PRO SERIES LED1000 INSTRUCTION MANUAL
THANK YOU
• Thank you for purchasing your Dracast PRO Series LED1000. We’re
condent that your Dracast light will provide years of reliable service.
• Please review this instruction booklet before using your Dracast light.
• To ensure proper continued operation, only use the power supply that is
included with your Dracast LED1000.
• To protect your eyes, do not look directly into the LED1000 while it is
powered on.
• To prevent electric shock, the LED1000, power supply, and any batteries
should be kept away from water or excessive moisture. Never submerge
the LED1000 or power supply.
• Make sure that the ventilation slots on the back of the LED1000 are clear
during operation. Covering these vents will cause the unit to overheat and
possibly malfunction.
• To extend the life of the LED1000, turn the unit o when it is not in use.
• Store the LED1000 in a clean, dry place with good ventilation. Do not store
the LED1000 in direct sunlight for extended periods.
• In case of malfunction, do not open your Dracast LED1000 unit. Please
consult your nearest Dracast repair center for assistance. Opening the
Dracast unit will void its one-year warranty.
FEATURES
• Anodized aluminum frame and all-metal chassis
• Local and remote DMX control
• 95 CRI (Color Rendering Index) for ultra-pure light
• High output. Up to 8000 Lux or 743 Footcandles
• V-Mount and Gold Mount battery plates included
• Included mounting yoke for use with 5/8” (baby pin) studs
• Locking yoke knobs
• Optional barn doors, lters, soft boxes, batteries, and more
• x1 Dracast PRO Series LED1000
• x1 12V A/C Power Supply for LED1000
• x1 5/8” Mounting Yoke
• x1 Nylon soft carrying case
• x1 Clear plastic LED board protector
• x1 V-Mount battery plate
• x1 Gold-Mount battery plate
INCLUDED IN THE BOX
OPERATING INSTRUCTIONS
Powering the light
The Dracast PRO Series LED1000 has three power options to choose from.
- A/C Power - Plug the power supply (included) into the XLR port on the back
of your LED1000. Press the power switch to “ON”
- V-Mount Battery - Attach a V-Mount lithium-ion battery (not included) to the
V-Mount battery plate included with your LED1000. Press the power switch to
“BATTERY”
- Gold Mount Battery - Attach a Gold-Mount lithium-ion battery (not included)
to the Gold-Mount battery plate included with your LED1000. Press the power
switch to “BATTERY”
Understanding the Controls
Your Dracast PRO Series is equipped with full 0 - 100% local controlability.
The dimming and color controls (if available) can be found on the back of the
xture.
PHOTOMETRIC DATA
LED1000 PRO 5600K
DRP-LED1000-DV/DG
3 ft / 0.9 m 6 ft / 1.8 m 9 ft / 2.7 m 12 ft / 3.6 m
743 fc
8000 lux
195 fc
2100 lux
95 fc
1025 lux
56 fc
600 lux
LED500 PRO 3200K
DRP-LED1000-TV/TG
790 fc
8500 lux
251 fc
2700 lux
121 fc
1330 lux
68 fc
735 lux
LED500 PRO
3200K - 5600K
DRP-LED1000-BV/BG
353 fc @ 3200K
669 fc @ 4400K
390 fc @ 5600K
3800 lux @ 3200K
7200 lux @ 4400K
4200 lux @ 5600K
107 fc @ 3200K
190 fc @ 4400K
111 fc @ 5600K
1150 lux @ 3200K
2050 lux @ 4400K
1200 lux @ 5600K
49 fc @ 3200K
88 fc @ 4400K
49 fc @ 5600K
530 lux @ 3200K
950 lux @ 4400K
530 lux @ 5600K
28 fc @ 3200K
52 fc @ 4400K
28 fc @ 5600K
300 lux @ 3200K
560 lux @ 4400K
300 lux @ 5600K
