Side 1/4

Basic Phone Use:

Place a Call

Lift Handset, or press Line Button, or press

NewCall

soft key, or press the speaker button,

or headset button and dial.

▪

Answer a Call

Lift Handset, or press

Answer

soft key or line button, or speaker button or headset button.

▪

End a Call

Hang up handset, or press

EndCall

soft key, or headset key or speaker key, etc.

Phone Features:

PickUp

1 Find the displaying PickUp softkey label & then press softkey button associated with it.

▪

GPickUp

Answering a call that is ringing on another extension outside of your workgroup

Check with your

do one of the following:

IS Department to find

If the Group PickUP button or GPickUp softkey is available, press it.

out if you have the

If the Group PickUp button or GPickUp softkey is NOT available, go "off -hook" (obtain

capability to pick up

a dial tone) to display the GPickUP softkey, then press it.

calls from another

3 Enter the group pickup code.

group

▪

Tip: If your phone supports auto-pickup, you are now connected to the call.

If the call rings, press Answer to connect the the call.

Mute a Call During the call press the Mute button Then press Mute again to resume speaking.

Quick Guide

Dial an extension to reach internal staff. Can you find your extension #_________?

Dial 9 plus 7 or 10 digits for local calls (local dialing rules apply).

Dial 9 plus 1 and the phone number for long distance call.

The call will be presented to your extension, press the Answer soft key to take the call.

Cisco Unified IP Phone: Model 7931

To pickup a call from a phone ringing in your workgroup do the following:

Note: You can only pickup calls that are ringing on an extension of your pickup workgroup, once the call

has moved on to a coverage path (gone to voice mail or someone else answers the call), you cannot

pickup the call.

Tip: If you receive a second call, you will hear a beep.

Then press the Answer soft key to answer it, and the first call will be put on hold.

Quick Guide 1/2008

Place a Call on Hold During the call press Hold button Press Resume soft key to take it back off hold.

▪

Place Call o Hold

▪

Tip: Your phone will come back off HOLD (revert back to you) after one (1) minute .

Remove a call from

Hold

Park a Call

2 The display will indicate the "parking space" that the caller is assigned to.

▪

Note: Park range number are:

Sites Park Ranges

Medford 1000 - 1025

Klamath 2000 - 2025

Phoenix 3000 - 3025

Gilbert Creek 4000 - 4025

▪

Transfer a Call

Press the Transfer Button on lower right of phone (the call will be put on hold)

2 Dial the number you want to transfer the call to.

Transfering to

You get a call and it needs to go to another department at another site you can select

another site

Transfer button, the extension [remember have to dial "9" first then extension number

because it is outside of your site] & then consult with person & hit Transfer button

Or if it is not a consult transfer just hit Transfer, then "9", then number, then Transfer.

Transfer a Call

Directly to Voice

Mail

Immediate Divert

▪

Once the call is ringing, you can either press Transfer button again immediately to transfer

the call without waiting for the call to be answered -- this is called a blind transfer. Or wait

until you've talked to the other person and then press Transfer button to complete it -- this

is called a consult or announced transfer.

Tip: If you forget the parking space number, or forget to pick the caller back up, the call will ring back to

the original phone after a timeout period of one (1) minute .

Tip: If multiple calls are on hold, use the Up/Down Arrow key to select the call and then press

Resume

ResumeResume

Resume

Access that caller by dialing the "parking space" number from any phone.

During a call, press the more soft key to access additional options and select the Park soft

key.

Hang up and the caller will be delivered directly to voicemail without ringing the phone.

Dial "  ", the extension number, and then press the Transfer button again.

Send a calling party directly to voicemail by pressing the iDivert soft key.

Note: You can use immediate divert anytime your phone is receiving a call to send that caller to

voicemail, even if you are on another call.

During a call, press the Transfer Button.

Quick Guide 1/2008

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Telefon
Modell:	7931G
Produkttype:	IP-telefon
Vekt:	1360 g
Bredde:	203 mm
Dybde:	229 mm
Høyde:	178 mm
Bluetooth:	Nei
Berøringsskjerm:	Nei
Wi-Fi:	Nei
Volumkontroll:	Digitalt
Nettverksstandard:	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Frontkamera:	Nei
Støttede nettverksprotokoller:	DHCP, TFTP, CDP
Elektromagnetisk kompatibilitet:	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Sikkerhet:	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Antall håndtak inkludert:	1 stykker
Skjermoppløsning:	192 x 64 piksler
Produktfarge:	Sort
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-10 - 60 °C
Montering:	Bord/Vegg
Kan monteres på vegg:	Ja
Høyttalertelefon:	Ja
Antall linjer:	24 linjer
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 95
Display antall farger:	Monochrome
Display:	LCD
Strøm over Ethernet (PoE):	Ja
Stemmekodekser:	G.711a, G.729A, G.729B, G.729ab
Telefonlistekapasitet:	- oppføringer
Håndsett-type:	Kablet håndsett
Ringe-ID:	Nei
Gjenoppringing:	Ja
Ethernet LAN-grensesnittype:	Raskt Ethernet
Vis antall linjer:	3 linjer
Funksjoner for flere håndsett:	1
Samtaleanlegg:	Nei
