final page size: 8.5 x 5.5 in CRAFTSMAN
10" (254 mm) Drill Press
10" (254 mm) Perforadora de columna
CMXEDAR300
INSTRUCTION MANUAL | MANUAL DE INSTRUCTIONES
IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US.
SI TIENE DUDAS O COMENTARIOS, CONTÁCTENOS.
1-888-331-4569 WWW.CRAFTSMAN.COM
English (original instructions) 1
Español (traducido de las instrucciones originales) 21
3
ENGLISH
COMPONENTS
1
Depth scale pointer
2
Feed handles
3
Bevel lock bolt
4
Base
5
Table lock handle
6
Rack ring
7
LED light
8
Quill return coil/spring
9
ON/OFF LED light switch
10
Depth stop nuts
11
Pulley cover
12
Belt tension lock knob
13
Motor
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: Never modify the product or any part of it.
Damage or personal injury couldresult.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this
product, call CRAFTSMAN toll free at: 1-888-331-4569.
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
14
Head locking set screws
15
Table crank handle
16
Table bracket
17
Rack
18
Mounting holes
19
Column
20
Table
21
Chuck
22
ON/OFF switch with
safety key
23
Chuck key holder
24
Spindle pulley
25
Motor pulley
24
11
25
Front
Rear
Fig. A
1
10
9
2
3
4
5
6
7
8
11
12
13
14
15
18
19
20
21
22
23
17
16
