Side 1/4

AIR-AP1840I-I-K9 Datasheet
Get a Quote
Overview
The Cisco® Aironet 1840 Access Points delivers an ideal blend of predictable performance in a compact form factor. Packed with 802.11ac Wave
2 features and Bluetooth Low Energy (BLE) for location-based services, this platform is ideal for small to mid-size enterprise deployments.
Product Details
Cisco AP AIR-AP1840I Series provides these features:
-802.11ac Wave 1 and 2 capabilities
-Multiuser Multiple-Input Multiple-Output (MU-MIMO) technology
-Intelligent Capture
-Cisco Mobility Express
-Bluetooth 4.2
Supported Platforms
Table 1 shows the supported platforms and software.
Supported wireless LAN controllers and Software Recommended Model
Cisco 3500 Series Wireless Controllers AIR-CT3504-K9
Cisco 5520 Series Wireless Controllers AIR-CT5520-K9
Cisco 8540 Series Wireless Controllers AIR-CT8540-K9
AIR-CT8540-1K-K9
Cisco 9800 series Wireless Controllers C9800-40-K9
C9800-80-K9
Cisco Virtual Wireless Controller /
Cisco Unified Wireless Network Software Release 8.8 MR2 or later /
Cisco IOS ® XE Software Release 16.11 or later /
Compare to Similar Items
Table 2 shows the comparison of Cisco AIR-AP1840I Series.
SKU Description
AIR-AP1840I-A-K9 Cisco Aironet AP1840I Series access point - A domain
AIR-AP1840I-B-K9 Cisco Aironet AP1840I Series access point - B domain
AIR-AP1840I-D-K9 Cisco Aironet AP1840I Series access point - D domain
AIR-AP1840I-E-K9 Cisco Aironet AP1840I Series access point - E domain
AIR-AP1840I-F-K9 Cisco Aironet AP1840I Series access point - F domain
AIR-AP1840I-G-K9 Cisco Aironet AP1840I Series access point - G domain
AIR-AP1840I-H-K9 Cisco Aironet AP1840I Series access point - H domain
AIR-AP1840I-I-K9 Cisco Aironet AP1840I Series access point - I domain

AIR-AP1840I-K-K9 Cisco Aironet AP1840I Series access point - K domain

AIR-AP1840I-N-K9 Cisco Aironet AP1840I Series access point - N domain

AIR-AP1840I-S-K9 Cisco Aironet AP1840I Series access point - S domain

AIR-AP1840I-T-K9 Cisco Aironet AP1840I Series access point - T domain

AIR-AP1840I-Z-K9 Cisco Aironet AP1840I Series access point - Z domain

Get More Information

Do you have any question about the AIR-AP1840I-I-K9?

Speciﬁcation

AIR-AP1840I-I-K9 Specification

Description Cisco Aironet AP1840I Series access point - I domain

Software •Cisco Unified Wireless Network Software Release 8.8 MR2 or later

• Cisco IOS ® XE Software Release 16.12 or later

Supported wireless LAN controllers •Cisco Catalyst 9800 Wireless Controllers

•Cisco 3500, 5520 and 8540 Series Wireless Controllers, Cisco Virtual

Wireless Controller

•Cisco Mobility Express

802.11n version 2.0 (and related) capabilities •5 GHz, 4x4 MIMO with four spatial streams

•2.4 GHz, 2x2 MIMO with two spatial streams

•Maximal Ratio Combining (MRC)

•802.11n and 802.11a/g beamforming

•20 and 40 MHz channels

•PHY data rates up to 744 Mbps (40 MHz with 5 GHz and 20MHz with

2.4GHz)

•Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

•802.11 Dynamic Frequency Selection (DFS)

•Cyclic Shift Diversity (CSD) support

802.11ac •4x4 downlink MU-MIMO with four spatial streams

•MRC

•802.11ac beamforming

•20, 40, 80 MHz channels

•PHY data rates up to 1733 Mbps (80MHz with 5 GHz)

•Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

•802.11 DFS

•CSD support

Integrated antenna •2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in

azimuth

•5 GHz, peak gain 5 dBi, internal antenna, omnidirectional in azimuth

Interfaces •2 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet

(PoE)

•Management console port (RJ-45)

•USB 2.0 (enabled via future software)

Indicators •Status LED indicates boot loader status, association status, operating

status, boot loader warnings, boot loader errors

Dimensions (W x L x H) • Access point (without mounting brackets): AIR-AP1840I: 7 x 7 x 1.5

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	AIR-AP1840I-H-K9
Vekt:	430 g
Bredde:	177.8 mm
Dybde:	177.8 mm
Høyde:	38.1 mm
LED-indikatorer:	Ja
Bluetooth:	Ja
Plassering:	Vegg
Bluetooth-versjon:	4.2
Antall USB 2.0-porter:	1
Internminne:	1000 MB
Flash-minne:	256 MB
Universal Plug and Play (UPnP):	Ja
Maksimal dataoverføringshastighet:	1733 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Integrert antenne
Type antenneretning:	Rundtvirkende
Produktfarge:	Hvit
Monteringssett:	Ja
Pakketype:	Boks
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Relativ luftfuktighet under drift (H-H):	10 - 90
Webbasert administrasjon:	Ja
Strøm over Ethernet (PoE):	Ja
Antennetype:	Innvendig lys
Antenne forbedringsnivå (max):	5 dBi
Antall antenner:	2
MIMO:	Ja
