Side 1/5

Cisco Systems, Inc.

Page 1 of 5

Product Bulletin No. 2081

End-of-Sale Announcement for Cisco NM-1FE1CT1,

NM-1FE1CT1-CSU, NM-1FE1CE1B, NM-1FE1CE1U,

NM-1FE2CT1, NM-1FE2CT1-CSU, NM-1FE2CE1B, and

NM-1FE2CE1U Network Modules and the Cisco

3620MBUNDLE-24DM and 3620MBUNDLE-30DM Dial

Bundles for the Cisco 3600 Series

The Cisco

NM-1FE1CT1, NM-1FE1CT1-CSU, NM-1FE1CE1B, NM-1FE1CE1U, NM-1FE2CT1,

NM-1FE2CT1-CSU, NM-1FE2CE1B, and NM-1FE2CE1U network modules were introduced in 1998. They

provide Fast Ethernet and T1/E1 connectivity options that, when combined with digital modem network

modules, enable digital dial in a Cisco 3620 while providing a LAN connection. Since the Cisco

NM-1FE2CT1-CSU and NM-1FE2CE1U are used in Cisco 3620 dial bundles—Cisco 3620MBUNDLE-24DM

and 3620MBUNDLE-30DM—it is also necessary to announce the end of sale of these bundles. Cisco is announcing

the end of sale of these network modules and associated bundles, with a last sale date of September 24, 2003.

Products Affected by this Announcement

The following Cisco products are affected by this announcement.

Table 1 Cisco Network Modules and Cisco 3620 Dial Bundles

End-of-Sale Product

Part Number Product Description

Network modules

NM-1FE1CE1B(=) One-port Fast Ethernet and one-port channelized E1/ISDN-PRI balanced network module

NM-1FE1CE1U(=) One-port Fast. Ethernet and one-port channelized E1/ISDN-PRI unbalanced

network module

NM-1FE1CT1(=) One-port Fast Ethernet and one-port channelized T1/ISDN-PRI network module

NM-1FE1CT1-CSU(=) One-port Fast Ethernet and one-port channelized T1/ISDN-PRI network module with

channel service unit (CSU)

NM-1FE2CE1B(=) One-port Fast Ethernet and two-port channelized E1/ISDN-PRI balanced network module

NM-1FE2CE1U(=) One-port Fast. Ethernet and two-port 2 Port channelized E1/ISDN-PRI unbalanced

network module

NM-1FE2CT1(=) One-port Fast Ethernet and two-port channelized T1/ISDN-PRI network module

NM-1FE2CT1-CSU(=) One-port Fast Ethernet and two-port channelized T1/ISDN-PRI network module with CSU

Cisco 3620 dial bundles

3620MBUNDLE-24DM Cisco 3620 PRI Dial Bundle: 1FE2CT1-CSU, 24DM, IP IOS

Cisco Systems, Inc.

Page 2 of 5

Recommended Replacement Products

Recommended Replacement Products for Cisco Network Modules

The recommended replacement products are the Cisco NM-1CT1, NM-1CT1-CSU, NM-1CE1B, NM-1CE1U,

NM-2CT1, NM-2CT1-CSU, NM-2CE1B, and NM-2CE1U network modules (Table 2). These modules are

supported in all of the Cisco 2600, 3600, and 3700 series routers. Please note that the recommended replacement

products do not include a built-in Fast Ethernet port. However for most applications and conﬁgurations, these

modules can still act as a direct replacement for the LAN/WAN combination network modules affected by this end

of sale announcement.

Details on the Cisco NM-1CT1, NM-1CT1-CSU, NM-1CE1B, NM-1CE1U, NM-2CT1, NM-2CT1-CSU,

NM-2CE1B, and NM-2CE1U network modules can be found in the data sheet, available at:

http://www.cisco.com/en/US/products/hw/routers/ps274/products_data_sheet09186a0080091b85.html

Recommended Migration for Cisco 3620 Dial Bundles

The recommended replacement products for Cisco 3620 dial bundles are the Cisco 3725 dial bundles. The

replacement one- and two-Primary Rate Interface (PRI) WAN network modules, when combined with the digital

modem network module in a Cisco 3725 dial bundle, provide the same capabilities as a similarly equipped Cisco

3620—but offer greater ﬂexibility and investment protection at the same solution price. Cisco 3725 dial solutions

offer the following advantages over similarly equipped Cisco 3620 solutions:

• An additional Fast Ethernet port

• Three additional WAN interface slots

3620BUNDLE-30DM Cisco 3620 PRI Dial Bundle: 1FE2CE1-U, 30DM, IP IOS

Table 2 Recommended Replacement Products

Fast Ethernet Plus Channelized T1/E1 Card Recommended Replacement

NM-1FE1CE1B(=) NM-1CE1B(=)

NM-1FE1CE1U(=) NM-1CE1U(=)

NM-1FE1CT1(=) NM-1CT1(=)

NM-1FE1CT1-CSU(=) NM-1CT1-CSU(=)

NM-1FE2CE1B(=) NM-2CE1B(=)

NM-1FE2CE1U(=) NM-2CE1U(=)

NM-1FE2CT1(=) NM-2CT1(=)

NM-1FE2CT1-CSU(=) NM-2CT1-CSU(=)

Table 1 Cisco Network Modules and Cisco 3620 Dial Bundles

End-of-Sale Product

Part Number Product Description

Produkspesifikasjoner

Merke:	Cisco
Kategori:	Ruter
Modell:	NM-1FE1CE1B=
Vekt:	1000 g
Formfaktor:	Plugg-inn
Videoopptaksgrensesnitt:	Ethernet 10Base-T/100Base-TX - RJ-45, ISDN PRI E1 - 15 pin D-Sub (DB-15)
Støttede dataoverføringsrater:	Full-duplex 2.05 Mbps E1
Datalinkprotokoll:	Ethernet, Fast Ethernet
