PRO-1.5KP12.2

12'' COMPETITION MID-BASS /

WOOFER LOUDSPEAKER

ALTAVOZ TIPO WOOFER / MEDIO BAJO

DE COMPETICION DE 12’’

OWNER’S MANUAL

MANUAL DEL USUARIO

PRO-1.5KP12.2

SPECIFICATIONS / ESPECIFICACIONES:

Nominal Diameter / Diámetro Nominal.. ............................................................................................................12"

Nominal Impedance / Impedancia Nominal ............................................................................................ 2 OHMS

RMS Power Handling / Manejo de Potencia RMS ................................................................................... 1500W

MAX Power Handling / Manejo de Potencia MAX.................................................................................... 3000W

Sensitivity (1w/1m) / Sensibilidad (1w/1m) ............................................................................................ 96.5 dB

Frequency Response / Respuesta de Frecuencia .............................................................................60Hz-8KHz

Recommended Hi Pass Crossover / Crosover Paso alto Recomendado ................................................ 70Hz

Pair or Single / Par o Unidad............................................................................................................Single / Unidad

MOTOR / MOTOR:

Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................................4”

Voice Coil Former Material / Material Interior de Bobina Móvil ...................... Fiber Glass / Fibra de Vidrio

Winding Material / Material de Bobinado..................................................................................................... CCAW

Cone Material / Material del Cono..................................................................................................... Paper / Papel

Dust Cap Material / Material de la Tapa anti-polvo ...................................................................... Paper / Papel

Surround Material / Material de la Suspension ..................................................................................Cloth / Tela

Basket Material / Material de la Canasta..........................................................................Aluminum / Aluminio

Basket Color | Finish / Color Acabado de Canasta......................................................................... Black / Negro

Magnet Material / Material del Imán............................................................................................. Ferrite / Ferrita

Magnet Weight / Peso del Imán.................................................................................................................... 150 Oz

THIELE & SMALL PARAMETERS/ PARÁMETROS T/S:

Equivalent Volume / Volumen Equivalente ......................................................Vas ................................ 22.775 L

Free Air Resonance / Resonancia al Aire Libre................................................Fs .................................... 72.4 Hz

Mechanical Factor / Factor Mecánico................................................................Qms ................................... 9.451

Electrical Factor / Factor Eléctrico......................................................................Qes......................................0.301

Total Factor / Factor Total.....................................................................................Qts....................................... 0.291

Mechanical Mass / Factor Mecánico..................................................................Mms ................................ 51.09g

Mechanical Compliance / Cumplimiento Mecánico........................................Cms.................... 70.323 mm/N

BL Factor / Factor BL..............................................................................................BL ..................................... 15.144

Voice Coil Inductance / Inductancia de Bobina de Voz ..................................Le.................................1.566 mH

Cone Area / Area del cono.....................................................................................Sd .................................. 560 cm2

DC Resistance / Resistencia DC ..........................................................................Re ................................... 1.6 ohm

Efficiency Bandwitch Product /

Eficiencia del Ancho de Bancda del Producto .....................................................Ebp..........................................240

MEASUREMENTS / MEDIDAS:

Overall Diameter / Diámetro Total............................................................................................ 12.36“ / 314 mm

Overall Depth / Profundidad Total................................................................................................6.53” / 166 mm

Front Mount Baffle Cutout / Corte del Orificio de Montaje................................................. 11.18” / 284 mm

Mounting Depth / Profundidad de Montaje ............................................................................... 5.98” / 152 mm

Motor Diameter / Diámetro del Motor ........................................................................................ 8.66” / 220 mm
