Side 1/4

PRO-NS6.4

OWNER’S MANUAL

MANUAL DEL USUARIO

6.5'' MID-RANGE LOUDSPEAKER WITH

ULTRA SLIM NEODYMIUM MAGNET

ALTAVOZ DE RANGO MEDIO DE 6.5” CON

MAGNETO ULTRA DELGADO DE NEODIMIO

ENGLISH | ESPAÑOL

PRO-NS6.4

6.57”/167mm

5.7”/145mm

4”/103mm

mm65/”2.2

mm05/”69.1

SPECIFICATIONS / ESPECIFICACIONES:

Nominal Diameter / Diámetro Nominal.........................................................................................6.5" / 167mm

Nominal Impedance / Impedancia Nominal ............................................................................................. 4 Ohms

RMS Power Handling / Manejo de Potencia RMS ......................................................................................150W

MAX Power Handling / Manejo de Potencia MAX.......................................................................................300W

Sensitivity (1w/1m) / Sensibilidad (1w/1m) ................................................................................................94 dB

Frequency Response / Respuesta de Frecuencia ..................................................................... 100Hz - 12KHz

Recommended Hi Pass Crossover / Crossover Paso alto Recomendado ............................................180Hz

Pair or Single / Par o Unidad............................................................................................................Single / Unidad

MOTOR / MOTOR:

Voice Coil Diameter / Diámetro de la Bobina de Voz....................................................................1.5”/38.6 mm

Voice Coil Former Material / Material Interior de Bobina Móvil .................................................................. KSV

Winding Material / Material de Bobinado.....................................................................................Copper / Cobre

Cone Material / Material del Cono..................................................................................................... Paper / Papel

Dust Cap Material / Material de la Tapa anti-polvo ...................................................................... Paper / Papel

Surround Material / Material de la Suspension ..................................................................................Cloth / Tela

Basket Material / Material de la Canasta..........................................................................................Steel / Acero

Basket Color / Color de la Canasta ............................................................................Glossy Red / Rojo Brillante

Magnet Material / Material del Imán.............................................................................Neodymium / Neodimio

Magnet Weight / Peso del Imán...................................................................................................................1.79 Oz

THIELE & SMALL PARAMETERS/ PARÁMETROS T/S:

Equivalent Volume / Volumen Equivalente ......................................................Vas .................4.58L / 0.161ft3

Excursion (one way) / Excursión (1 vía).............................................................Xmax ..................................2 mm

Free Air Resonance / Resonancia al Aire Libre................................................Fs ..................................... 137 Hz

Mechanical Factor / Factor Mecánico................................................................Qms ...................................4.906

Electrical Factor / Factor Eléctrico......................................................................Qes......................................1.072

Total Factor / Factor Total.....................................................................................Qts..........................................0.88

Mechanical Mass / Factor Mecánico ................................................................Mms ................................ 7.356g

Mechanical Compliance / Cumplimie

nto Mecánico........................................Cms................183.287m cm/N

BL Factor / Factor BL..............................................................................................BL ............................................. 4.2

Voice Coil Inductance / Inductancia de la Bobina Móvil ...............................Le.................................. 2.695mH

Cone Area / Area del cono.....................................................................................Sd .........................132.732 Cm3

DC Resistance / Resistencia DC ..........................................................................Re ................................. 3.2 ohms

Mechanical Mass w/o air/ Factor Mecánico sin Aire .....................................Mmd ............................... 6.477 g

MEASUREMENTS / MEDIDAS:

Overall Diameter / Diámetro Total ................................................................................................6.57” / 167mm

Overall Depth / Profundidad Total...................................................................................................... 2.2” / 56mm

Front Mount Baffle Cutout / Corte del Orificio de Montaje........................................................5.7” / 145mm

Mounting Depth / Profundidad de Montaje ...................................................................................1.96” / 50mm

Motor Diameter / Diámetro del Motor ............................................................................................... 4” / 103mm
