Side 1/8
Dell
Dell
Dell
DellDell™
™
™
™™ 7700FullHD
7700FullHD
7700FullHD
7700FullHD 7700FullHD SNMP
SNMP
SNMP
SNMP SNMP Protocol
Protocol
Protocol
Protocol Protocol Document
Document
Document
DocumentDocument
Control Commands List
Control Commands List
Control Commands List
Control Commands List Control Commands List
Name Feature Oid Value
Type
Read /Write Criteria
RFC1213-system sysDescr .1.3.6.1.2.1.1.1.0 String R Dell 7700FullHD
RFC1213-system sysObjectID .1.3.6.1.2.1.1.2.0 OID R .1.3.6.1.4.1.674.10901.200.12
RFC1213-system sysUpTime .1.3.6.1.2.1.1.3.0
Timetic
ks
R * hours * minutes * seconds
RFC1213-system sysContact .1.3.6.1.2.1.1.4.0 String R/W
RFC1213-system sysName .1.3.6.1.2.1.1.5.0 String R/W
RFC1213-system sysLocation .1.3.6.1.2.1.1.6.0 String R/W
RFC1213-system sysServices .1.3.6.1.2.1.1.7.0 Integer R DEFVAL { 72 }
RFC1213-interfac
es
ifNumber .1.3.6.1.2.1.2.1.0 Integer R DEFVAL { 1 }
pdmGeneral
pdmGeneralProdu
ctName
.1.3.6.1.4.1.2699.2.4.1.2.1.0 String R Dell 7700FullHD
pdmGeneral
pdmGeneralSerial
Number
.1.3.6.1.4.1.2699.2.4.1.2.2.0 String R
Check PPID number (the latter
7 yards)
pdmGeneral
pdmGereralAssetT
ag
.1.3.6.1.4.1.2699.2.4.1.2.3.0 String R/W Range (0~63 byte)
pdmGeneral
pdmGereralHardw
areVersion
.1.3.6.1.4.1.2699.2.4.1.2.4.0 String R DEFVAL { " " }
pdmGeneral
pdmGereralServic
ePerson
.1.3.6.1.4.1.2699.2.4.1.2.5.0 String R/W Range (0~255 byte)
pdmGeneral
pdmGeneralDevic
eAge
.1.3.6.1.4.1.2699.2.4.1.2.6.0 Integer R Check display hours
pdmGeneral
pdmGeneralPower
OnCount
.1.3.6.1.4.1.2699.2.4.1.2.7.0 Integer R
pdmGeneral
pdmGereralManuf
actureDate
.1.3.6.1.4.1.2699.2.4.1.2.8.0 String R
pdmGeneral
pdmGereralLangu
ageTagSNMP
.1.3.6.1.4.1.2699.2.4.1.2.9.0 String R en-US
pdmGeneral
pdmGeneralNtpSe
rverAddress
.1.3.6.1.4.1.2699.2.4.1.2.10.0 String R DEFVAL { "" }
PdmCtlr pdmCtlrIndex .1.3.6.1.4.1.2699.2.4.1.3.1.1.1.1 Integer not-accessible 1
PdmCtlr
pdmCtlrDescripti
on
.1.3.6.1.4.1.2699.2.4.1.3.1.1.2.1 String R TI DDP3021
PdmCtlr
pdmCtlrHardware
Version
.1.3.6.1.4.1.2699.2.4.1.3.1.1.3.1 String R DEFVAL { "" }
PdmCtlr
pdmCtlrFirmware
Version
.1.3.6.1.4.1.2699.2.4.1.3.1.1.4.1 String R
PdmCtlr
pdmCtlrFirmware
Upgradeable
.1.3.6.1.4.1.2699.2.4.1.3.1.1.5.1 Integer R DEFVAL { 10 }
PdmCtlr
pdmCtlrUpgradeI
nstructions
.1.3.6.1.4.1.2699.2.4.1.3.1.1.6.1 String R DEFVAL { " " }
PdmCtlr
pdmCtlrPostStatu
s
.1.3.6.1.4.1.2699.2.4.1.3.1.1.7.1 Integer R DEFVAL{ 2 }
PdmCtlr pdmCtlrPostCode .1.3.6.1.4.1.2699.2.4.1.3.1.1.8.1 String R DEFVAL { " " }
PdmCtlr
pdmCtlrPostStatu
sDefinitions
.1.3.6.1.4.1.2699.2.4.1.3.1.1.9.1 String R DEFVAL { " " }
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.1 Integer not-accessible 1
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.2 Integer not-accessible 2
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.3 Integer not-accessible 3
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.4 Integer not-accessible 4
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.5 Integer not-accessible 5
PdmPower pdmPowerIndex .1.3.6.1.4.1.2699.2.4.1.4.1.1.1.6 Integer not-accessible 6
PdmPower
pdmPowerImplem
entedState
.1.3.6.1.4.1.2699.2.4.1.4.1.1.2.1 Integer R 11
PdmPower
pdmPowerImplem
entedState
.1.3.6.1.4.1.2699.2.4.1.4.1.1.2.2 Integer R 7
PdmPower
pdmPowerImplem
entedState
.1.3.6.1.4.1.2699.2.4.1.4.1.1.2.3 Integer R 9
PdmPower
pdmPowerImplem
entedState
.1.3.6.1.4.1.2699.2.4.1.4.1.1.2.4 Integer R 8
PdmPower pdmPowerImplem .1.3.6.1.4.1.2699.2.4.1.4.1.1.2.5 Integer R 8
entedState
PdmPower
pdmPowerImplem
entedState
.1.3.6.1.4.1.2699.2.4.1.4.1.1.2.6 Integer R 10
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.1 String R Power On.-11
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.2 String R Power Off.-7
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.3 String R Projector is cooling down.-9
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.4 String R Low power mode.-8
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.5 String R Low power mode.-8
PdmPower
pdmPowerDescrip
tion
.1.3.6.1.4.1.2699.2.4.1.4.1.1.3.6 String R Warming up.-10
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.1 String R
Full power on, all components
active.
