Craftsman CMCC2520M1 Bruksanvisning
Craftsman
Kompressor
CMCC2520M1
Les nedenfor 📖 manual på norsk for Craftsman CMCC2520M1 (48 sider) i kategorien Kompressor. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/48
final page size: 8.5 x 5.5 in CRAFTSMANfinal page size: 8.5 x 5.5 in CRAFTSMAN
20V Max* 2.5 Gallon Cordless Air Compressor
Compresseur d’air sans fil de 9,46 litres
(2,5 gallons) 20 V max*
Compresor de Aire Inalámbrico de 9,46 liters
(2,5 Galones) 20V Máx*
CMCC2520
INSTRUCTION MANUAL | GUIDE D’UTILISATION | MANUAL DE INSTRUCTIONES
IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US.
POUR TOUTE QUESTION OU TOUT COMMENTAIRE, NOUS CONTACTER.
SI TIENE DUDAS O COMENTARIOS, CONTÁCTENOS.
1–888–331–4569 WWW.CRAFTSMAN.COM
English (original instructions) 1
Français (traduction de la notice d’instructions originale) 13
Español (traducido de las instrucciones originales) 28
Specifications/ Fiche technique/ Especificaciones
Model/ modèle/ modelo CMCC2520
Weight/ poids/ peso 21.5 Lbs. (9.75 Kg)/ 9,75 kg (21.5 lbs.)/ 9,75 Kg (21.5 libras)
Height/ hauteur/ altura 15.5" (393.7 mm)/ 393,7 mm (15,5 po)/ 393,7 mm (15,5")
Width/ largeur/ ancho 12.5" (317.5 mm)/ 317,5 mm (12,5 po)/ 317,5 mm (12,5")
Length/ longueur/ longitud 14.0" (355.6 mm)/ 355,6 mm (14,0 po)/ 355,6 mm (14,0")
Air tank capacity/ capacité du réservoir d’air/ capacidad del tanque de aire 2.5 Gallon (9.5 Liters)/ 9,5 liters (2,5 gallons)/ 9,5 litros (2,5 galones)
Approx cut-in pressure/ pression d’enclenchement approx./ Presión de arranque
aproximada
95 psi/ 95 lb/po
2
/ 95 psi
Approx. Cut-out pressure/ env. Pression de déclenchement/ presión de corte aprox. 125 psi/ 125 lb/po
2
/ 125 psi
Scfm @ 90 psi/ pi
3
/min standard à 90 psi/ scfm a 90 psi
1.0 **/ 1,0 **/ 1,0 **
Noise level/ niveau sonore/ nivel de ruido 80.0 dBA
+
/ 80,0 dBA
+
/ 80,0 dBA
+
Fuse type/ type de fusible/ fusible de tipo Time delay/ temporisation/ acción retardada
Regulated pressure rating (approximate) / pression nominale stabilisée
(approximative)/ clasificación de presión regulada (aproximadamente)
0–125 psi/ 0 a 125 lb/po
2 /
0–125 psi
Quick connect type/ type de raccord à connexion rapide/ tipo de conexión rápida 1/4" (6.4 mm) industrial/ 6,4 mm (1/4 po) industriel/
6,4 mm (1/4") Industrial
Pump Type/ Type de pompe/ Tipo bomba Oilless/ Sans huile/ Sin aceite
**Tested per iso 1217:1996/ testé conformément à la norme iso 1217:1996/probado según la norma iso 1217:1996
+Tested per iso 3744:1994/ testé conformément à la norme iso 3744:1994/probado según la norma iso 3744:1994
1
ENGLISH
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or any
product, call CRAFTSMAN toll free at: 1-888-331-4569.
1
Auto On/Off switch
2
Battery (not shown)
3
Battery release button (not shown)
4
Safety valve
5
Tank pressure gauge
6
Regulator pressure gauge
7
Regulator dial
8
Drain valve
9
Check valve
10
Quick-connect coupler
11
Carry handle
12
Tank
FRONT BACK
11
6
5
1
4 10
8
9
12
7
Fig. A
Produkspesifikasjoner
| Merke: | Craftsman |
| Kategori: | Kompressor |
| Modell: | CMCC2520M1 |
