GETTING STARTED GUIDE

Cisco Aironet 1600 Series Access Points

December, 2012

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Troubleshooting

11 Declarations of Conformity and Regulatory Information

12 Configuring DHCP Option 43 and DHCP Option 60

13 Access Point Specifications

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 1600 Series

Access Point. The 1600 Series Access Point is referred to as the 1600 series or the access point in this

document.

2 Introduction to the Access Point

The 1600 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated and external antenna

options. The access points support full inter-operability with leading 802.11n clients, and support a

mixed deployment with other access points and controllers.

The 1600 series access point is available in controller-based mode and in cloud-enabled mode and

supports:

• Simultaneous single-band or dual-band (2.4 GHz/5 GHz) radios

• Integrated antennas on 1602I access point models (AIR-CAP1602I-x-K9)

• External antennas on 1602E access point models (AIR-CAP1602E-x-K9)

Note The ‘x’ in the model numbers represents the regulatory domain. Refer to “Regulatory

Domains” section on page 6 for a list of supported regulatory domains.

The features of the 1600 series are:

• Processing sub-systems (including CPUs and memory) and radio hardware which supports:

–

Network management

–

ClientLink 2.0—BeamForming to 802.11n clients as well as legacy 802.11a/g OFDM clients

–

VideoStream

–

Location

–

WIDS/WIPS

–

Security

–

Radio Resource Management (RRM)

–

Rogue detection

–

Management Frame Protection (MFP)

–

Cloud-based mode (on AIR-CLD1602I-x-K9 models)

• 32 MB flash size

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 1602
Vekt:	860 g
Bredde:	221 mm
Dybde:	221 mm
Høyde:	47 mm
LED-indikatorer:	Ja
Sertifisering:	FCC Bulletin OET-65C\r\nRSS-102
Internminne:	256 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3af
Flash-minne:	32 MB
Sikkerhet:	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1
Maksimal dataoverføringshastighet:	300 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Avtakbar antenne
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Samsvar med industristandarder:	IEEE 802.11a/b/g, IEEE 802.11n, IEEE 802.11h, IEEE 802.11d
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	EAP, EAP-TLS, EAP-TTLS, PEAP, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H):	-10 - 90
Intern:	Nei
Webbasert administrasjon:	Nei
Strøm over Ethernet (PoE):	Ja
Antenne forbedringsnivå (max):	6 dBi
Frekvensbånd og driftskanaler:	2.4, 5 GHz
