Side 1/9
DATE: 22 AUG, 2014
SC NO.: SC-0192/14
JOB-00214-0077
MODEL NO.: RCD144 “DURONIC”
(Z-255-PM3UCi)
MANUAL LAYOUT & FOLDING PLAN FOR APPROVAL
Ref# IM-Z-255-PM3UCi-S02-009
SIZE: 102(W) x 136(H)mm
MATERIAL: 80 WOODFREE PAPER
PRINTING COLOR: BLACK
ENGLISH
COVER
FRONT VIEW
BACK VIEW
E-2 E-3
E-6E-5 E-7
BLANKWarranty BLANK
E-10E-9 E-11
E-4
E-8
BLANK
E-12
CD-MP3-USB-SD
DIGITAL MICRO HI-FI SYSTEM
OPERATING INSTRUCTIONS
RCD144
REMO TE
CONT R OL
PLL
DIGITAL
TUNER
USB
FLASH MEMORY
MP3 PLAYBACK
SD
MEMORY CARD
MP3 PLAYBACK
DI GI TAL
PLAYBACK
MP3
CLOCK
QUARTZ
DIGITAL
BLUE
BACKLIGHT
DISPLAY
CAUTION
DO NOT EXPOSE TO DRIPPING
OR SPLASHING LIQUIDS!
NOTE: CAUTION SYMBOLS ARE PRINTED ON REAR OF UNIT. PLEASE REFER TO
INSTRUCTION MANUAL.
E-2
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
VORSICHT: UNSICHTBARE LASERSTRAHLUNG TRITT AUS,
WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG
ÜBERBRÜCKT IST. NICHT DEM STRAHL AUSSETZENI.
VARNING: OSYNLIG LASERSTRÁLNING NÄR DENNA DEL ÄR ÖPPNAD OCH
SPÄRR ÄR URKOPPLAND. STRÁLEN ÄR FARLIG.
ADVARSEL: USYNLIG LASERSTRÁLING VED ÁBNING. NÁR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÁ UDS/ETTELSE FOR
STRÁLING.
ATTNENZIONE: RADIONS LASER INVISIDILE. NON GUARDARE
DIRETTAMENTE NELLA SORGENTE DEL LASER.
ACHTUNG: LASERLINSE NICHT BERÜHREN UNSICHTBARER LASERSTRAHL.
AVISO: A LENTE NUNCA DEVE SER TOCADA.
PLEASE NOTE: YOU WILL FIND THE
RATING LABEL FOR THIS PRODUCT
LOCATED ON THE BOTTOM OF THE UNIT.
CAUTION: GROUNDING OR POLARIZATION. THE PRECAUTIONS SHOULD BE TAKEN
SO THAT THE WIDER BLADE OF THE AC PLUG MUST MATCH THE SLOT IN
RECEPTACLE "WALL SOCKET".
CLASS 1 L ASER P RODUCT
KLASSE 1 L ASE R PRODUKT
LASER DE C LAS SE
LASER DI P RIM A CLASSE
KLASSE 1 L ASE R
LASER PRIM ERA C LASE
LASER CLAS SE 1
KLASSE 1 L ASE R PRODUKT
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS.
THE MAINS PLUG IS USED AS THE DISCONNECT DEVICE AND IT SHALL REMAIN
READILY OPERABLE. TO COMPLETELY DISCONNECT THE POWER INPUT, THE
MAINS PLU G OF THE APPARATUS MUST BE DISCONNECTED FROM THE MAINS
COMPLETELY. THE MAINS PLUG SHOULD NOT BE OBSTRUCTED OR SHOULD BE
EASILY ACCESSED DURING INTENDED USE.
The lightning ash and arrowhead within the triangle is a warning sign
alerting you of "dangerous voltage" inside the product.
CAUTION
RISK OF ELE CTRIC SHOCK
DO NOT OPEN
WARNING:
To reduce the risk of electric shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing to qualied service personnel.
CAUTION:
The exclamation point within the triangle is a warning sign alerting you of
important instructions accompanying the product.
THE APPARATUS SHOU LD NOT BE EXP OSED TO DRIPPIN G OR SPLASHING AND NO OBJECTS
FILLED WITH LIQUIDS SHOU LD BE PLA CED ON THE APPARATUS.
UNDER THE INFLUENCE OF ELECTROSTATIC PHENOMENON, THE PRODUCT MAY
MALFUNCTION AND USER TO POWER RESET.
BATTERY SHALL NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE, FIRE OR
THE LIKE.
CAUTION
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE.
THE MARKING AND RATING LABEL IS LOCATED AT REAR ENCLOSURE OF THE APPARATUS.