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.2 String R
Standby State.
Only network electronics remain
on.
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.3 String R Going down to standby mode.
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.4 String R
Lamp off
Fan on.
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.5 String R
Lamp off
Fan on.
PdmPower
pdmPowerMfrDes
cription
.1.3.6.1.4.1.2699.2.4.1.4.1.1.4.6 String R
Lamp warming up
Fan on.
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.1 Integer R 7
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.2 Integer R 11
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.3 Integer R 3
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.4 Integer R 7
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.5 Integer R 11
PdmPower
pdmPowerTargetSt
ate
.1.3.6.1.4.1.2699.2.4.1.4.1.1.5.6 Integer R 3
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.1 Integer R 120
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.2 Integer R 30
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.3 Integer R 0
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.4 Integer R 120
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.5 Integer R 20
PdmPower
pdmPowerTransiti
onTime
.1.3.6.1.4.1.2699.2.4.1.4.1.1.6.6 Integer R 0
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.1 Integer R 3
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.2 Integer R 4
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.3 Integer R 4
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.4 Integer R 3
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.5 Integer R 3
PdmPower
pdmPowerComm
Available
.1.3.6.1.4.1.2699.2.4.1.4.1.1.7.6 Integer R 4
PdmPower
pdmPowerCurrent
State
.1.3.6.1.4.1.2699.2.4.1.4.2.0 Integer R
PdmPower
pdmPowerRequest
edState
.1.3.6.1.4.1.2699.2.4.1.4.3.0 Integer R/W
pdmDisplayCap
pdmDisplayCapRe
solutionH
.1.3.6.1.4.1.2699.2.4.1.5.1.0 Integer R 1600
pdmDisplayCap
pdmDisplayCapRe
solutionV
.1.3.6.1.4.1.2699.2.4.1.5.2.0 Integer R 1200
pdmDisplayCap
pdmDisplayCapPh
ysSizeH
.1.3.6.1.4.1.2699.2.4.1.5.3.0 String R DEFVAL { "" }
pdmDisplayCap pdmDisplayCapPh .1.3.6.1.4.1.2699.2.4.1.5.4.0 String R DEFVAL { "" }
ysSizeV
pdmDisplaySet
pdmDisplaySetInd
ex
.1.3.6.1.4.1.2699.2.4.1.6.1.1.1.1 Integer not-accessible 1
pdmDisplaySet
pdmDisplaySetAff
ectsAll
.1.3.6.1.4.1.2699.2.4.1.6.1.1.2.1 Integer R DEFVAL { 1 }
pdmDisplaySet
pdmDisplaySetInp
utSource
.1.3.6.1.4.1.2699.2.4.1.6.1.1.3.1 Integer
1. VGA_A
2. VGA_B
3. S-Video
4. Composite Video
5. HDMI
pdmDisplaySet
pdmDisplaySetBri
ghtness
.1.3.6.1.4.1.2699.2.4.1.6.1.1.4.1 Integer R/W
pdmDisplaySet
pdmDisplaySetBrt
Max
.1.3.6.1.4.1.2699.2.4.1.6.1.1.5.1 Integer R 100
pdmDisplaySet
pdmDisplaySetCo
ntrast
.1.3.6.1.4.1.2699.2.4.1.6.1.1.6.1 Integer R/W
pdmDisplaySet
pdmDisplaySetCo
nMax
.1.3.6.1.4.1.2699.2.4.1.6.1.1.7.1 Integer R 100
pdmDisplaySet
pdmDisplaySetRe
d
