Side 1/88

Cisco Systems, Inc.

www.cisco.com

Cisco Aironet Series 1700/2700/3700 Access Point

Deployment Guide

Last Updated: October, 2014

Cisco Aironet Series 3700 Access Point

Abstract

This section covers the Cisco 3700 Series Access Points theory of operation and installation as part of a Cisco wireless LAN

(WLAN) solution. Subjects related include:

• Choosing the right Access Point (AP).

• Differences between AP 3700 and AP 3600.

• Feature module and ClientLink support.

• Physical/Hardware details, mounting options, bracket choices, and installation considerations.

• Antenna options, radiation patterns, and external antenna deployments.

• Understanding spatial streams, MCS rates and beam-forming (802.11n Primer).

• Review of 802.11ac and Wave-1 module for AP 3600.

• Understanding 802.11ac and Wave-1 for the AP 3700.

• Best Practices–Understanding Channel usage, 80 MHz, and available 11ac clients.

• 802.11ac performance considerations.

This document is intended for trained and experienced technical personnel familiar with the existing Cisco Wireless

Networking Group (WNG) product line and features.

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 2702E
Vekt:	1000 g
Bredde:	221 mm
Dybde:	221 mm
Høyde:	51 mm
LED-indikatorer:	Ja
Sertifisering:	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1, EN 50155
Internminne:	512 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at
Antall brukere:	- bruker(e)
Flash-minne:	64 MB
MIMO-type:	Multi User MIMO
Maksimal dataoverføringshastighet:	1300 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Cyclic Shift Diversity (CSD):	Ja
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Hvit
Strømforbruk (vanlig bruk):	15 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	-20 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	EAP, EAP-TLS, EAP-TTLS, PEAP, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H):	10 - 90
Intern:	Nei
Webbasert administrasjon:	Nei
Strøm over Ethernet (PoE):	Ja
Frekvensbånd og driftskanaler:	2.4, 5 GHz
Wi-Fi-dataoverføringshastighet (maks.):	1300 Mbit/s
MIMO:	Ja
Maximal-Ratio Combining (MRC):	Ja
Dynamic Frequency Selection (DFS):	Ja
