GETTING STARTED GUIDE
Cisco Aironet 2600 Series Access Points
July, 2012
P/N: 78-20842-01
1 About this Guide
2 Introduction to the Access Point
3 Safety Instructions
4 Unpacking
5 Configurations
6 Access Point Ports and Connectors
7 Configuring the Access Point
8 Mounting the Access Point
9 Deploying the Access Point on the Wireless Network
10 Troubleshooting
11 Declarations of Conformity and Regulatory Information
12 Configuring DHCP Option 43 and DHCP Option 60
13 Access Point Specifications
2
1 About this Guide
This Guide provides instructions on how to install and configure your Cisco Aironet 2600 Series
Access Point. The 2600 Series Access Point is referred to as the 2600 series or the access point in this
document.
2 Introduction to the Access Point
The 2600 series supports high-performing Spectrum Intelligence which sustains three spatial stream
rates over a deployable distance with high reliability when serving clients. The 2600 series provides
high reliability and overall wireless performance.
The 2600 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated and external antenna
options. The access points support full inter-operability with leading 802.11n clients, and support a
mixed deployment with other access points and controllers.
The 2600 series access point is available in both controller-based (Unified) and standalone
(Autonomous) configurations and supports:
Simultaneous single-band or dual-band (2.4 GHz/5 GHz) radios
Integrated antennas on 2602I access point models (AIR-CAP2602I-x-K9)
External antennas for rugged 2602E access point models (AIR-CAP2602E-x-K9)
Note The ‘x’ in the model numbers represents the regulatory domain. Refer to “Regulatory
Domains” section on page 6 for a list of supported regulatory domains.
The features of the 2600 series are:
Processing sub-systems (including CPUs and memory) and radio hardware which supports:
Network management
CleanAir—Automatic detection, classification, location and mitigation of RF interference
(not available on autonomous or standalone models)
ClientLink 2.0—BeamForming to 802.11n clients as well as legacy 802.11a/g OFDM clients
VideoStream
Location
WIDS/WIPS
Security
Radio Resource Management (RRM)
Rogue detection

Produkspesifikasjoner

Merke: Cisco
Kategori: Tilgangspunkt
Modell: Aironet 2602E
Vekt: 1040 g
Bredde: 221 mm
Dybde: 54 mm
Høyde: 221 mm
LED-indikatorer: Ja
Plassering: Ceiling, Wall
Internminne: 256 MB
Nettverksstandard: IEEE 802.11a, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Flash-minne: 32 MB
Maksimal dataoverføringshastighet: 1000 Mbit/s
2,4 GHz: Ja
5 GHz: Ja
Antennefunksjoner: Avtakbar antenne
AC-inngangsspenning: 44 - 57 V
Produktfarge: Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45): 1
Driftstemperatur (T-T): -20 - 55 °C
Oppbevaringstemperaturomåde (Celsius): -30 - 70 °C
Driftshøyde: 0 - 3000 m
Ethernet LAN dataoverføringshastigheter: 10,100,1000 Mbit/s
Sikkerhetsalgoritmer: 802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H): -20 - 55
Intern: Nei
Antenne forbedringsnivå (max): 6 dBi
Frekvensbånd og driftskanaler: 2.4, 5 GHz
Wi-Fi Multimedia (WMM)/(WME): Ja
Wi-Fi-dataoverføringshastighet (maks.): 450 Mbit/s
Høyde når uvirksom: 0 - 4500 m
Antall forbindelser: 4
