Side 1/12

DAC-8P

SDI TO HDMI CONVERTER

Instruction Manual

w w w . d a t a v i d e o . c o m

Table of Contents

FCC COMPLIANCE STATEMENT ................................................ 3

WARNINGS AND PRECAUTIONS .............................................. 3

WARRANTY ............................................................................. 5

S W TANDARD ARRANTY ................................................................. 5

T YHREE EAR WARRANTY 5...............................................................

DISPOSAL 6................................................................................

FRONT PANEL .......................................................................... 7

REAR PANEL ............................................................................ 8

SPECIFICATIONS .................................................................... 10

SERVICE & SUPPORT .............................................................. 12

Disclaimer of Product & Services

The information offered in this instruction manual is intended as a guide only. At all times, Datavideo

Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies

cannot exclude that some information in this manual, from time to time, may not be correct or may be

incomplete. This manual may contain typing errors, omissions or incorrect information. Datavideo

Technologies always recommend that you double check the information in this document for accuracy

before making any purchase decision or using the product. Datavideo Technologies is not responsible for

any omissions or errors, or for any subsequent loss or damage caused by using the information contained

within this manual. Further advice on the content of this manual or on the product can be obtained by

contacting your local Datavideo Office or dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference

that may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or

aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may

fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are provided for

ventilation. To ensure safe and reliable operation of this unit, and to

protect it from overheating, do not block or cover these openings. Do not

place this unit on a bed, sofa, rug, or similar surface, as the ventilation

openings on the bottom of the cabinet will be blocked. This unit should

never be placed near or over a heat register or radiator. This unit should

not be placed in a built in installation unless proper ventilation is -

provided.

7. This product should only be operated from the type of power source

indicated on the marking label of the AC adapter. If you are not sure of the

type of power available, consult your Datavideo dealer or your local power

company.

8. Do not allow anything to rest on the power cord. Do not locate this unit

where the power cord will be walked on, rolled over, or otherwise

stressed.

9. If an extension cord must be used with this unit, make sure that the total

of the ampere ratings on the products plugged into the extension cord do

not exceed the extension cord rating.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	lyd / video konverterer
Modell:	DAC-8P
Vekt:	500 g
Bredde:	105 mm
Dybde:	120 mm
Høyde:	38 mm
Sertifisering:	CE, FCC
Maksimal videooppløsning:	1920 x 1080 piksler
Vertsgrensesnitt:	SDI
Driftsspenning:	12 V
Utgangsgrensesnitt:	HDMI
Produktfarge:	Black, Grey
Analogt signalformatsystem:	NTSC, PAL
Strømforbruk (vanlig bruk):	4 W
Støttede videofunksjoner:	480i, 576i, 720p, 1080i, 1080p
Driftstemperatur (T-T):	0 - 40 °C
Video ut:	1x HDMI
Relativ luftfuktighet under drift (H-H):	10 - 90
Videoopptaksgrensesnitt:	1x 3G/HD/SD-SDI
AC-adapter bunt:	Ja
Antall:	1
Driftsstrøm:	0.5 A
