storage, it is important to charge
the battery 30 minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove
the internal rechargeable battery and
dispose of it according to local regulations.
Charge jack cover
USB cable
2
1
To PC or USB battery charger
Charging
(Illuminated in red)
Charging is completed
(Off)
Indicator
Clip bracket
Light unit
+ Clip bracket
Install
Remove
Click
How to mount the unit on your bicycle
Rubber band and hook
Seatpost
OK NO
How to mount the
unit on your backpack
Confirm the jack cover of
the light unit facing the
clip bracket tab, and snap
the unit on the bracket.
Remove the unit from the
bracket by turning the
unit to the left or right.
Press and hold
ON
OFF
Remove / Install clip bracket
1
1
1
2
2
2
Approx.Ø26 – Ø32 mm
High
Low
Flashing
Rapid
Group Ride
Daytime
HyperFlash
Switch
Click
Approx.
1h
Approx.
10h
Approx.
30h
Approx.
10h
Approx.
10h
Approx.
13h
Design Pat. Pending
Copyright© 2018 CATEYE Co., Ltd.
SLWA100-180308
