Side 1/5

KNOCKDOWNWAGONBASE

BEGINNINGSERIAL NO.10123781

KD-4.0-E

4/1/2012

DOC:KD400010

PARTSDESCRIPTION

ASSEMBLY HARDWARE

7630

1/4-20x1/2 HEXBOLT (2)

12994

3/8-16x8-1/2CARRIAGEBOLT (2)

12343

1/4-20SPECIAL NUT (18)

10134

1/2"FLAT WASHER(6)

1766

3/8”SPACER(2)

12372

7/16BOXWRENCH-S.S.(1)

12341

1/4-20x2REDCARRIAGEBOLT (8)

12340

1/4-20x3/4REDCARRIAGEBOLT (8)

7622

3/8”WASHER(6)

12350

PLUG(2)

2437

DUMP LEVERKNOB(2)

2455-KD1WAGONSIDE

2455-KD2WAGONFRONT

2455-KD3WAGONBACK

2455-KD4WAGONBOTTOM

2455-KD5WAGONCROSSBAR

12894 WAGON AXLESUPPORT TUBE

16787 AXLEROD-ONLY SMALL

2604 ANTIQUEWAGONWHEEL-YELLOW

2606 DECAL-GR/T-2000-ANTIQUEWAGON

12338 WAGONLEG- YELLOW-KNOCKDOWN

12938 WAGONSHELF-GOLDRUSH

2555-2 WAGONMOUNTINGBRACKET

7644 #10x¾SHEETMETAL SCREW

HARDWARE TOMOUNT POPPER

12818

CLIP-RETAINING(2)

7644

#10xPHILLIPSPANHD-TY-A (2)3/4

2555-2

WAGONMOUNTINGBRACKET(2)

C.CRETORS ANDCOMPANY

176MITTEL DRIVE

WOODDALE,IL 60191

PHONE:(773)588-1690,(800)228-1885,FAX:(847)616-6970

WEBSITE:http://www.cretors.comEmail:postmaster@cretors.com

16786

SPACER(2)

KNOCKDOWNWAGONBASE

BEGINNINGSERIAL NO.10123781

DOC:KD400008

Detail1

Slidehemover

standingedge

2455-KD2

WAGONFRONT

2455-KD1

WAGONSIDE

2455-KD3

WAGONBACK

ASSEMBLY STEP 1

DONOTTIGHTENHARDWAREUNTIL STEP 14

1- 1 2 3

Withpiece lyingfacedownslidethehemmededgesofpieces and ontoedge

ofpiece ,ensuringsnugfit.( )

# # #

SeeDetail1&2

Detail2

Slidehemover

standingedge

1, 2and 3

# #

Hem

2455-KD4

WAGONBOTTOM

Detail3

Slideedge

intohem

ASSEMBLY STEP 2

DONOTTIGHTENHARDWAREUNTIL STEP 14

2- 4 1, 2 3Carefullyslidepiece downunderthehemmededgesofassembledpieces & .( )

# # # #

SeeDetail1

KD-4.0-D

12/2010

KNOCKDOWNWAGONBASE

BEGINNINGSERIAL NO.10123781

DOC:KD400008

12340

7622

12343

12340

12343

7622

ASSEMBLY STEP 3

DONOTTIGHTENHARDWAREUNTIL STEP 14

3- 2 3 1 2 4Usinghardwareandwrenchshownonpageonefastensidepieces & topiece andpieces to aligningall

holesandfasten.MakingsureCarriageBoltsfitsnuglyintosquareholesonbase.

ThiscompletestheBaseportionof TheWagon.

# # # # #

(SeeDetail1)

12343

12341

12338

12350

ASSEMBLY STEPS4through6

DONOTTIGHTENHARDWAREUNTIL STEP 14

5- 1, 4

TurnWagonBaseontoside.

PlaceWagonLegsinsidebottomofWagonBasealigningWagonLegswithholeopeningson and ,

fastenlegstoWagonBase

pieces

usingSpecialWrenchprovidedora7/16wrench.

PushPlugsintoopenendsoftheWagonLegs.

# # #

2455-KD4

12350

Detail1

FitCarriageBolt

completelyInsquare

openings

12340

KD-4.0-D

12/2010