.1.3.6.1.4.1.2699.2.4.1.6.1.1.8.1 Integer R DEFVAL { 0 }
pdmDisplaySet
pdmDisplaySetGr
een
.1.3.6.1.4.1.2699.2.4.1.6.1.1.9.1 Integer R DEFVAL { 0 }
pdmDisplaySet
pdmDisplaySetBlu
e
.1.3.6.1.4.1.2699.2.4.1.6.1.1.10.1 Integer R DEFVAL { 0 }
pdmDisplaySet
pdmDisplaySetRG
BMax
.1.3.6.1.4.1.2699.2.4.1.6.1.1.11.1 Integer R DEFVAL { 100 }
pdmDisplaySet
pdmDisplaySetSat
uration
.1.3.6.1.4.1.2699.2.4.1.6.1.1.12.1 Integer R/W
pdmDisplaySet
pdmDisplaySetSat
Max
.1.3.6.1.4.1.2699.2.4.1.6.1.1.13.1 Integer R 100
pdmDisplaySet
pdmDisplaySetHu
e (Tint)
.1.3.6.1.4.1.2699.2.4.1.6.1.1.14.1 Integer R/W
pdmDisplaySet
pdmDisplaySetHu
eMax
.1.3.6.1.4.1.2699.2.4.1.6.1.1.15.1 Integer R 100
pdmDisplaySet
pdmDisplaySetSh
arpness
.1.3.6.1.4.1.2699.2.4.1.6.1.1.16.1 Integer R/W
pdmDisplaySet
pdmDisplaySetSh
pMax
.1.3.6.1.4.1.2699.2.4.1.6.1.1.17.1 Integer R 31
pdmDisplaySet
pdmDisplaySetCol
orTemp
.1.3.6.1.4.1.2699.2.4.1.6.1.1.18.1 Integer R/W
3. Custom
4. Low
5. Mid
6. High
pdmDisplaySet
pdmDisplaySetRe
dClrTmp
.1.3.6.1.4.1.2699.2.4.1.6.1.1.19.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet
pdmDisplaySetGr
eenClrTmp
.1.3.6.1.4.1.2699.2.4.1.6.1.1.20.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet
pdmDisplaySetBlu
eClrTmp
.1.3.6.1.4.1.2699.2.4.1.6.1.1.21.1 Integer R/W DEFVAL { 50 }
pdmDisplaySet
pdmDisplaySetClr
TmpMax
.1.3.6.1.4.1.2699.2.4.1.6.1.1.22.1 Integer R DEFVAL { 0 }
pdmDisplaySet
pdmDisplaySetVid
eoMute
.1.3.6.1.4.1.2699.2.4.1.6.2.0 Integer R/W
Blank Screen
1. Muted
2. notMuted
pdmDisplaySet
pdmDisplaySetDis
playMode
.1.3.6.1.4.1.2699.2.4.1.6.3.0 Integer R/W
pdmLightSource
pdmLightSourceIn
dex
.1.3.6.1.4.1.2699.2.4.1.7.1.1.1.1 Integer not-accessible 1
pdmLightSource
pdmLightSourceD
escription
.1.3.6.1.4.1.2699.2.4.1.7.1.1.2.1 String R Philips E21.9 400W ARC1.3
pdmLightSource
pdmLightSourceSt
atus
.1.3.6.1.4.1.2699.2.4.1.7.1.1.3.1 Integer R
Standby mode->DEFVAL { 2 }
Okay(3) ; Failed(4)
pdmLightSource
pdmLightSourceE
coSetting
.1.3.6.1.4.1.2699.2.4.1.7.1.1.4.1 Integer R/W
ECO Mode
4. Off -> Normal
5. On -> Low
pdmLightSource
pdmLightSourceA
ge
.1.3.6.1.4.1.2699.2.4.1.7.1.1.5.1 Integer R
pdmLightSource
pdmLightSourceE
rrorCounter
.1.3.6.1.4.1.2699.2.4.1.7.1.1.6.1 Integer R
pdmLightSource
pdmLightSourceR
eset
.1.3.6.1.4.1.2699.2.4.1.7.1.1.7.1 Integer R/W
DEFVAL { 1 }
resetFRU(3) &
resetCountersOnly(4)-->lamp
hour & Error Counter reset to0
pdmLightSource
pdmLightSourceR
eplacementCount
.1.3.6.1.4.1.2699.2.4.1.7.1.1.8.1 String R DEFVAL { "" }
pdmLightSource pdmLightSourceR .1.3.6.1.4.1.2699.2.4.1.7.1.1.9.1 String R DEFVAL
Produkspesifikasjoner
| Merke: | Dell |
| Kategori: | videoprosjektor |
| Modell: | 7700HD |
| Produkttype: | Stor projektor for arenaer |
| Vekt: | 7260 g |
| Bredde: | 432 mm |
| Dybde: | 290 mm |
| Høyde: | 135 mm |
| Støynivå: | 39 dB |
| Strømkilde: | AC |
| Bruksanvisning: | Ja |
| Plassering: | Desktop |
| Wi-Fi: | Nei |
| USB-kontakttype: | Mini-USB B, USB Type-A, USB Type-B |
