MR74 Installation Guide
The Cisco Meraki MR74 is a dual-band enterprise class 802.11ac cloud-managed access point. Designed for general
purpose network design, the MR74 meets the needs of the most demanding environments, and also includes the first
ever cloud-managed third radio dedicated to optimizing the RF environment and securing the airwaves.
The Meraki MR74 has an operating temperature of -40
o
to 55
o
C.
Package Contents
The MR74 package contains the following:
• MR74 Cloud-Managed Access Point
• Mount cradle
• Wall screws
• Wall screw anchors
• Grounding screws
• Mounting straps
Understanding the MR74
LED indicator
Your MR74 is equipped with a multi-color LED light on the bottom edge of the unit to convey information about system
functionality and performance:
• Orange - AP is booting (permanent Orange suggests hardware issue)
• Rainbow - AP is initializing/scanning
• Blinking Blue - AP is upgrading
• Green - AP in Gateway mode with no clients
• Blue - AP in Gateway mode with clients
• Blinking Orange - AP can't find uplink
The MR74 may be operated in “Run Dark” mode for additional security and to reduce the visibility of the access point. In
this mode, the LED will not be illuminated. This mode may be enabled through the Meraki dashboard.
1
Ethernet Port
The MR74 features 1 Ethernet port:
The port labeled “PoE” accepts 802.3af power and should be used as the primary uplink to your LAN/WAN.
N-Type antenna attachment ports (4x)
2x N-Type antenna ports are located at the top of the MR74 and 2x are located at the bottom of the MR74. The pairs of
antenna ports each correspond to the 2 client-serving radios. The spectrum that each pair serves is printed on the shell
of the MR74. In order to ensure highest performance, ensure antennas connected to the 4 ports have overlapping
coverage areas.
Mount plate attachment slots (4x)
The mounting slots located on the rear shell of the MR74 marry to the 4 mounting posts on the mounting plate, securely
fastening the MR74 to the mounting plate.
Factory reset button
The factory reset button is located in a small pin-sized hole just above the PoE Ethernet port of the MR74. If the button
is pressed and held for at least five seconds and then released, the MR74 will reboot and be restored to its original
factory settings by deleting all configuration information stored on the unit.
The Vent
The vent allows pressure equalization between the interior and the environment. This prevents internal condensation
and maintains a waterproof seal.
Understanding the MR74 mount plate
The mount cradle has the following features:
The mount plate is unique to the MR74. Previous outdoor AP mount plates are not compatible with the MR74.
2
