Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
EN
Original Instructions
Version 1
Version 1: December 2024
First release
Read this manual in full before using this product and retain it
for future use. Always use the latest version of the manual.
Please visit drapertools.com/manuals for the latest
version.
1. Intended Use
This rechargeable battery-operated pump is designed for
quick and easy transfer of a wide range of uids. The pump
will t 20 Litre Drums. For use with Diesel, Kerosene, Diesel
Exhaust Fluid (DEF/ Adblue), Antifreeze, Windshield Fluid,
Mild Detergents & Agricultural Chemicals.
Any other application beyond the conditions established for
use will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No.: 07039
Part No.: RD/AP
Drum size: 20litres
Flow Rate: 11.5 L/min
Dispense Rate (Fully
charged battery) :
300 litres (tested with water)
Flexible Hose Length: 1.5m
Telescopic Suction Tube
Length:
380 – 520mm
Built in Battery: Rechargeable 2900mAh
Lithium-ion
Charging Time: approx. 3 hours
Operating Temperature: 5 - 40°C
Operating Cycle: maximum 15min (30min o)
Recommend Use: Diesel, kerosene, light oils,
diesel exhaust fuel, water,
antifreeze, mild detergents and
agricultural chemicals.
07039
DEF/ADBLUE PUMP
RECHARGEABLE
3. HealthandSafetyInformation
Important: Read all the Health and Safety instructions
before attempting to operate, maintain or repair this product.
Failure to follow these instructions may result in injury or
damage to the user or the product.
WARNING!
• DO NOT run the pump dry.
• DO NOT use with acids, acetone, benzene, cresol,
concentrated caustic soda, liquid thinner or other
solvents.
• DO NOT use with deteriorated or contaminated liquids or
fuels.
• DO NOT use the pump for hot liquids above 40°C.
• DO NOT operate the pump for longer than 15 minutes
without a 30-minute rest.
• DO NOT turn the pump upside down after use.
• ALWAYS ensure the pump is turned ‘OFF’ and liquid has
been drained from the pump before cleaning.
• DO NOT use abrasives or solvents to clean the pump.
• ALWAYS wear suitable protective clothing and eye
protection.
• Wear suitable protective impermeable gloves to avoid
repeated and prolonged contact of uids with the skin.
• Keep the work area clean and dry. DO NOT use in damp or
wet areas.
• DO NOT modify the pump and DO NOT use for a purpose
it was not intended.
• Before using the pump check for damaged parts and that
it operates correctly. Replace any damage parts
immediately.
• Keep the pump away from heat and sharp edges. Before
each use check the pump for wear and ensure all
connections are secure.
• Store the pump in a dry location when not in use to
prevent rusting.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Website: drapertools.com
Email: sales@drapertools.com
Product Helpline: +44 (0) 23 8049 4344
Telephone Sales Desk: +44 (0) 23 8049 4333
General Enquiries: +44 (0) 23 8026 6355
© Published by Draper Tools Limited
4. Identication
Carefully remove the product from the packaging and
examine it for any signs of damage that may have occurred
during shipment. If any part is damaged or missing, do not
attempt to use the product. Please contact the Draper
Helpline; contact details can be found at the back of this
manual.
1
10
9
8
7
6
2
5
3
4
1. Storage hook
2. ON/OFF switch
3. Nozzle holder
4. USB charging port
5. USB charging light
6. Flexible hose
7. Telescopic suction tube
8. Flow control nozzle
trigger
9. Nozzle
10. USB charging cable
Please visit drapertools.com for our full range of accessories
and consumables.
5. Chargingthepump
Important: Before operating this product fully charge using
the USB cable supplied.
Plug into the charging port
4
and the green light
5
will
ash while charging.
Once charged the light will remain solid.
6. PreparingthePump
1. Adjust the length of the suction tube
7
depending on
the size the container/drum the uid is being pumped
from. Turn the adjuster to release the two section and
tighten once length adjusted.
2. Place the nozzle
9
into the container that the uid is
being transferred into.
7. OperationthePump
1. Slide the switch
2
to the “ON” position.
2. Press the nozzle trigger
8
to start dispensing the uid.
3. Release the trigger once dispensing complete and slide
the switch to the “OFF” position.
− A buzzer will sound during operation when the battery
level is low and needs recharging.
8. Maintenance,StorageandDisposal
• ALWAYS ensure the pump is turned “OFF” and liquid
has been drained before cleaning or carrying out any
maintenance.
• DO NOT abrasives or solvents to clean the pump.
• Clean the suction tube and nozzle after each use.
• At the end of its working life, dispose of the product
responsibly and in line with local regulations. Recycle
where possible.
• DO NOT dispose of this product with domestic waste;
most local authorities provide appropriate recycling
facilities.
• DO NOT burn or mutilate batteries; this may release
toxic or corrosive substances.
9. Warranty
12 months from date of purchase –
Visit drapertools.com/warranty for full details.
10. Symbols
Read the instruction
manual
WEEE – Waste Electrical &
Electronic Equipment
Do not dispose of Waste
Electrical & Electronic
Equipment in with domestic
rubbish
European conformity
UK Conformity Assessed
Warning!
Do not incinerate or throw
onto re
Wear suitable eye protection
Wear suitable personal
protective equipment (PPE)
