QUICK START GUIDE
Under-monitor Soundbar With
Bluetooth
®
And USB Digital Audio


creative.com/register

creative.com/support
MULTI-LANGUAGE QUICK START GUIDE DOWNLOAD
creative.com/support/StageSE
[DE] MEHRSPRACHIGE SCHNELLSTARTANLEITUNG HERUNTERLADEN
[FR] TÉLÉCHARGEMENT DU GUIDE DE DÉMARRAGE RAPIDE MULTI-LANGUES
[IT] DOWNLOAD DELLA GUIDA DI AVVIO RAPIDO MULTILINGUA
[ES] DESCARGA DE LA GUÍA DE INICIO RÁPIDO EN MÚLTIPLES IDIOMAS
[NL] MEERTALIGE SNELSTARTGIDS DOWNLOAD
[NO] NEDLASTING AV HURTIGSTARTVEILEDNING FOR FLERE SPRÅK
[FI] MONIKIELINEN PIKA-ALOITUSOPPAAN LATAUS
[SV] FLERSPRÅKIG SNABBSTARTSGUIDE LADDA NER
[DA] DOWNLOAD AF HURTIG STARTVEJLEDNING PÅ FLERE SPROG
[CZ] STÁHNOUT VÍCEJAZYKOVÝ RYCHLÝ NÁVOD K POUŽITÍ
[PL] POBIERZ PRZEWODNIK SZYBKIEGO STARTU W WIELU JĘZYKU
[SK] STIAHNUŤ SI RÝCHLY NÁVOD NA ŠTARTOVANIE VIAC JAZYKOV
[RU] МНОГОЯЗЫЧНОЕ КРАТКОЕ РУКОВОДСТВО ЗАГРУЗИТЬ
[JP] 󲡕󸌫󸑤
[CS] 󱘕󸱠󲡕󸛓󸌫󳗐󸷀󱡋󵫞󳬘󱻣
[CT] 󱘕󸮛󲡕󸑤󸌫󳗐󸷀󱡋󵫞󳬘󱻣
[KO] 󻁓󺫜󼌣󾖴󻯏󻛧󾖴󼁋󼔀󾖴󺥯󼓣󻉋󾖴󻁓󼐣󻗋󻉋
OVERVIEW CONTROLS
Volume Control Knob
LED Indicator
Multifunction Button (Power, Source Selection,
Bluetooth
®
)
DC-in Power Port
USB-A Port (For Firmware Updates Only)
USB-C Port (For USB Audio Playback)
Note: Upon powering on, Creative Stage SE will automatically initiate Bluetooth
pairing when source input is switched from USB Audio to Bluetooth.
1
2
3
4
5
6
x1
2s
x1
x2
Button
LED Indicator
FunctionAction
Soundbar State
Blinking Blue
Bluetooth
Pairing Mode
Blinking LED
(Source Color)
Volume Adjustment
Solid Red
Standby
Solid Blue
Bluetooth
Paired
Solid Purple
USB Audio
1
4
5
6
2 3
ON
OFF
USB
AUDIO
VOICE PROMPT
ON
VOICE PROMPT
OFF
IR REMOTE CONTROL INTERCHANGEABLE AC PLUGS
CONNECTIVITY
TECHNICAL SPECIFICATIONS
Power Output: 12W RMS x 2
Total System Peak Power: 48W
Frequency Range: 55–20,000 Hz
SNR: ≥ 80 dB
Operating Frequency: 2402–2480 MHz
Operating Range: Up to 10m / 33 ft, measured in open space. Walls and structures may
aect range of device
Maximum RF Output Power: 7 dBm
Bluetooth
Version:
Bluetooth
5.3
Supported
Bluetooth
Proles: A2DP (Advanced Audio Distribution Prole), AVRCP (Audio
/ Video Remote Control Prole)
Supported Codec: SBC
Soundbar Input Rating: 15V
2.0A
Max Operating Temperature: 40°C
Power Adapter Model: GJ30WD-1500200DP
Input: 100–240V~, 50/60 Hz 0.8A
Output: 15V
2.0A, 30.0W
Note: Compliance marking are located at the bottom of this product
Power Button
Press once to turn on the soundbar.
Press once again to turn it o.
Input Selection Button
Press once to switch between USB Audio mode and
Bluetooth mode.
Press and hold for 2s to initiate Bluetooth pairing mode.
Mute Button
Press once to mute the soundbar.
Press once again to unmute.
Volume + Button
Press once to increase volume.
Volume - Button
Press once to decrease volume.
Play / Pause Button
Press once to play / pause audio playback.
Previous Track Button
Press once to return to previous track.
Next Track Button
Press once to skip to next track.
Tone - Button
Press to increase audio warmth; this will increase the
prominence of bass reproduction and vocals.
Tone + Button
Press to increase audio brilliance; this will increase the
prominence of high and upper mid frequencies, making
the audio crisper.
Surround Button
Press once to activate Surround mode; this mode will
deliver expanded soundstage and spatialized audio for
a more immersive experience.
Press once again to turn it o.
Dialog Button
Press once to activate Dialog Plus mode; this mode
provides improved vocal intelligibility in spoken dialogs,
allowing you to hear each syllable clearer.
Press once again to turn it o.
Reset Button
Press once to revert all changes made, including Tone,
Surround, and Dialog settings.
a
i
c
k
b
j
d
l
f
e
m
g
h
a
g
m
i
k
b
f
e
h
j
l
d
c
MASTER RESET
Press and hold the power button on the provided IR remote control for 8s to perform
a Master Reset. Upon completion, a voice prompt will trigger with the prompt “Reset
To Factory Default” and the soundbar will revert to its default state. Master Reset is
reserved for cases where users encounter issues while the soundbar is in use or during
situations such as:
Bluetooth
Pairing failure, random LED blinks, or to reset all data.
8s
Tablets / Mobile Devices
PC / Mac
Bluetooth mode
Wall socket
Back View
PC / Mac PS5™ PS4™
Nintendo Switch
(Docked Mode)
Nintendo Switch™
(Handheld Mode)
Creative Stage SE includes a power adapter with interchangeable AC plugs, suitable for
use in multiple regions. Refer to the instructions below for more information.
Note: Interchangeable AC plug(s) are bundled based on the requirements in their
respective countries and are suitable for use in regions using the same AC plugs.
Replacing Interchangeable AC Plugs
China USA / Canada /
Japan / Taiwan
Australia
Singapore / UK / Hong Kong /
Saudi Arabia / UAE / Malaysia
Korea
(Plug with 4.8mm pin
diameter)
EU / Singapore
(Plug with 4mm pin
diameter)
i) Place the AC plug on the power adapter,
then push it down and turn clockwise
direction to lock it
ii) Press and turn the AC plug anti-clockwise
to remove from the power adapter
3
4
1
2
