Side 1/122

CHAPTER

4-1

Cisco Wireless LAN Controller Configuration Guide

OL-21524-02

Configuring Controller Settings

This chapter describes how to configure settings on the controller. It contains these sections:

• Installing and Configuring Licenses, page 4-2

• Configuring 802.11 Bands, page 4-26

• Configuring 802.11n Parameters, page 4-30

• Configuring 802.11h Parameters, page 4-35

• Configuring DHCP Proxy, page 4-36

• Configuring Administrator Usernames and Passwords, page 4-38

• Configuring SNMP, page 4-39

• Changing the Default Values of SNMP Community Strings, page 4-40

• Changing the Default Values for SNMP v3 Users, page 4-42

• Configuring Aggressive Load Balancing, page 4-44

• Configuring Band Selection, page 4-48

• Configuring Fast SSID Changing, page 4-51

• Enabling 802.3X Flow Control, page 4-51

• Configuring 802.3 Bridging, page 4-52

• Configuring Multicast Mode, page 4-54

• Configuring Client Roaming, page 4-59

• Configuring IP-MAC Address Binding, page 4-64

• Configuring Quality of Service, page 4-65

• Configuring Voice and Video Parameters, page 4-72

• Configuring Voice Prioritization Using Preferred Call Numbers, page 4-90

• Configuring EDCA Parameters, page 4-91

• Configuring the Cisco Discovery Protocol, page 4-94

• Configuring Authentication for the Controller and NTP Server, page 4-105

• Configuring RFID Tag Tracking, page 4-106

• Configuring and Viewing Location Settings, page 4-110

• Configuring the Supervisor 720 to Support the WiSM, page 4-118

• Using the Wireless LAN Controller Network Module, page 4-119

4-2

Cisco Wireless LAN Controller Configuration Guide

OL-21524-02

Chapter 4 Configuring Controller Settings

Installing and Configuring Licenses

• Resetting the Controller to Default Settings, page 4-120

Installing and Configuring Licenses

You can order Cisco 5500 Series Controllers with support for 12, 25, 50, 100, 250 or 500 access points

as the controller’s base capacity. You can add additional access point capacity through capacity adder

licenses available at 25, 50, 100 and 250 access point capacities. You can add the capacity adder licenses

to any base license in any combination to arrive at the maximum capacity of 500 access points. The base

and adder licenses are supported through both rehosting and RMAs.

Note These controller platforms do not require licenses: Cisco 2100 and Cisco 4400 Series Controllers, Cisco

WiSMs, Controller Network Modules, and Catalyst 3750G Integrated Wireless LAN Controller

Switches.

Note All features included in a Wireless LAN Controller Wplus license are now included in the base license;

this change is introduced in release 6.0.196.0. There are no changes to WCS BASE and PLUS licensing.

The base license supports the standard base software set and, for releases 6.0196.0 and later, the

premium software set is included as part of the base feature set, which includes this functionality:

• Datagram Transport Layer Security (DTLS) data encryption for added security across remote WAN

and LAN links. See the “Configuring Data Encryption” section on page 8-2 for more information

on data encryption.

Note The Availability of data DTLS for the 7.0.116.0 release is as follows:

Cisco 5500 Series Controller—The Cisco 5500 Series Controller will be available with two licensing

options: One with data DTLS capabilities and another image without data DTLS.

2500, WiSM2, WLC2—These platforms by default will not contain DTLS. To turn on data DTLS, you

must install a license. These platforms will have a single image with data DTLS turned off. To use data

DTLS you will need to have a license.

• Support for OfficeExtend access points, which are used for secure mobile teleworking. See the

“OfficeExtend Access Points” section on page 8-69 for more information on OfficeExtend access

points.

• Support for the 1130AG and 1240AG series indoor mesh access points, which dynamically establish

wireless connections in locations where it might be difficult to connect to the wired network. See

Chapter 9, “Controlling Mesh Access Points,” for more information on mesh access points.

All features included in a Wireless LAN Controller WPLUS license are now included in the base license;

this change is introduced in release 6.0.196.0. There are no changes to WCS BASE and PLUS licensing.

These WPlus license features are included in the base license:

• OfficeExtend AP

• Enterprise Mesh

• CAPWAP Data Encryption

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Ruter
Modell:	2504
Vekt:	1590 g
LED-indikatorer:	Link, Power, Status
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Antall brukere:	25 bruker(e)
Sikkerhet:	UL 60950-1, EN 60950:2005, FCC 15.107, FCC 15.109, ICES-003, VCCI, EN 55022, EN 55024
Maksimal dataoverføringshastighet:	1000 Mbit/s
Dimensjoner (B x D x H):	271.5 x 203.2 x 43.9 mm
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Type strømforsyning:	AC
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	5
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-25 - 70 °C
Lagringsrelativ fuktighet:	0 - 95
Quality of Service (QoS) støtte:	Ja
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	3DES, DES, MD5, SSL/TLS, WPA, WPA2
Krav til strømforsyning:	100 - 240 V
Relativ luftfuktighet under drift (H-H):	10 - 95
Intern:	Nei
Webbasert administrasjon:	Ja
Strøm-LED:	Ja
VLAN støtte:	Ja
