GETTING STARTED GUIDE

Cisco Aironet 3600 Series Lightweight Access Points

Last Updated: March 31, 2015

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Installing Modules

11 Troubleshooting

12 Declarations of Conformity and Regulatory Information

13 Configuring DHCP Option 43 and DHCP Option 60

14 Access Point Data Sheet

15 Obtaining Documentation and Submitting a Service Request

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 3600 Series Access Point and how to install

any port modules. This guide also provides mounting instructions and limited troubleshooting procedures.

The 3600 Series Access Point is referred to as the access point in this document.

2 Introduction to the Access Point

The 3600 series supports high-performing Spectrum Intelligence which sustains three spatial stream rates over a deployable

distance with high reliability when serving clients. The 3600 series provides high reliability and overall wireless performance.

The 3600 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated and external antenna options. The access points

support full inter-operability with leading 802.11n clients, and support a mixed deployment with other access points and

controllers.

The 3600 series access point is a controller-based (Unified) product and supports:

• Simultaneous dual-band (2.4 GHz/5 GHz) radios

• Integrated antennas on the 3602I access point model (AIR-CAP3602I-x-K9, AIR-AP3602I-UXK9)

• External antennas for rugged 3602E access point model (AIR-CAP3602E-x-K9, AIR-AP3602E-UXK9)

Note The ‘x’ in the model numbers represents the regulatory domain. Model numbers containing -UX, support the

universal regulatory domain. Refer to “Regulatory Domains” section on page 5 for a list of supported regulatory

domains.

The features of the 3600 series are:

• Processing sub-systems (including CPUs and memory) and radio hardware which supports:

–

Network management

–

CleanAir —Automatic detection, classification, location and mitigation of RF interference

–

ClientLink+ —BeamForming to 802.11n clients as well as legacy 802.11a/g OFDM clients

–

VideoStream

–

Location

–

WIDS/WIPS

–

Security

–

Radio Resource Management (RRM)

–

Rogue detection

–

Management Frame Protection (MFP)

–

Throughput, forwarding, and filtering performance scaled to meet 3 spatial stream 450 Mbps data-rates

• 32 MB flash size

• 802.11af/at

–

CDP (Cisco Discovery Protocol)

• 2.4 GHz and 5 GHz 802.11n radios with the following features:

–

4TX x 4RX

–

3-spatial streams, 450 Mbps PHY rate

–

Spectrum intelligence

–

DPD (Digital Pre-Distortion) technology

–

Cisco Vector Beamforming—Implicit Co-phase beamforming for .11ag clients and 1x1 11n clients

–

Radio hardware is capable of explicit compressed beamforming (ECBF) per 802.11n standard

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 3600i
Vekt:	1130 g
Bredde:	221 mm
Dybde:	221 mm
Høyde:	54 mm
LED-indikatorer:	Ja
Plassering:	Ceiling, Wall
Sertifisering:	UL 60950-1\nCAN/CSA-C22.2 No. 60950-1\nUL 2043\nIEC 60950-1\nEN 60950-1\nEN 50155
Internminne:	256 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x
Utgangsstrøm:	44 - 57 V
Flash-minne:	32 MB
MIMO-type:	Multi User MIMO
Maksimal dataoverføringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Cyclic Shift Diversity (CSD):	Ja
Antennefunksjoner:	Integrert antenne
Antall kanaler:	18 kanaler
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Hvit
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Driftshøyde:	0 - 3000 m
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	AES, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H):	10 - 90
Intern:	Nei
Strøm over Ethernet (PoE):	Ja
Antenne forbedringsnivå (max):	4 dBi
Frekvensbånd og driftskanaler:	2.412 - 2.472, 5.745 - 5.825 GHz
Overføringskraft:	23 dBmW
Wi-Fi Multimedia (WMM)/(WME):	Ja
Wi-Fi-dataoverføringshastighet (maks.):	450 Mbit/s
MIMO:	Ja
Høyde når uvirksom:	0 - 4572 m
Maximal-Ratio Combining (MRC):	Ja
Dynamic Frequency Selection (DFS):	Ja
