Side 1/16

Data Sheet

Catalyst 4500E Supervisor Engine 7-E: Leading

Borderless Network Access and Aggregation

Supervisor Engine Data Sheet

Overview

Establishing borderless leadership is now easier than ever to achieve with the new Cisco

Catalyst

4500E

Supervisor Engine 7-E (Figure 1), an enterprise-class Borderless Networks access and aggregation supervisor

engine designed to provide 848 Gbps per system with E-Series chassis. Cisco Catalyst 4500E Supervisor

Engine 7-E is the first Cisco Catalyst supervisor engine to provide 48 Gbps per slot with Flexible NetFlow (FNF)

and Advanced Security combined with reduced total cost of ownership (TCO) and excellent investment protection.

With these capabilities; four 10 Gigabit Ethernet uplinks; and 10/100/1000 Power over Ethernet (PoE), PoE Plus

(PoEP), and Cisco Universal PoE (UPoE) ports, this supervisor engine is undoubtedly Cisco's leading Borderless

Networks access supervisor engine in the Cisco Catalyst Family. Supervisor Engine 7-E is built with price-

performance aggregation deployments in mind, providing increased Gigabit Ethernet and 10 Gigabit Ethernet fiber

density along with hardware capabilities to support enterprise-class aggregation functions. Supervisor Engine 7-E

facilitates user experiences for enterprise, public sector, mid-market, and commercial customer deployment

business-critical applications.

Cisco leadership in Borderless Networks is extended with important features - hardware readiness for Cisco

TrustSec

technology, medianet, Flexible NetFlow, Cisco EnergyWise

™

technology, Cisco Powered Workspace -

and other feature enhancements enabled by the Cisco Catalyst 4500E Supervisor Engine 7-E. Backward and

forward compatibility with most existing Cisco Catalyst 4500 and 4500E line cards helps assure deeper customer

satisfaction with the industry's best investment protection architecture. Cisco Catalyst Supervisor Engine 7-E is

supported in Cisco Catalyst 4500 E-Series chassis only.

The Cisco Catalyst 4500E Supervisor Engine 7-E delivers several new technology breakthroughs and industry

firsts, extending the Cisco Catalyst 4500 Series placement from a premium wiring closet solution into next-

generation borderless access and aggregation deployments.

The Supervisor Engine 7-E offers the following important leading innovations and capabilities:

●

More than 10 years of investment protection through backward and forward compatibility

●

Cisco Catalyst switch with 48 Gbps per slot (848 Gbps per system)

●

Around 5 microseconds of latency to and from any 10 Gigabit Ethernet port

●

First Cisco Catalyst switch with campus FNF

●

First Cisco Catalyst switch offering Cisco IOS

XE Modular Software services

●

First Cisco Catalyst switch with less than 200 msec In-Service Software Upgrade (ISSU) high availability

●

First Cisco Catalyst switch for next-generation Cisco Powered Workspace (Energy Efficient Ethernet [EEE]

and UPOE)

●

First and only modular switch with 8 bidirectional line rate Switched Port Analyzer (SPAN) or Remote SPAN

(RSPAN) sessions

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Ruter
Modell:	Catalyst 4500E
Nettverksstandard:	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3az
Elektromagnetisk kompatibilitet:	FCC Part 15 (CFR 47) Class A, ICES-003 Class A, EN55022 Class A, CISPR22 Class A, AS/NZS 3548 Class A, VCCI Class A, ETS 300 386, EN 55022, EN 55024, EN 61000-6-1, EN 50082-1, EN 61000-3-2, EN 61000-3-3
Sikkerhet:	UL 60950CAN/CSA-C22.2 No. 60950, EN 60950, IEC 60950, TS 001, AS/NZS 3260
Kompatibilitet:	Cisco Catalyst 4500
Antall VLAN:	4094
Strømforbruk (vanlig bruk):	280 W
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 75 °C
Harmonisert system (HS)-kode:	85176990
Quality of Service (QoS) støtte:	Ja
Driftshøyde:	-60 - 3000 m
Ethernet LAN dataoverføringshastigheter:	10,100,1000,10000 Mbit/s
Relativ luftfuktighet under drift (H-H):	10 - 90
Størrelse på adressetabell:	55000 oppføringer
Ruting/svitsjekapasitet:	848 Gbit/s
Største båndbredde for port:	48 Gbit/s
Videresendingshastighet:	250 Mpps
SFP module antall spor:	4
Access Control List (ACL)/tilgangskontrolliste:	Ja
Address Resolution Protocol (ARP)-oppføringer:	47000
Køer per port:	8
