Side 1/22

Office +1

Quick Installation Guide

12-2017 / v1.0

CONTENTS

I Quick Summary & Reminder .................................................................. 3

II Product Information .............................................................................. 4

II-1 Package Contents .................................................................................................................. 4

II-2 System Requirements ........................................................................................................... 5

II-3 Hardware Overview .............................................................................................................. 5

II-4 LED Status .............................................................................................................................. 6

II-5 Reset ...................................................................................................................................... 6

III Adding Office +1 AP to Office 1-2-3 ........................................................ 7

IV Replacing Master AP ............................................................................. 8

I Quick Summary & Reminder

1. You can find all supporting documents, video, and programs:

www.edimax.com/edimax_pro/download/Office1-2-3

2. For the complete Office 1-2-3 system introduction, please go to the link

below:

http://office123.edimax.com

3. During the initial power up, the master AP will automatically

communicate its settings with the Office +1 Access Point. After the

process (~10 minutes), all the settings will be set for the Office +1 AP.

4. The default username and password for Office +1 AP are admin and

1234 respectively.

After the automatic communication with the master AP, the username

and password of the Office +1 AP will change to the Master AP’s

username and password.

5. Clicking Apply during any of the configuration will reboot the AP, which

takes time, it is recommended that you use Apply only after changing

all settings.

6. If you wish to add more APs to expand your office coverage, Office

1-2-3 supports up to a total of 16 APs, please refer to the “Office +1”

package.

Produkspesifikasjoner

Merke:	Edimax
Kategori:	Tilgangspunkt
Modell:	Office +1
Vekt:	342 g
Bredde:	176 mm
Dybde:	176 mm
Høyde:	32 mm
LED-indikatorer:	Diagnostic, Power
Plassering:	Tak
Sertifisering:	CE, FCC
Internminne:	256 MB
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Antall brukere:	100 bruker(e)
MAC-adressefiltrering:	Ja
Utgangsstrøm:	1 A
Flash-minne:	32 MB
MIMO-type:	Multi User MIMO
Maksimal dataoverføringshastighet:	1267 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Virtuelle LAN-funksjoner:	Tagged VLAN
STA-isolasjon (samme VLAN):	Ja
Rask roaming:	Ja
Produktfarge:	Hvit
Monteringssett:	Ja
Kabler inkludert:	LAN (RJ-45)
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Hurtigstartsguide:	Ja
Harmonisert system (HS)-kode:	85176990
Quality of Service (QoS) støtte:	Ja
tilbakestillingsknapp:	Ja
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	1000 Mbit/s
Sikkerhetsalgoritmer:	PEAP, WEP, WPA, WPA2
Krav til strømforsyning:	11 W
Relativ luftfuktighet under drift (H-H):	0 - 90
Intern:	Ja
Kabellåsport:	Ja
Kabellåstype:	Kensington
AC-adapter bunt:	Ja
Strøm over Ethernet (PoE):	Ja
Antenne forbedringsnivå (max):	5 dBi
Antall antenner:	4
VLAN støtte:	Ja
Mottakersensitivitet:	-93 dBm
MIMO:	Ja
Antall SSID-støtte:	32
SSID-funksjoner:	Hidden SSID
