Cisco Aironet 1550 Series Outdoor Mesh Access Point Hardware Installation Guide

OL-24247-01

Preface

This section describes the objectives, audience, organization, and conventions of the Cisco Aironet 1550

Series Outdoor Mesh Access Point Hardware Installation Guide.

Objectives

This publication explains the steps for installing the Cisco Aironet 1550 Series Outdoor Mesh Access

Point (called the access point in this document). The access point is available in model 1552.

The 1552 model is a dual-radio platform that supports dual-band (2.4- and 5-GHz) operation.

Audience

This publication is for the person installing and configuring an access point for the first time. The

installer should be familiar with network structures, terms, and concepts.

Warning

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

Warning

This equipment must be installed in restricted access locations in Norway, Finland, and Sweden. Only

trained and qualified personnel are allowed to install, replace, or service this equipment as

instructed in this installation guide.

Cisco Aironet 1550 Series Outdoor Mesh Access Point Hardware Installation Guide

OL-24247-01

Running H/F 3

Running H/F 2

Organization

This guide contains the following sections:

Conventions

This publication uses the following conventions:

Chapter Title Description

Chapter 1 Overview Describes the major components and features

of the access point.

Chapter 2 Installing the Access Point Provides warnings, safety information, and

mounting information you need to install your

access point.

Chapter 3 Troubleshooting Provides basic troubleshooting procedures for

the access point.

Chapter 4 Installing or Replacing the

Backup Battery

Describes the procedures to install or replace

the backup battery in the access point.

Appendix A Translated Safety Warnings Indicates how to access the document that

provides translations of the safety warnings

that appear in this publication.

Appendix B Declarations of Conformity

and Regulatory Information

Describes the regulatory conventions to which

the access point conforms and provides

guidelines for operating access points in Japan.

Appendix C Channels and Power Levels Indicates how to access the document that lists

the access point radio channels and the

maximum power levels supported by the world

regulatory domains.

Appendix D Access Point Specifications Lists technical specifications for the access

point.

Appendix E Access Point Pinouts Describes the connector pinouts for the access

point.

Appendix F Configuring DHCP Option

Describes the procedure to configure DHCP

Option 43.

Convention Description

boldface font Commands, command options, and keywords are

in boldface.

italic font Arguments for which you supply values are in

italics.

[ ] Elements in square brackets are optional.

screen font

Terminal sessions and information the system

displays are in screen font.

boldface screen font

Information you must enter is in boldface screen

font.

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 1550
Vekt:	8000 g
Bredde:	312 mm
Dybde:	229 mm
Høyde:	163 mm
Plassering:	Ceiling, Wall
Sertifisering:	ANSI, EN, FCC, RSS, AS/NZS, ICES
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
MAC-adressefiltrering:	Ja
Maksimal dataoverføringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Avtakbar antenne
Antall kanaler:	18 kanaler
WAN-port:	Ethernet (RJ-45)
Produktfarge:	Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-40 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-50 - 85 °C
Quality of Service (QoS) støtte:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	802.1x RADIUS, EAP, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA, WPA-AES, WPA2
Intern:	Nei
Webbasert administrasjon:	Nei
Strøm over Ethernet (PoE):	Ja
Antenne forbedringsnivå (max):	7 dBi
Frekvensbånd og driftskanaler:	2.4, 5 GHz
VPN-støtte:	IPsec, L2TP
Antall antenner:	3
Overføringskraft:	28 dBmW
Wi-Fi-dataoverføringshastighet (maks.):	300 Mbit/s
MIMO:	Ja
Antall forbindelser:	3
