Side 1/52

PTC-150T/

PTC-150TW

www.datavideo.com

Instruction Manual

HD/SD-SDI HDBaseT

PTZ CAMER

Table of Contents

FCC COMPLIANCE STATEMENT ...................................................................... 4

WARNINGS AND PRECAUTIONS .................................................................... 4

WARRANTY ................................................................................................... 6

STANDARD WARRANTY ........................................................................................ 6

THREE YEAR WARRANTY ...................................................................................... 6

DISPOSAL ...................................................................................................... 7

1. PRODUCT OVERVIEW ................................................................................ 8

2. FEATURES .................................................................................................. 8

3. LOCATION AND FUNCTION OF PARTS ........................................................ 9

4. CONNECTIONS ......................................................................................... 12

4.1 CAMERA REAR CONTROL PANEL ............................................................. 12

4.2 RECEIVER BOX FRONT PANEL ................................................................. 12

4.3 RECEIVER BOX REAR PANEL ................................................................... 13

5. SYSTEM DIAGRAM ................................................................................... 15

6. REMOTE CONTROL AND ON-SCREEN MENU ............................................ 16

6.1 REMOTE CONTROL FUNCTIONS ............................................................... 16

6.2 ON-SCREEN MENU .............................................................................. 20

7. INSTALLATION INSTRUCTIONS ................................................................. 30

STEP 1 – DIP SWITCH SETTING ............................................................................ 30

STEP 2 – ONE END OF MOUNTING WIRE ............................................................... 30

STEP 3 – CEILING BRACKET (B) ............................................................................ 30

STEP 4 – CEILING BRACKET (A) AND CAMERA ......................................................... 31

STEP 5 – MOUNT CAMERA TO CEILING ................................................................. 33

STEP 6 – SCREW TO SECURE CAMERA ................................................................... 34

STEP 7 – CABLE CONNECTION ............................................................................. 34

8. DIP SWITCH SETTINGS ............................................................................. 35

8.1 DIP SWITCH SW1 ............................................................................... 35

8.2 DIP SWITCH SW2 (IRID) ...................................................................... 36

9. NETWORK CONFIGURATION .................................................................... 37

10. RMC-180 PTZ CAMERA CONTROL UNIT .................................................. 42

10.1 DIRECT CONNECTION TO CAMERA ........................................................... 42

10.2 CONNECTION TO CAMERA VIA RECEIVER BOX ............................................ 42

11. FIRMWARE UPDATE .............................................................................. 44

12. FREQUENTLY-ASKED QUESTIONS ........................................................... 45

13. DIMENSIONS ......................................................................................... 47

14. SPECIFICATIONS ..................................................................................... 49

CABLE SELECTION .............................................................................................. 51

15. SERVICE AND SUPPORT ......................................................................... 52

Disclaimer of Product and Services

The information offered in this instruction manual is intended as a guide only.

At all times, Datavideo Technologies will try to give correct, complete and

suitable information. However, Datavideo Technologies cannot exclude that

some information in this manual, from time to time, may not be correct or

may be incomplete. This manual may contain typing errors, omissions or

incorrect information. Datavideo Technologies always recommend that you

double check the information in this document for accuracy before making

any purchase decision or using the product. Datavideo Technologies is not

responsible for any omissions or errors, or for any subsequent loss or damage

caused by using the information contained within this manual. Further advice

on the content of this manual or on the product can be obtained by contacting

your local Datavideo Office or dealer.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	Videokamera
Modell:	PTC-150TL
Vekt:	2700 g
Bredde:	189 mm
Dybde:	173 mm
Høyde:	219 mm
Strømkildetype:	DC
Maksimal bildefrekvens:	60 fps
Antall HDMI-porter:	1
Optisk zoom:	30 x
Maksimal videooppløsning:	1920 x 1080 piksler
Hvitbalanse:	Auto, Fluorescent, Indoor, MWB, One push, Outdoor
HDMI-versjon:	1.3
PTZ-kontroll:	Ja
Synsfelt:	63.7 °
Sensortype:	CMOS
Produktfarge:	Blå
HD-type:	Full HD
Vippevinkelområde:	-20 - 90 °
Brennviddeområde:	4.3 - 129 mm
Strømforbruk (vanlig bruk):	29 W
Støttede videofunksjoner:	480i, 720p, 1080i, 1080p
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
CCD-sensorstørrelse:	1/2.8 "
Signal-til-støy-forhold (SNR):	50 dB
Megapiksel:	2.14 MP
Justering av fokus:	Automatisk/Manuell
Panoreringsomfang:	0 - 270 °
Minimumsbelysning:	0.03 lx
Blenderåpning rekkevidde:	1.6 - 4.7
BNC-utgangsporter:	2
Vinningskontrolltype (gain):	Manuell
DC inngående spenning:	12 V
RS-422-port:	1
Antall kameraforhåndsinnstillinger:	50
Raskeste lukkerhastighet:	1/1500 s
Panoreringshastighet (min):	1 °/sek
Panoreringshastighet (maks):	150 °/sek
Lutningshastighet (min):	1 °/sek
Lutningshastighet (maks):	150 °/sek
