PRO-X57.4BM
5x7" MID-RANGE
LOUDSPEAKER WITH BULLET
ALTAVOZ DE RANGO MEDIO
DE 5X7” CON BALA
ENGLISH | ESPAÑOL
OWNER'S MANUAL
MANUAL DEL USUARIO
SPECIFICATIONS / ESPECIFICACIONES
Nominal Diameter / Diámetro nominal ..................................................... 5x7" / 127x178mm
Nominal Impedance / Impedancia nominal ...................................................................... 4
Ohms
RMS Power Handling / Manejo de potencia RMS .............................................................175W
MAX Power Handling / Manejo de potencia MAX .............................................................350W
Sensitivity (1w/1m) / Sensibilidad (1w/1m) ....................................................................... 94dB
Frequency Response / Respuesta de frecuencia ................................................... 100Hz-8kHz
Recommended High-Pass Cr
ossover / Crossover de paso alto recomendado.............125Hz
Pair or Single / Par o unidad .................................................................................
Single/ Unidad
MOTOR / MOTOR
Voice Coil Diameter / Diámetro de la bobina de voz ...........................................1.5" / 38.6mm
Voice Coil Former Material / Material interior de la bobina de voz ...............................Kapton
Winding Material / Material de bobinado...........................................................................CCAW
Cone Material / Material del cono ......................... Non-Pressed Paper / Papel no prensado
Bullet Material / Material de la bala......................................................... Aluminum / Aluminio
Bullet Color /
Color de la bala
.............................................................
Gloss Red
/ Rojo brillante
Surround Material / Material de la suspensión ........................................................Cloth / Tela
Basket Material / Material de la canasta................................................................ Steel / Acero
Basket Color / Color de la canasta
..................................................
Gloss Red / Rojo brillante
Magnet Material / Material del imán ..................................................................Ferrite / Ferrita
Magnet Weight / Peso del imán ........................................................................................... 20 oz
MEASUREMENTS / MEDIDAS
Overall Diameter / Diámetro total ...................................................... 5.6x7.5" / 142x190mm
Overall Depth / Profundidad total ..................................................................... 2.67" / 67.8mm
Front Mount Baffle Cutout / Corte del orificio de montaje........... 5x7.1" / 127mmx181mm
Mounting Depth / Profundidad de montaje........................................................ 2.44" / 62mm
Motor Diameter / Diámetro del motor.............................................................. 4.33" / 110mm
THIELE & SMALL PARAMETERS / PARÁMETROS T/S
Equivalent Volume / Volumen equivalente ...................................... Vas...........10L / 0.353ft3
Excursion (one way) / Excursión (1 vía)............................................. Xmax.................... 1.4mm
Free Air Resonance / Resonancia al aire libre ................................. Fs ........................... 150Hz
Mechanical Factor / Factor mecánico ............................................... Qms .........................10.63
Electrical Factor / Factor eléctrico..................................................... Qes............................... 1.1
Total Factor / Factor total .................................................................. Qts ...................................1
Mechanical Mass / Masa mecánica ................................................. Mms.........................9.14g
Mechanical Compliance / Cumplimiento mecánico......................... Cms............. 0.088mm/N
BL Factor / Factor BL ........................................................................... BL .............................. 4.45
Voice Coil Inductance / Inductancia de la bobina de voz ................. Le ...................... 0.118mH
Cone Area / Área del cono................................................................... Sd ................. 203.58Cm2
DC Resistance / Resistencia DC ......................................................... Re...................... 3.5Ohms
PRO-X57.4BM
Displacement Volume /
Volumen de desplazamiento
.................................
0.24L / 0.0084ft3
Please visit our website DS18.com for more information
on our warranty policy.
We reserve the right to change products and specifications
at any time without notice.
Images may or may not include optional equipment.
Visite nuestra página web DS18.com para obtener más
información sobre nuestra garantía.
Nos reservamos el derecho de cambiar productos y
especificaciones en cualquier momento sin previo aviso. Las
imágenes pueden incluir o no equipo opcional.
WARRANTY
GARANTÍA
WARNING:
Cancer and Reproductive Harm.
www.P65Warning.ca.gov
ADVERTENCIA:
Cáncer y Daño Reproductivo.
www.P65Warning.ca.gov
MEASUREMENTS / MEDIDAS:
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
-10
0
10
20
30
40
50
60
70
80
90
100
110
SPL vs Freq
7.1" / 181mm
9" / 229mm
8.4" / 213mm
4.7" / 119mm
4.2" / 107mm
5.6" / 142mm
5
"/127mm
2.44" / 62mm
2.67"/67.8mm
Ø4.33"/110mm
7.5" / 190mm
