Side 1/6
7
GB
Table of contents
1. Safety information
2. Layout
3. Items supplied
4. Intended use
5. Technical data
6. Before starting the equipment
7. Assembly
8. Using the equipment
9. Functions
10. Maintenance
11. Ordering spare parts
12. Disposal and recycling
Anleitung_RT-TS 1221_SPK1:_ 24.01.2011 9:21 Uhr Seite 13
8
GB
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety regulations with due care. Keep this manual in
a safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety
regulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1/2)
1 Saw table
2 Saw blade guard
3 Push stick
4 Saw blade
5 Splitter
6 Table insert
7 Parallel stop
8 Motor
9 Power cable
10 Stand
11 On/Off switch
12 Star-grip screw for parallel stop
13 Scale for angle settings
14 Angle stop
15 Locking handle
16 Round handle for angle settings
17 Round handle for cutting height settings
18 Overload switch
19 Chip bin cover
20 Fixing screws
21 Table width extension
22 Swing-out support foot
3. Items supplied
Carbide-tipped saw blade
Parallel stop
Push stick
Bench-type circular saw
Angle stop
Ring wrench (30)
Wrench (31)
Operating instructions
Safety information
Table width extension (21)
4. Proper use
The bench-type circular saw is designed for cutting all
types of timber commensurate with the machine’s
size. The equipment is to be used for cutting anynot
type of round wood.
The machine is to be used only for its prescribed
purpose.
Any use other than that mentioned is considered to
be a case of misuse. The user/operator and not the
manufacturer shall be liable for any damage or injury
resulting such cases of misuse. The machine is to be
operated only with suitable saw blades. It is
prohibited to use any type of cutting-off wheel.
To use the machine properly you must also observe
the safety regulations, the assembly instructions and
the operating instructions to be found in this manual.
All persons who use and service the machine have
to be acquainted with this manual and must be
informed about its potential hazards.
It is also imperative to observe the accident
prevention regulations in force in your area.
The same applies for the general rules of
occupational health and safety.
The manufacturer shall not be liable for any changes
made to the machine nor for any damage resulting
from such changes.
Even when the machine is used as prescribed it is
still impossible to eliminate certain residual risk
factors. The following hazards may arise in
connection with the machine’s construction and
design:
Contact with the saw blade in the uncovered saw
zone.
Reaching into the running saw blade (cut
injuries).
Kick-back of workpieces and parts of workpieces
Saw blade fracturing.
Catapulting of faulty carbide tips from the saw
blade.
Anleitung_RT-TS 1221_SPK1:_ 24.01.2011 9:21 Uhr Seite 14
9
GB
Damage to hearing if essential ear-muffs are not
worn.
Harmful emissions of wood dust when the
machine is used in closed rooms.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data
V042-V032egatloV 50 Hz~
W 0021gnitar rewoP
Idle speed n
0
4800 rpm
Carbide saw blade Ø 210 x Ø 30 x 2.6 mm
42hteet fo rebmuN
mm 004 x 525ezis elbaT
Table size with width extension 525 x 470 mm
Max. table size with width extension 525 x 620 mm
Cutting height max.90° 48 mm
Cutting height max.45° 45 mm
Connector for dust extractor dia. 36 mm
/ IIdetalusni ytefaS
gk 6.51thgieW
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level 93,9 dB(A)
K
pA
Bd 3 ytniatrecnu
L
WA
sound power level 106,8 dB(A)
K
WA
Bd 3 ytniatrecnu
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
6. Before putting the machine into
operation
Make sure the machine stands securely, i.e. bolt
it to a workbench or solid base.
All the covers and safety devices have to be
properly fitted before the machine is switched on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine’s moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
Important. Always pull out the power plug before
carrying out any maintenance or conversion
work on the bench type circular saw.
7.1 Fitting the saw blade (Fig. 2/3)
Important! Pull out the power plug.
Loosen the chip bin cover (19) by undoing the
fixing screws (20) and swing it up.
Undo the nut with a ring wrench (30) on the nut
itself and a second wrench (31) on the motor
shaft (32) to apply counter-pressure.
Important! Turn the nut in the direction of
rotation of the saw blade (4).
Take off the outer flange and pull the old saw
blade (4) off the inner flange by dropping the
blade at an angle.
Clean the mounting flange.
Fit the new saw blade in reverse order.
Important! Note the direction of rotation (see
arrow on the saw blade).
Anleitung_RT-TS 1221_SPK1:_ 24.01.2011 9:21 Uhr Seite 15
