Side 1/38

GETTING STARTED GUIDE

Cisco Aironet 1600 Series Access Points

First Published: December, 2012

Last Updated: March 31, 2015

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Troubleshooting

11 Declarations of Conformity and Regulatory Information

12 Access Point Specifications

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 1600 Series

Access Point. The 1600 Series Access Point is referred to as the 1600 series or the access point in this

document.

2 Introduction to the Access Point

The 1600 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated and external antenna

options. The access points support full interoperability with leading 802.11n clients, and support a

mixed deployment with other access points and controllers.

The 1600 series access point is available in controller-based mode and supports:

• Simultaneous single-band or dual-band (2.4 GHz/5 GHz) radios

• Integrated antennas on 1602I access point models (AIR-CAP1602I-x-K9, AIR-AP1602I-UXK9)

• External antennas on 1602E access point models (AIR-CAP1602E-x-K9, AIR-AP1602E-UXK9)

Note The ‘x’ in the model numbers represents the regulatory domain. Model numbers

containing -UX, support the universal regulatory domain. For information on supported

regulatory domains, see “Regulatory Domains” section on page 6.

The features of the 1600 series are:

• Processing sub-systems (including CPUs and memory) and radio hardware which supports:

–

Network management

–

ClientLink 2.0—BeamForming to 802.11n clients as well as legacy 802.11a/g OFDM clients

–

VideoStream

–

Location

–

WIDS/WIPS

–

Security

–

Radio Resource Management (RRM)

–

Rogue detection

–

Management Frame Protection (MFP)

• 32 MB flash size

• 802.11af/at

–

CDP (Cisco Discovery Protocol)

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 1600i
Vekt:	860 g
Bredde:	221 mm
Dybde:	47 mm
Høyde:	221 mm
LED-indikatorer:	Ja
Plassering:	Ceiling, Wall
Sertifisering:	UL 60950-1\nCAN/CSA-C22.2 No. 60950-1 \nUL 2043\nIEC 60950-1\nEN 60950-1
Internminne:	256 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Flash-minne:	32 MB
Maksimal dataoverføringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Integrert antenne
Antall kanaler:	29 kanaler
AC-inngangsspenning:	44 - 57 V
Produktfarge:	Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Driftshøyde:	0 - 3000 m
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	802.1x RADIUS, AES, EAP, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H):	10 - 90
Intern:	Nei
Strøm over Ethernet (PoE):	Ja
Frekvensbånd og driftskanaler:	2.412 - 2.472, 5.18 - 5.32, 5.5 - 5.7 GHz
Wi-Fi Multimedia (WMM)/(WME):	Ja
Wi-Fi-dataoverføringshastighet (maks.):	300 Mbit/s
Høyde når uvirksom:	0 - 4572 m
