Side 1/4
012512
www.DiamondAudio.com
DE Speaker Manual 2013.indd Spread 1 of 4 - Pages(8, 1)
(a division of CV & DA Holdings, Inc.)
®
1225 E. 7th Street
Los Angeles, CA. 90021
S e r i e s
SP EA KE RS
S e r i e s
SP EA KE RS
DE525/DE652/DE682/DE692/DETAK/DEK3/DE65C/DE365C/DE65V
FEATURES
ABOUT THE DIAMOND AUDIO EXPERIENCE
• Composite foam core carbon fiber cone
• 25mm aluminum dome tweeter with Ferro fluid cooling
• Composite ABS frame design
• External 18dB/octave SQ matched crossover with RAF (rear acoustic fill) output
PARTS LIST
DE525,DE652,DE682,DE692
(2) DE Coaxial Speakers
(2) Mounting Gaskets
(1) Mounting Hardware Kit
DE65V
(2) DEV Convertible Speakers
(2) DEV Model Specific Crossovers
(2) Mounting Gaskets
(1) Mounting Hardware Kit
DETAK,DEK3,DE65C,DE365C
(2) DE Component Speakers (except DETAK)
(2) DE Model Specific Crossovers
(2) Mounting Gaskets
(1) Mounting Hardware Kit
(2) DE Component Tweeters (except DEK3)
LIMITED SPEAKER WARRANTY STATEMENT
Diamond Audio T echnologies, (CV & DA HOLDINGS INC.) warrants this product to be free from defects in material and
workmanship for a period of one (1) year from the original date of purchase provided it was purchased from an authorized
DAT retailer within the United States. Product warranty period starts at date of purchase or one year past manufacture date
whichever is first. However, upon purchase, completion of the online registratio and installation by an authorized Dn AT dealer
your warranty period will be extended to two (2) years. This warranty extension o fer will only be recognized upon completion f
of the online registration of your product within 30 days of the date of purchase.
THIS ARRANTW Y IS NO AND APPLIES ONLY T TRANSFERABLE T THE ORIGINAO L PURCHASER OF THIS PRODUCT
IN ITS ORIGINA TL INS ALLATION. Original purchaser must reside in the United States and be able to provide proof of
purchase and installation with the sales receipt and completion of online regoistration from the authorized DAT retailer that
sold and installed the product.
Should a manufacturing defect occur durin above said warranty period, Dg AT will replace or repair the defective product
with a product of the same or equivalent value and performance.
Damage or failure caused by any of the following is not covered under this warranty policy: negligence, improper use,
abuse, product modification, unauthorized repair attempts, accident, acts of God, misrepresentations by DAT retailers, and
improper/inadequate packaging during return shipping.
Warranty is void if serial numbers have been removed, altered or defaced.
HOW TO OBTAIN WARRANTY SERVICE
In the event a DAT product should require service, you should visit the authorized DAT retailer you purchased the product
from and they can expedite your claim. All claims must fall into the guidelines listed above and be accompanied by a copy of
the original sales and installation receipt from that authorized DAT retailer.
Product returned for warranty service must be freight-prepaid, properly packaged and clearly marked with the Return
Authorization (RA) number issued by DAT. Any product returned to DAT that is improperly packaged, does not have a
RA number clearly marked on the package, or never received a R number may be refused upon deliveryA . DAT does not
assume responsibility for lost or misdirected product.
Repair or replacement under this warranty is the exclusive remedy of the consumer. DAT shall not be liable for any
incidental or consequential damages for breach of any expressed or implied warranty on this product. Some states do not
allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may
also have other rights that may vary from state to state.
Customers outside the United States should contact their local sales office to obtain information on pricing, exchange unit
availability, instructions, service and warranty/non-warranty replacement or repair.
Diamond Audio Technologies
1225 E.7th ST
LOS ANGELES,CA 90021
Tel: 213-261-4161
Fax: 213-947-4767
Web: diamondaudio.com
Service/Tech Support:
213-261-4161
Tech Support Email
techsupport@diamondaudio.com
Diamond Audio T echnologies.