E-3
LOCATION OF CONTROLS
1. CD DOOR
2. USB/ SD COMPARTMENT DOOR
3. SD CARD SOCKET
4. USB SOCKET
5. SPEAKER (LEFT)
6. LCD DISPLAY
7. ON/ STANDBY KEY
8. BACK/ TUNE DOWN KEY
9. NEXT/ TUNE UP KEY
10. STOP/ BAND/ CLOCK SET KEY
11. PLAY/ PAUSE/ FM MODE KEY
12. FUNCTION KEY
13. VOLUME DOWN (-)/ FOLDER/ MEM - KEY
14. VOLUME UP (+)/ FOLDER/ MEM + KEY
15. REMOTE CONTROL SENSOR
16. SPEAKER (RIGHT)
17. FM ANTENNA
18. AUX IN SOCKET
19. HEADPHONE SOCKET
20. SPEAKER OUTPUT SOCKET
(LEFT & RIGHT)
21. AC CORD & PLUG
E-4
POWER SUP PLY
PREPARATION OF REMOTE CONTROL
-
UNDER THE UNIT.
- REMOVE (GENTLY PULL OUT) THE PLASTIC "TAB" FROM THE BATTERY
COMPARTMENT AT THE REAR OF THE REMOTE CONTROL.
- TEST THE REMOTE CONTROL BY PRESSING THE ON/ STANDBY KEY TO
CHECK THAT THE UNIT SWITCHES ON PROPERLY USING THE REMOTE CONTROL.
THE REMOTE CONTROL UNIT CAN BE FOUND THE BATTERY COMPARTMENT
REMOTE CONTROL:
2. EQ KEY
3. FUNCTION KEY
4. BACK/ TUNE DOWN KEY
5. PLAY/ PAUSE/ FM MODE KEY
6. NEXT/ TUNE UP KEY
7. id3/ SLEEP KEY
8. STOP/ BAND/ CLOCK SET KEY
9. VOLUME UP (+)/ FOLDER/ MEM + KEY
10. SNOOZE/ TIMER KEY
11. MEM/ PROG./ PLAY MODE KEY
12. VOLUME DOWN (-)/ FOLDER/ MEM - KEY
13. BATTERY COMPARTMENT
1. ON/ STANDBY KEY
1
2
3
4
7
10
5
8
11
6
9
12
13
WHEN THE POWER IS THE ENTIRE DIGITAL DISPLAY WILL LIGHT UP WITH
A BACK-LIGHT. THIS INDICATES THE HI-FI IS SWITCHED . "BLUE" "ON"
"ON"
IMPORTANT : HOW TO TELL IF POWER IS "ON" ?
- THIS SET WORKS ON NORMAL HOUSEHOLD AC-POWER.
- MAKE SURE THE SET VOLTAGE OF THE UNIT MATCHES YOUR LOCAL
VOLTAGE.
- INSERT THE PLUG OF THE AC-CORD INTO A WALL OUTLET WITH
AC-POWER.
- PRESS THE "ON/ STANDBY" KEY TO SWITCH “ON” THE UNIT.
- THIS UNIT IS DESIGNED TO OPERATE WITHOUT BEING TOTALLY POWERED "OFF".
IT WILL EITHER BE "ON" OR IN "STANDBY” MODE.
- IN STANDBY MODE, THE BLUE BACK-LIGHT OF THE DIGITAL DISPLAY WILL BE DIMMED
BUT THE DISPLAY WILL SHOW THE CURRENT TIME (CLOCK FUNCTION).
- ANYTIME DURING STANDBY MODE, YOU CAN SWITCH "ON" THE UNIT BY PRESSING THE
"ON/ STANDBY" KEY (ON REMOTE CONTROL OR FRONT PANEL OF THE MAIN UNIT).
- SAVE ENERGY BY SWITCHING THE SYSTEM TO "STANDBY" MODE WHEN NOT IN USE.
7
8
9
10
11
12 13
14
15
16
5
17
1
3
2
6
4
18 19 20
21
CONNECTION OF SPEAKER BOXES
- UNWRAP THE SPEAKER-CORDS OF BOTH SPEAKER-BOXES AND INSERT THE
LEFT/RIGHT PLUGS INTO SOCKETS IN THE REAR OF MAIN UNIT.
- PLACE THE SPEAKER BOXES AS FAR APART AS POSSIBLE FOR BEST SOUND
EFFECT.
INTELLIGENT POWER SAVING SYSTEM
- THIS SET HAS A BUILT-IN POWER SAVING SYSTEM WHICH WILL AUTOMATICALLY
PUT THE SET INTO A "STANDBY MODE" TO REDUCE POWER CONSUMPTION
WHEN IT DETECTS THAT THE SET IS NOT IN USE.
- THIS AUTOMATIC SWITCHING TO "STANDBY MODE" WILL HAPPEN
APPROXIMATELY 10-15 MINUTES AFTER THE FOLLOWING CIRCUMSTANCES:
(A) "CD" MODE: CD PLAYBACK HAS STOPPED (eg. AT THE END OF A DISC).
(B) "USB" MODE: USB PLAYBACK HAS STOPPED.
(C) "CARD" MODE: SD CARD PLAYBACK HAS STOPPED.
- TO RE-ACTIVATE THE UNIT AFTER IT HAS AUTOMATICALLY SWITCHED
TO "STANDBY MODE", SIMPLY PRESS THE "STANDBY/ON" KEY TO SWITCH
ON THE UNIT.
