SE95008 Rev. 6
Operators Manual
Installation & Operation
Direct Steam Table Top Kettles
Table-Top Direct
Steam Kettles
MODELS: KDT- 1- T
KDT- 3- T
KDT- 6- T
KDT-12- T
KDT-20- T
SD Stands
MODELS: SD- 450
SD- 650
SD- 760
SD-1050
SD-1200
SD-1600
SD-1800
Kettles on
SD Stands
MODELS: SD-450- K 6
SD-650 - K12
SD-760 - K12
SD-760 - K20
SD-1050- K 6 6
SD-1200- K 6 12
SD-1600- K 6 20
SD-1600- K 12 12
SD-1600- K 12 20
SD-1600- K 20 20
1333 East 179th St., Cleveland, Ohio, U.S.A. 44110
Phone: (216) 481-4900 Fax: (216) 481-3782
Visit our web site at www.clevelandrange.com
Clev elan
d
™
Enodis
For a complete Service Manual
refer to www.clevelandrange.com
Shut off power at main
fuse disconnect prior
to servicing.
Ensure kettle is at room
temperature and pressure
gauge is showing zero or less
prior to removing any fittings.
Inspect unit daily for
proper operation.
0
Do not fill kettle above
recommended level
marked on outside of kettle.
Surfaces may be
extremely hot! Use
protective equipment.
Keep appliance and area free
and clear of combustibles.
Stand clear of product
discharge path when
discharging hot product.
Wear protective equipment
when discharging hot product.
Do not lean on or place
objects on kettle lip.
Do not attempt to operate
this appliance during a
power failure.
Keep clear of pressure
relief discharge.
Keep hands away from
moving parts and pinch points.
SERVICING
IMPORTANT
CAUTION
DANGER
GAS APPLIANCES
For your safety
GENERAL
Installation of the unit must be accomplished by
qualified installation personnel working to all
applicable local and national codes. Improper
installation of product could cause injury or damage.
This unit is built to comply with applicable
standards for manufacturers. Included among
those approval agencies are: UL, NSF,
ASME/Ntl.Bd., CSA, ETL, CE, and others. Many
local codes exist, and it is the responsibility of the
owner/installer to comply with these codes.
INSPECTION
Before uncrating, visually inspect the unit for
evidence of damage during shipping. If damage
is noticed, do not unpack the unit, follow shipping
damage instructions.
SHIPPING DAMAGE
INSTRUCTIONS
If shipping damage to the unit is discovered or
suspected, observe the following guidelines in
preparing a shipping damage claim.
1. Write down a description of the damage or the
reason for suspecting damage as soon as it is
discovered. This will help in filling out the claim
forms later. If possible, take a polaroid picture.
2. As soon as damage is discovered or suspected,
notify the carrier that delivered the shipment.
3. Arrange for the carrier's representative to
examine the damage.
4. Fill out all carrier claims forms and have the
examining carrier sign and date each form.
CLEARANCE REQUIREMENTS
The first installation step is to refer to the
SPECIFICATION DRAWINGS at the back of this manual
in order to determine the exact location of the kettle.
CLEARANCE REQUIREMENTS TO
COMBUSTIBLE AND NONCOMBUSTIBLE
SURFACES:
RIGHT LEFT BACK
KDT-1-T 4" 0" 0"
KDT-3-T & KDT-6-T 4" 4" 1"
KDT-12-T & KDT-20-T 4" 4" 1.75"
Note: For SD Stands (with or without kettles) zero
clearance is required on the sides and back.
KETTLES
Table-top models must be positioned on a firm stand
or existing counter top and secured in place. An
optional modular cabinet base (SD Stand), with
level-adjustable legs is available .
1. Make two 1" holes for
the kettle legs.
2. Remove the leg mounting
locknuts and washers from
the kettle's legs.
3. Install the legs into the two
1" holes.
4. Position washers as
illustrated and secure
the kettle to its' base by
refastening the locknut
from underneath the
cabinet or countertop.
5. Once the kettle is secure,
screw the tilt handle into
the mounting block welded
to the side of the kettle.
6. Install service requirements
as required.
KETTLES c/w SD STAND
1. Place unit in desired location.
2. Place a carpenter's level on the kettle rim and
level the stand using the level adjustable feet.
3. Install service requirements as required.
INSTALLATION
A
DRILL TWO
1" HOLES
A
KDT-1-T 8 1/8"
KDT-3-T 10"
KDT-6-T 12"
KDT-12-T 19 1/2"
KDT-20-T 23 3/4"
COUNTERTOP
