TLM-102

DUAL 10” MONITOR

www.datavideo.com

TLM-102 DUAL 10” MONITOR

POWER INPUT F1 F2 EXIT

Instruction Manual

Table of Contents

FCC COMPLIANCE STATEMENT .................................................................. 3

WARNINGS AND PRECAUTIONS ................................................................ 3

WARRANTY ............................................................................................... 4

STANDARD WARRANTY ................................................................................... 4

THREE YEAR WARRANTY ................................................................................. 5

DISPOSAL .................................................................................................. 5

1. INTRODUCTION ................................................................................. 6

FEATURES ..................................................................................................... 6

TLM-102 MODEL TYPE ................................................................................. 7

COMPATIBLE RESOLUTIONS AND FORMATS .......................................................... 8

2. CONNECTIONS AND CONTROLS......................................................... 9

FRONT PANEL ................................................................................................ 9

REAR PANEL ................................................................................................ 11

3. SOFTWARE FUNCTION .................................................................... 12

4. BUILT-IN SDI-HDMI CROSS-CONVERSION ......................................... 13

5. OSD MENU ...................................................................................... 15

6. INSTALL THE TLM-102 ...................................................................... 17

7. DIMENSIONS ................................................................................... 20

8. SPECIFICATIONS .............................................................................. 21

9. ACCESSORIES................................................................................... 22

10. SERVICE AND SUPPORT ............................................................... 24

Disclaimer of Product and Services

The information offered in this instruction manual is intended as a guide only. At all times,

Datavideo Technologies will try to give correct, complete and suitable information. However,

Datavideo Technologies cannot exclude that some information in this manual, from time to

time, may not be correct or may be incomplete. This manual may contain typing errors,

omissions or incorrect information. Datavideo Technologies always recommend that you

double check the information in this document for accuracy before making any purchase

decision or using the product. Datavideo Technologies is not responsible for any omissions or

errors, or for any subsequent loss or damage caused by using the information contained

within this manual. Further advice on the content of this manual or on the product can be

obtained by contacting your local Datavideo Office or dealer.

FCC Compliance Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that

may cause undesired operation.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or

aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit may fall,

causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are provided for

ventilation. To ensure safe and reliable operation of this unit, and to protect it

from overheating, do not block or cover these openings. Do not place this unit

on a bed, sofa, rug, or similar surface, as the ventilation openings on the

bottom of the cabinet will be blocked. This unit should never be placed near or

over a heat register or radiator. This unit should not be placed in a built-in

installation unless proper ventilation is provided.

7. This product should only be operated from the type of power source indicated

on the marking label of the AC adapter. If you are not sure of the type of

power available, consult your Datavideo dealer or your local power company.

8. Do not allow anything to rest on the power cord. Do not locate this unit where

the power cord will be walked on, rolled over, or otherwise stressed.

9. If an extension cord must be used with this unit, make sure that the total of

the ampere ratings on the products plugged into the extension cord do not

exceed the extension cord rating.

10. Make sure that the total amperes of all the units that are plugged into a single

wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet ventilation

slots, as they may touch dangerous voltage points or short out parts that could

result in risk of fire or electric shock. Never spill liquid of any kind onto or into

this unit.

12. Except as specifically explained elsewhere in this manual, do not attempt to

service this product yourself. Opening or removing covers that are marked “Do

Not Remove” may expose you to dangerous voltage points or other risks, and

will void your warranty. Refer all service issues to qualified service personnel.

Produkspesifikasjoner

Merke:	DataVideo
Kategori:	Høyttaler
Modell:	TLM-102
Strømkilde:	DC
Synsvinkel, horisontal:	170 °
Antall HDMI-porter:	4
Inngangsspenning:	12 V
Kontrastforhold:	800:1
Skjermoppløsning:	1280 x 800 piksler
Produktfarge:	Sort
Skjermdiagonal:	10.1 "
Strømforbruk (vanlig bruk):	28 W
Modell/Type:	Rackskjerm
Synsvinkel, vertikal:	170 °
Rack-kapasitet:	4U
Lysstyrke for skjerm:	300 cd/m²
