HCC 260 P1 - HCC 360 P2 - HCC 360 E1
SERVICE MANUAL
en • Rev. 1.0 • 2020-45-3
3
Introduction: Table of contents
en
Introduction
Table of contents
This service manual covers the following main topics:
Table of contents
Introduction .....................................................................3
Table of contents ......................................................................3
Overview .............................................................................4
Declaration of conformity .............................................................5
Product description ..............................................................6
Overall description ....................................................................6
Components description ..............................................................9
Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
System operation strategy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation .................................................................... 12
General location requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting additional equipment ....................................................21
Initial calibration .....................................................................24
Operation (user) ................................................................ 26
Overall ventilation functions .........................................................26
User Rights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Maintenance and care .......................................................... 28
Preventative maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Trouble shooting .....................................................................31
Appendix ...................................................................... 38
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Schematics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Week program specication ..........................................................41
Spare parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4
Introduction: Overview
Overview
This is the service manual for the Dantherm HCC 260/360 residential ventilation unit.
Part number of this service manual is 108478 and covers units with serial numbers from:
HCC260 P1-A-BP - 2010121652545
HCC360 E1-A-BP-RH - 2010131652548
HCC360 P2-A-BP-RH - 2010131652549
This manual is for both installers and users of the product.
Installation and repair of the unit is to be carried out by qualied personnel only. It is the
responsibility of the installer to read and understand this service manual prior to initial start
and setup of the HCC 260/360 unit. Warranty is restricted to units, installed by trained person-
nel only.
This application is not intended for use by persons (including children) with reduced physi-
cal, sensory or mental capabilities, unless they have been given supervision or instructions
concerning the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Apart from the replacement of air lters and exterior cleaning of the system, any kind of
maintenance will require the use of trained personnel.
The unit MUST be earthed, through cables WITH earth wire and earthed power supply.
Copying of this service manual, or part of it, is forbidden without prior written permission
from Dantherm
Dantherm reserves the right to make changes and improvements to the product and the
service manual at any time without prior notice or obligation.
This units is designed for long term durability. When total lifetime ends, the unit should be
recycled according to national rules and with high environmental protection considerations
This manual uses following abbreviations for ventilation terminologies.
Abbr. Description
T1 Outside air coming into the unit
T2 Supply air from the unit to the home
T3 Extract air from the home to the unit
T4 Exhaust air from the unit
S1 Temperature sensor no 1
S2 Temperature sensor no 2
S3 Temperature sensor no 3
S4 Temperature sensor no 4
Mode A Indicating operation mode A. See more at page 15
Mode B Indicating operation mode B.(reverse fan) See more at page 15
G4 Standard air lter class (ISO Coarse)
F7 Filter class (ePM1), better and absorbs ner grains than G4 lter
BP Bypass damper
IP Unique address for the Ethernet port.
DHCP Automatic settings of an Ethernet address provided from an external network
component ( if connecting the unit to Ethernet)
PC Personel computer running MS Windows
USB Universal serial bus connection– located on almost any computer
LAN Local area network is the internal network with or without wireless access
VOC Volatile organic compounds sensor, controls the ventilation level depending on
the pollution of the air.
PC Tool Windows software application specic for this unit.
Manual
Target group
Warning
Caution
WARNING
Warning
Caution
WARNING
Copyright
Reservations
Recycling
Abbreviations in
this manual
