Quick Start Guide

Cisco 2600, 2600XM, 2800, 3660, 3700, and 3800 Series

Network Analysis Module

1 Network Analysis Module Overview

2 Software and Hardware System Requirements

3 Installing the NAM

4 Setting Up the NAM

5 Where to Go Next

6 Related Documentation

7 Obtaining Documentation

8 Documentation Feedback

9 Cisco Product Security Overview

10 Obtaining Technical Assistance

11 Obtaining Additional Publications and Information

1 Network Analysis Module Overview

The Network Analysis Module (NM-NAM) is a network module installed in select models of Cisco

2600, 2600XM, 2800, 3660, 3700, and 3800 Series routers, that monitors and analyzes network

traffic. (See Table 2 for a list of supported routers.)

The NAM Traffic Analyzer is software embedded in the NAM that gives you browser-based access to

the monitoring features of the NAM. You use this software to troubleshoot and monitor network

availability and health. In this document you will find:

• Package contents, including links for accessing online documentation.

• Hardware and software requirements.

• Installation and configuration procedures for getting the NAM and Traffic Analyzer running.

• Pointers to additional documentation that provides detailed procedures for installing and using

the product.

• Information about ordering documentation and contacting Cisco Systems for additional

assistance.

Package Contents

• NM-NAM module.

• Cisco Network Modules Quick Start Guide.

Note Only available for spare NM-NAM orders.

• Cisco Network Modules and Interface Cards Regulatory Compliance and Safety Information.

• Copyright Notices for the Network Analysis Module Release 3.4.

2 Software and Hardware System Requirements

This section provides NAM Traffic Analyzer software and hardware requirements:

• Table 1 describes the software requirements for installing and using the NAM Traffic Analyzer.

• Table 2 describes the hardware requirements for installing and using the NAM Traffic Analyzer.

• Table 3 describes the browser requirements for all platforms.

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Ruter
Modell:	3845
Vekt:	15880 g
Internminne:	512 MB
Ethernet WAN:	Ja
Flash-minne:	128 MB
Forhåndsinstallert programvare:	Cisco IOS Advanced IP Services
Sikkerhet:	UL 60950, CAN/CSA C22.2 No. 60950, EN 60950, AS/NZS 60950
URL-filtrering:	Ja
Utvidelsesspor:	4 ( 4 ) x NME-X\r\n4 ( 4 ) x HWIC\r\n4 ( 3 ) x PVDM\r\n1 ( 1 ) x SFP (mini-GBIC)\r\n2 ( 1 ) x AIM\r\n1 ( 0 ) x CF
Produktfarge:	Blue, Stainless steel
Antall USB-porter:	2
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Quality of Service (QoS) støtte:	Ja
I/O-porter:	2x 10Base-T/100Base-TX/1000Base-T - RJ-45\r\n2x USB - 4 PIN USB Type A\r\n1x cnsl\r\n1x aux
Rack-kapasitet:	3U
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Ethernet/bredbåndsforbindelse:	Ja
Rack-montering:	Ja
Brennmur-sikkerhet:	Cisco IOS
Stemmekodekser:	G.711, G.723.1, G.726, G.728, G.729, G.729a
Funksjoner 01:	G.711, G.723.1\r\nMPLS, IDS, IPS
Dobbeltbånd:	Nei
