Side 1/27

GETTING STARTED GUIDE

Cisco Aironet 700 Series Access Points

First Published: June 2013

Last Updated: January 5, 2016

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Troubleshooting

11 Declarations of Conformity and Regulatory Information

12 Configuring DHCP Option 43 and DHCP Option 60

13 Access Point Specifications

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 700 Series Access Point. The 700 Series

Access Point is referred to as the 700 series or the access point in this document.

2 Introduction to the Access Point

The 700 series supports high-performing two spatial stream rates over a deployable distance with high reliability when serving

clients. The 700 series provides high reliability and overall wireless performance.

The 700 series offers dual-band radios (2.4 GHz and 5 GHz) with integrated internal antennas. The access point supports full

interoperability with leading 802.11n clients.

The 700 series access point is available in the controller-based and autonomous configurations and supports:

• Simultaneous dual-band (2.4 GHz/5 GHz) radios

• Integrated antennas on 702I access point models (AIR-CAP702I-x-K9, AIR-AP702I-UXK9)

Note The ‘x’ in the model numbers represents the regulatory domain. Model numbers containing -UX, support the

universal regulatory domain. Refer to “Regulatory Domains” section on page 4 for a list of supported regulatory

domains.

The features of the 700 series are:

• Processing sub-systems for controller-based models (including CPUs and memory) and radio hardware which supports:

–

Unified

–

FlexConnect

–

Monitor-mode

Note Enhanced Local Mode (ELM) is not supported.

• The following processor features:

–

128 MB NAND flash size

–

1 MB NOR flash size

–

128 MB DDR2 memory bus, x32

• 2.4 GHz and 5 GHz 802.11n radios with the following features:

–

802.11n standard compliant

–

A-MPDU TX

–

HT Duplicate Mode

–

2TX x 2RX

–

2-spatial streams, 300 Mbps PHY rate

–

Maximal ratio combining (MRC)

–

Cyclic Shift Diversity (CSD)

–

MCS0-MCS15; Short or Long Guard Intervals

–

DFS for UNII-2 and UNII-2 Extended channels, including 0.5us radar pulse detection

3 Safety Instructions

Translated versions of the following safety warnings are provided in the translated safety warnings document that is shipped

with your access point. The translated warnings are also in the Translated Safety Warnings for Cisco Aironet Access Points,

which is available on Cisco.com.

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Aironet 702i
Vekt:	480 g
Bredde:	177.6 mm
Dybde:	177.6 mm
Høyde:	50.4 mm
LED-indikatorer:	Ja
Internminne:	128 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x
Flash-minne:	128 MB
Maksimal dataoverføringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Integrert antenne
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Hvit
Strømforbruk (vanlig bruk):	9.5 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	EAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, TKIP, WPA, WPA2
Relativ luftfuktighet under drift (H-H):	10 - 90
Intern:	Nei
Webbasert administrasjon:	Nei
Antennetype:	Innvendig lys
Antenne forbedringsnivå (max):	5 dBi
Frekvensbånd og driftskanaler:	2.4, 5 GHz
Wi-Fi-dataoverføringshastighet (maks.):	300 Mbit/s