| Antall USB 2.0-porter: | 4 |
| Antall HDMI-porter: | 2 |
| DVI-port: | Nei |
| Innebygde høyttalere: | Ja |
| Antall innebygde høyttalere: | 2 |
| Passordbeskyttelse: | Ja |
| Hodetelefonutganger: | 2 |
| Full HD: | Ja |
| HDCP: | Ja |
| 3D: | Nei |
| HDMI-versjon: | 1.3 |
| Kontrastforhold (dynamisk): | 10000:1 |
| Ensartethet: | 85 |
| Kontrastforhold: | 2500:1 |
| AC-inngangsspenning: | 100 - 240 V |
| AC-inngangsfrekvens: | 50 - 60 Hz |
| Strømforbruk (standby): | 0.5 W |
| Projektorens lysstyrke: | 5000 ANSI lumen |
| Projektoroppløsning: | 1080p (1920x1080) |
| Produktfarge: | Sort |
| Naturlig sideforhold: | 16:9 |
| Analogt signalformatsystem: | NTSC, NTSC 4.43, NTSC J, NTSC M, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL M, PAL Nc, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L |
| Kabler inkludert: | AC, USB, VGA |
| Visningsteknologi: | DLP |
| Skjermstørrelsekompabilitet: | 20.3 - 292.9 " |
| Projeksjonsavstand: | 1 - 12 m |
| Støynivå (økonomisk funksjon): | 36 dB |
| Zoomfunksjon: | Ja |
| Brennviddeområde: | 39.12 - 46.94 mm |
| Zoom-type: | Manuell |
| RS-232-port: | 1 |
| Lyskildens tjenestetid: | 1500 timer |
| Lyskildetype: | Lampe |
| Strømforbruk (vanlig bruk): | 525 W |
| Støttede videofunksjoner: | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
| Antall VGA (D-Sub)-porter: | 3 |
| Komponentvideo (YPbPr/YCbCr) inn: | 1 |
| Strøminngang/AC (strøm) inn: | Ja |
| Seriell grensesnittype: | RS-232 |
| Antall ethernets-/bredbåndstilkoblinger (RJ-45): | 1 |
| Driftstemperatur (T-T): | 5 - 35 °C |
| Oppbevaringstemperaturomåde (Celsius): | 0 - 60 °C |
| Lagringsrelativ fuktighet: | 0 - 90 |
| Bærekraftsertifikater: | RoHS |
| Fjernkontroll medfølger: | Ja |
| Hurtigstartsguide: | Ja |
| forskyvning: | 115 |
| DC-inngangskontakt: | Ja |
| Antall S-Video-innganger: | 1 |
| Lampestrøm (økonomisk modus): | 2000 W |
| Ethernet/bredbåndsforbindelse: | Ja |
| Relativ luftfuktighet under drift (H-H): | 0 - 80 |
| Komposittvideo inn/sammensatt video inn: | 1 |
| RMS-rangert strøm/utgangseffekt: | 10 W |
| Batterier medfølger: | Ja |
| Lampens effekt: | 400 W |
| Forbruk (økonomimodus): | 430 W |
| Blenderåpning rekkevidde: | 2.6 - 2.9 |
| Projeksjonsfaktor: | 1.85 - 2.22:1 |
| Kabellåsport: | Ja |
| Kabellåstype: | Kensington |
| Zoom-forhold: | 1.2:1 |
| Støttede forhold: | 16:9 |
| Strømforbruk, strømsparing: | 20 W |
Trenger du hjelp?
Hvis du trenger hjelp med Dell 7700HD still et spørsmål nedenfor, og andre brukere vil svare deg
videoprosjektor Dell Manualer
5 August 2025
videoprosjektor Manualer
- videoprosjektor Sharp
- videoprosjektor Panasonic
- videoprosjektor JVC
- videoprosjektor Canon
- videoprosjektor BenQ
- videoprosjektor Barco
- videoprosjektor Stairville
Nyeste videoprosjektor Manualer
6 August 2025
5 August 2025
5 August 2025
5 August 2025
5 August 2025
4 August 2025
4 August 2025
4 August 2025
3 August 2025
3 August 2025