• (Aluminum cone on DE65V )
(used on DE65C,DE65V)
(2) DE tweeters
Congratulations, you have just purchased the finest mobile audio products on the market to
date. At Diamond Audio, our products represent the latest advances in acoustic technology in
sound reproduction for your vehicle. Diamond Audio products are designed, developed, and
engineered using the latest innovative materials and components to provide the finest sound
reproduction possible. Every Diamond Audio product has been Klippel verified and tested to
ensure the best sounding and most reliable product on the market, if installed properly,
Diamond Audio products will provide many years of the ultimate listening experience.
Please note that prolonged exposure to sound pressure levels in excess of 100dB can cause
permanent hearing loss. Using Diamond Audio products can exceed that level so please
exercise restraint in its operation in order to preserve your ability to enjoy its high fidelity sound
for many years to come.
Diamond Audio recommends our products be professionally installed by an authorized
Diamond Audio dealer to achieve the best possible system recommendation and installation.
This will ensure a true Diamond Audio listening experience and sound you would expect from
Diamond Audio products. In doing this you will extend your warranty from one year to two
years.
Go ahead, Hear the Music
©2014 Diamond Audio. All rights reserved.
(a division of CV & DA Holdings, Inc.)
©2014 Diamond Audio. All rights reserved.
(a division of CV & DA Holdings, Inc.)
DE Speaker Manual 2013.indd Spread 2 of 4 - Pages(2, 7)
PHYSICAL DIMENSIONS
A
D
B
E
C
MID-BASS SPEAKER MOUNTING
TWEETER CONFIGURATION
You have the option of configuring your speakers as
a coaxial system(tweeter attached) or a component
system(tweeter separate). If your choice is to use as
a coax then you will need to attach the tweeter to the
midrange. Locate the supplied tweeter post support and
attach the tweeter as shown. Remove the rubber boot
from the midrange, guide the tweeter wires down through
the middle of the midrange. Guide the tweeter wires so
that they lay in the groove of the inside of the rubber boot
as it replaced. Attach wires to the proper terminals.
DE Speaker Manual 2013.indd Spread 3 of 4 - Pages(6, 3)
UnitDimension
DE65V
6.5" 3.5"
DE365C
Total Diameter
(A)
in.
mm
6.51
165.5
Mounting Diameter
(B)
in.
mm
5.53
140.6
Screw Hole Dia.
(C)
in.
mm
6.14
156.0
Mounting Depth
(D)
in.
mm
2.26
57.5
Magnet Diameter
(E)
in.
mm
3.50
87.0
WattMax Power
150 140
dBSensitivity
88
3.43
87.0
2.81
71.3
3.15
80.0
1.56
39.7
2.58
65.5
87
HzFreq. Response
60-20k
DEK3
3.43
87.0
2.81
71.3
3.15
80.0
1.56
39.7
2.58
65.5
50
83
130-8k
DE65C
6.51
165.5
5.53
140.6
6.14
156.0
2.26
57.5
3.50
87.0
6.51
165.5
5.53
140.6
6.14
156.0
2.26
57.5
3.50
87.0
120
87
69-20k
DE692
9.20 x 6.40
233.9 x 162.8
8.46 x 5.79
215 x 147.1
6.58 x 4.71
167.2 x 119.7
2.75
70.0
4.21
106.4
150
84
60-20k
DE682
8.65 x 5.53
219.8 x 140.6
6.92 x 4.95
176.0 x 125.8
8.03 x 4.98
204.0 x 126.7
2.18
55.6
3.11
79.0
100
86
75-20k
DE652
6.51
165.5
5.53
140.6
6.14
156.0
2.26
57.5
3.50
87.0
120
87
69-20k
DE525
5.57
142.0
4.62
117.3
5.23
133.0
2.10
53.3
3.11
79.0
100
85
70-20k 69-20k
(OPTIONAL - FOR DE65V - ONLY!)
©2014 Diamond Audio. All rights reserved.
(a division of CV & DA Holdings, Inc.)
©2014 Diamond Audio. All rights reserved.
(a division of CV & DA Holdings, Inc.)
