SY-398H

CV & SV to HDMI Converter with

Audio Input

OPERATION MANUAL

Safety Precautions

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:



Always follow basic safety precautions to reduce the risk of

ﬁ re, electrical shock and injury to persons.



To prevent ﬁ re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.



Never spill liquid of any kind on or into this product.



Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.



Do not attach the power supply cabling to building surfaces.



Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.



To protect the equipment from overheating, do not block the

slots and openings in the module housing that provide ventilation.

Revision History

Version No Date Summary of Change

VR0 20101201 Preliminary Release

Table of Contents

1. Introduction .........................................................................................

2. Applications ........................................................................................

3. Package Contents ..............................................................................

4. System Requirements .........................................................................

5. Features ...............................................................................................

6. Specifications .....................................................................................

6.1 Audio Specification .............................................................

7. Operation Controls and Functions ....................................................

7.1 Left side Panel ......................................................................

7.2 Right side Panel ...................................................................

7.3 Front Panel ...........................................................................

7.4 Top Panel ..............................................................................

8. OSD ......................................................................................................

9. Connection and Installation ..............................................................

10. Acronyms ............................................................................................

Produkspesifikasjoner

Merke:	CYP
Kategori:	lyd / video konverterer
Modell:	SY-398H
Vekt:	200 g
Bredde:	105 mm
Dybde:	65 mm
Høyde:	25 mm
Bruksanvisning:	Ja
Pakkevekt:	280 g
Sertifisering:	CE/FCC/UL
Maksimal videooppløsning:	- piksler
On Screen Display (OSD):	Ja
Vertsgrensesnitt:	Composite + S-Video
Driftsspenning:	5 V
Utgangsgrensesnitt:	HDMI
Produktfarge:	Sort
Analogt signalformatsystem:	NTSC 3.58, PAL, SECAM
Strømforbruk (vanlig bruk):	2.5 W
Støttede videofunksjoner:	480p, 576p, 720p, 1080i, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Kroppsmateriale:	Plast
Video ut:	1
Ekstern strømadapter:	Ja
Støttede oppløsninger:	XGA, SXGA, UXGA
Relativ luftfuktighet under drift (H-H):	20 - 90
Videoopptaksgrensesnitt:	2
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Antall:	1
Driftsstrøm:	1 A
