Cisco Catalyst 9115AX Bruksanvisning

Cisco Tilgangspunkt Catalyst 9115AX

Les nedenfor 📖 manual på norsk for Cisco Catalyst 9115AX (38 sider) i kategorien Tilgangspunkt. Denne guiden var nyttig for 2 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/38

Deployment Guide

Cisco Catalyst 9115 and 9117

Series Access Points

Contents

Revision history ............................................................................................................Error! Bookmark not defined.

Wi-Fi 6 primer – how is it different from 802.11ac? .............................................................................................. 3

Choosing the right access point ............................................................................................................................ 6

Models .................................................................................................................................................................. 6

Access point physical hardware and mounting options ...................................................................................... 7

Channel rail adapters .......................................................................................................................................... 11

Wall mounting the access point .......................................................................................................................... 12

Changing the color of an access point ................................................................................................................ 13

Unique installations ............................................................................................................................................... 14

Clean rooms (healthcare).................................................................................................................................... 14

Above the ceiling tiles ......................................................................................................................................... 15

Stadium and harsh environments ....................................................................................................................... 17

Areas with high vibration ..................................................................................................................................... 18

Warehouse and factory environments ................................................................................................................ 18

Ethernet cable recommendation ......................................................................................................................... 20

Antenna cable recommendation ......................................................................................................................... 20

Access point spacing recommendations ............................................................................................................. 21

Installations in IDF closets (telecommunications or other electrical equipment) ................................................. 21

Installations inside and around elevators ............................................................................................................ 21

External antenna options and patterns ................................................................................................................ 22

For use with the Cisco Catalyst 9115E Access Point .......................................................................................... 22

Cisco Catalyst 9115I internal antenna model ...................................................................................................... 29

Understanding external antenna deployments ................................................................................................... 34

Power over Ethernet .............................................................................................................................................. 36

General considerations regarding access points ............................................................................................... 37

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Catalyst 9115AX
Vekt:	900 g
Bredde:	203 mm
Dybde:	203 mm
Høyde:	38 mm
LED-indikatorer:	Ja
Plassering:	Bord
USB-kontakttype:	USB Type-A
Opprinnelsesland:	Mexico
Pakkevekt:	530.61 g
Antall USB 2.0-porter:	1
Internminne:	2048 MB
Antall per pakke:	1 stykker
Nettverksstandard:	IEEE 802.11ax, IEEE 802.11n, IEEE 802.3ac
Flash-minne:	1024 MB
MIMO-type:	Multi User MIMO
Maksimal dataoverføringshastighet:	5380 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Cyclic Shift Diversity (CSD):	Ja
Produktfarge:	Hvit
Pakkedybde:	249.174 mm
Pakkehøyde:	84.074 mm
Pakkebredde:	230.124 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Harmonisert system (HS)-kode:	85176990
Quality of Service (QoS) støtte:	Ja
Driftshøyde:	0 - 3000 m
Oppgraderbar fastvare:	Ja
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	100,1000,2500 Mbit/s
Sikkerhetsalgoritmer:	802.1x RADIUS, AES, WPA, WPA2, WPA3
Relativ luftfuktighet under drift (H-H):	10 - 90
Webbasert administrasjon:	Ja
Strøm over Ethernet (PoE):	Ja
Antennetype:	Innvendig lys
Antenne forbedringsnivå (max):	4 dBi
Strømpluggtype:	Type C
Produkter per (indre) fraktkasse:	1 stykker
Produkter per masterkasse (ytterkasse):	1 stykker
MIMO:	Ja
Maximal-Ratio Combining (MRC):	Ja
Dynamic Frequency Selection (DFS):	Ja
