Side 1/46
1/4 in. Angle Die Grinder
Amoladora de troqueles en ángulo de 1/4 pulg.
Meuleuse angulaire à rectifier les matrices de
1/4 po
CMXPTSG1006NB
INSTRUCTION MANUAL | GUIDE D’UTILISATION | MANUAL DE INSTRUCCIONES
IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US.
POUR TOUTE QUESTION OU TOUT COMMENTAIRE, NOUS CONTACTER.
SI TIENE DUDAS O COMENTARIOS, CONTÁCTENOS.
1-888-331-4569 WWW.CRAFTSMAN.COM
1
ENGLISH
Components
1
1/4 In. Angle Die Grinder
2
Collet Jacket
3
Spindle
4
Trigger
5
Safety Lever
6
Spindle Lock
7
Collet
8
Air Inlet
9
Wrench
Fig. A
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to
hazardous situations and your risk of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in property damage.
(Used without word) Indicates a safety related message.
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
WARNING: Never modify the product or any
part of it. Damage or personal injury could result.
WARNING: To reduce the risk of injury, read the
instruction manual.
If you have any questions or comments about
this or any product, call CRAFTSMAN toll free
at: 1-888-331-4569.
1
3
6
2
5
7
4
8
9
Specifications
Model CMXPTSG1006NB
Collet 1/4" (6.35 mm)
Free Speed 21,000 rpm
Average Air Consumption 4.5 scfm
Air Inlet 1/4" npt
Air Hose 3/8" (9.53 mm)
Working Pressure 90 psi
1/4 in. Angle Die Grinder
2
ENGLISH
WARNING: Failure to observe and follow safety instructions could result in injury or death.
WARNING: Improper operation or maintenance of this tool could result in serious injury
and property damage. Read and understand all warnings and operation instructions before
using this tool. When using any tool, basic safety precautions should always be followed to
reduce the risk of personal injury. Anticipate and be alert for sudden changes in motion
during startup and operation of any power tool. Do not operate tool if trigger does not turn
the tool on or off. Do not use this tool at heights exceeding 6 feet (2m). Use each tool for its
intended function only. Do not use this product in unsafe work conditions. It is always
recommended to keep a fire extinguisher and first aid kit near work areas.
WARNING: User must also read the compressor manual and follow all compressor safety
instructions.
CMXPTSG1006NB
Compressor requirements
IMPORTANT: To operate correctly, this tool requires airflow that is at least 4.5 cubic feet per
minute (SCFM) at 90 pounds per square inch (PSI). Check the specifications of your air
compressor to be sure that it can support both the minimum SCFM and PSI required. The air
hose length could affect how much air pressure the tool is actually receiving. You may need to
adjust the air pressure higher on the air regulator to achieve the working pressure of 90 PSI.
™
4.5 SCFM @ 90 PSI
Tool Requirements
Exigences relatives aux outils
Requisitos de herramientas
Produkspesifikasjoner
