MR84 Installation Guide

The Cisco Meraki MR84 is a dual-band enterprise class 802.11ac cloud-managed access point. Designed for high

capacity and high density, the MR84 meets the needs of the most demanding environments, and also includes the first

ever cloud-managed third radio dedicated to optimizing the RF environment and securing the airwaves.

The Meraki MR84 has an operating temperature of -40

to 55

Package Contents

The MR84 package contains the following:

• MR84 Cloud-Managed Access Point

• Mount cradle

• Wall screws

• Wall screw anchors

• Grounding screws

• Mounting straps

Understanding the MR84

LED indicator

Your MR84 is equipped with a multi-color LED light on the bottom edge of the unit to convey information about system

functionality and performance:

• Orange - AP is booting (permanent Orange suggests hardware issue)

• Rainbow - AP is initializing/scanning

• Blinking Blue - AP is upgrading

• Green - AP in Gateway mode with no clients

• Blue - AP in Gateway mode with clients

• Blinking Orange - AP can't find uplink

The MR84 may be operated in “Run Dark” mode for additional security and to reduce the visibility of the access point. In

this mode, the LED will not be illuminated. This mode may be enabled through the Meraki dashboard.

Ethernet Port

The MR84 features 2 Ethernet ports:

The labeled “PoE” accepts 802.3at and 802.3af power and should be used as the primary uplink to your LAN/WAN.

The 2nd port may be used for LACP bonding with the PoE port

Link Aggregation

The second Ethernet port can be used in a bonded configuration with the "PoE" port. Ensure that the AP is

plugged into 2 switch ports on the same Ethernet switch that have been configured for LACP bonding. Keep in

mind that the maximum bonded aggregate bandwidth is 2.0 Gbps. See the MR Link Aggregation Configuration

Guide for more details

N-Type antenna attachment ports (4x)

2x N-Type antenna ports are located at the top of the MR84 and 2x are located at the bottom of the MR84. The 4

antenna ports are connected to both 2.4 GHz and 5 GHz client serving radios. In order to ensure highest performance,

ensure antennas connected to the 4 ports have overlapping coverage areas.

Mount plate attachment slots (4x)

The mounting slots located on the rear shell of the MR84 marry to the 4 mounting posts on the mounting plate, securely

fastening the MR84 to the mounting plate.

Factory reset button

The factory reset button is located in a small pin-sized hole just above the PoE Ethernet port of the MR84. If the button

is pressed and held for at least ﬁve seconds and then released, the MR84 will reboot and be restored to its original

factory settings by deleting all configuration information stored on the unit.

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Tilgangspunkt
Modell:	Meraki MR84
Vekt:	1700 g
Bredde:	286 mm
Dybde:	176 mm
Høyde:	185 mm
Plassering:	Vegg
Strømforbruk (maks.):	21 W
Nettverksstandard:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maksimal dataoverføringshastighet:	2500 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Virtuelle LAN-funksjoner:	Tagged VLAN
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	37 - 57 V
Type antenneretning:	Rundtvirkende
Produktfarge:	Hvit
Monteringssett:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	-40 - 60 °C
Quality of Service (QoS) støtte:	Ja
Internasjonal beskyttelses (IP)-kode:	IP67
Modulator:	256-QAM
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Sikkerhetsalgoritmer:	AES, IPSEC, TKIP
Relativ luftfuktighet under drift (H-H):	5 - 95
Intern:	Nei
Svitsjtype:	Håndtert
Webbasert administrasjon:	Ja
Strøm over Ethernet (PoE):	Ja
Frekvensbånd og driftskanaler:	2.412 - 5.825 GHz
Antall antenner:	4
VLAN støtte:	Ja
Antall forbindelser:	4
