Side 1/12

PU-1106-KIT

v1.3 HDMI over CAT6 Extender

Set with IR Pass-through

OPERATION MANUAL

Table of Contents

1. Introduction ……………………..……………………...…........….…….

2. Applications …………………..………………….……...................…..

3. Package Contents ………………………...........……….................…

4. System Requirements ……………..……….........………............…….

5. Features …………………………………………......……........…...……

6. Speciﬁ cations ………………………………...……..........………....….

7. Operation Controls and Functions ……………...……..............……

7.1 Front Panel ..............................................................................

7.2 Rear Panel .…………………………………..…….......…...….…

8. Pin Assignment .............................……………..........…......…....…...

8.1 IR Cable Pin Assignment .......................................................

8.2 RJ-45 Pin Deﬁ nitions ................................................................

10. Connection and Installation ….………………….........…..…..…......

11. Acronyms …......................................................................................

1. Introduction

The HDMI 1.3 transmitter and receiver over CAT6 is the ideal device to send

your HDMI signals over long distances. Instead of using expensive HDMI

cables, your existing CAT6 cables/sockets can replace HDMI cables while

performing the same functions like transferring Deep Color (12 bits/color)

video and lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-

HD Master Audio) digital audio. Moreover, you can use the existing remote

to control the source and connect it to another transmitter and receiver to

extend your HDMI signal to distances you never thought possible. This HDMI

1.3 Transmitter and receiver is your only choice when looking for an HDMI

extender.

2. Applications



Showroom display/control



Home entertainment systems



Commercial displays



Lecture room display/control

3. Package Contents



HDMI 1.3 Transmitter x 1



HDMI 1.3 Receiver x 1



IR Receiver x 1



IR Blaster x 1



5V DC power supply adaptor x 2



Operation Manual x 1

4. System Requirements

HDMI input source equipment, output HDMI displayer, two CAT6 cables and

source equipment

’

s remote control.

Produkspesifikasjoner

Merke:	CYP
Kategori:	AV ekstender
Modell:	PU-1106-KIT
Vekt:	480 g
Farge:	Ja
Maksimal oppløsning:	- piksler
Pakkevekt:	860 g
HDCP:	Ja
3D:	Ja
HDMI-versjon:	1.3
Fargedybde:	12 bit
HDMI inn:	1
Antall HDMI-utganger:	1
AC-inngangsspenning:	5 V
Mottakervekt:	140 g
Produktfarge:	Sort
Støttede grafikkoppløsninger:	640 x 480 (VGA), 1280 x 800 (WXGA)
Pakketype:	Boks
Støttede videofunksjoner:	480i, 1080p
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	2
DC-inngangskontakt:	Ja
Lydsystem:	Stereo
Ethernet/bredbåndsforbindelse:	Ja
DVI inngangs-porter:	1
DVI utgangs-porter:	1
Innput-strøm:	1.2 A
Maksimal overføring avstand:	40 m
Kabeltyper som støttes:	Cat5e, Cat6
Trådløs mottaker (B x D x H):	77 x 73 x 30 mm
Senderdimensjoner (BxDxH):	80 x 100 x 30 mm
Sendervekt:	340 g
RJ-45-utgangsporter:	2
3,5 mm inn:	Ja
Consumer Electronics Control (CEC)-støtte:	Ja
3.5 mm ut:	Ja
