Side 1/4
PRO-X8BM
ENGLISH | ESPAÑOL
OWNER'S MANUAL
MANUAL DE USUARIO
8" MID-RANGE
LOUDSPEAKER WITH BULLET
ALTAVOZ DE RANGO MEDIO DE
8" CON BALA
PRO-X8BM
We LIKE IT LOUD
SPECIFICATIONS / ESPECIFICACIONES
Nominal Diameter / Diámetro nominal................................................................... 8” / 203mm
Nominal Impedance / Impedancia nominal.....................................................................8 ohms
RMS Power Handling / Manejo de Potencia RMS............................................................ 275W
MAX Power Handling / Manejo de Potencia MAX............................................................ 550W
Sensitivity (1w/1m) / Sensibilidad (1w/1m) ......................................................................97 dB
Frequency Response / Respuesta de frecuencia..............................................115Hz - 16KHz
Recommended HI Pass Crossover / Crosover paso alto recomendado....................... 120Hz
Pair or Single / Vendido en par o unidad............................................................ Single / Unidad
MOTOR /MOTOR
Voice Coil Diameter / Diámetro de la bobina de voz ...........................................1.5”/38.6mm
Voice Coil Former Material / Material interior de la bobina de voz.............................. Kapton
Winding Material / Material de bobinado.......................................................................... CCAW
Cone Material / Material del cono...........................Non-Pressed Paper / Papel no prensado
Surround Material / Material de la suspensión.......................................................Cloth / Tela
Magnet Material / Material del imán..................................................................Ferrite / Ferrita
Magnet Weight / Peso del imán........................................................................................... 30 Oz
Displacement Volume / Volumen de desplazamiento ...........................0.046L / 0.00162ft3
Basket Material / Material de la canasta............................................................... Steel / Acero
Basket Color / Color de la canasta ...................................................Glossy Red / Rojo brillante
Bullet Material / Material de la bala .........................................................Aluminum / Aluminio
Bullet Color / Color de la bala ...........................................................Glossy Red / Rojo brillante
THIELE & SMALL PARAMETERS / PARÁMETROS T/S
Equivalent Volume / Volumen equivalente ............................... Vas ................13.7L / 0.486ft3
Excursion (one way) / Excursión (una vía)............................... Xmax............................. 9.3 mm
Free Air Resonance / Resonancia al aire libre........................ Fs .................................... 122Hz
Mechanical Factor / Factor mecánico ..................................... Qms ..................................9.645
Electrical Factor / Factor eléctrico........................................... Qes......................................0.98
Total Factor / Factor total......................................................... Qts ....................................0.889
Mechanical Mass / Masa mecánica......................................... Mms............................... 8.076g
Mechanical Compliance / Cumplimiento mecánico............... Cms........................ 0.21 mm/N
BL Factor / Factor BL ................................................................. BL ......................................5.751
Voice Coil Inductance / Inductancia de la bobina de voz....... Le................................ 0.857mH
Cone Area / Área del cono......................................................... Sd ........................... 216.42Cm2
DC Resistance / Resistencia DC ............................................... Re ............................... 5.2 ohms
MEASUREMENTS / MEDIDAS
Overall Diameter / Diámetro total......................................................................8.22" / 209mm
Overall Depth / Profundidad total........................................................................ 3.5" / 88.6mm
Front Mount Baffle Cutout / Corte del orificio de montaje..............................7.17" / 182mm
Mounting Depth / Profundidad de montaje ...........................................................3.2" / 82mm
Motor Diameter / Diámetro del motor...............................................................4.72" / 120mm
Please visit our website DS18.com for more information
on our warranty policy.
We reserve the right to change products and specifications
at any time without notice.
Images may or may not include optional equipment.
Visite nuestra página web DS18.com para obtener más
información sobre nuestra garantía.
Nos reservamos el derecho de cambiar productos y
especificaciones en cualquier momento sin previo aviso. Las
imágenes pueden incluir o no equipo opcional.
WARRANTY
GARANTÍA
WARNING:
Cancer and Reproductive Harm.
www.P65Warning.ca.gov
ADVERTENCIA:
Cáncer y Daño Reproductivo.
www.P65Warning.ca.gov
MEASUREMENTS / MEDIDAS:
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
0
10
20
30
40
50
60
70
80
90
100
110
120
SPL vs Freq
Ø0.108”/2.75mm
Ø3.878”/197mm
Ø8.22" / 209mm
Ø4.72" / 120mm
3.2" / 82mm
3.5" / 88.6mm
Ø7.17" / 182mm
