XLC-BGK Bottom Grid Kit
The X-Line Compact Bottom Grid Kit consists of the same rigging attachment parts as those integrated into the top of an
XLC Loudspeaker. When used at the bottom of an XLC Loudspeaker Array along with an additional XLC-Grid (sold
separately), the XLC-BGK allows for a column of X-Line Compact Loudspeakers to have a secondary rigging or
anchoring point while being safely pulled back to desired angles.
When using the Bottom Grid Kit never exceed the rigging rating of the XLC loudspeaker systems used
with it. These ratings account for stresses resulting from the load angles encountered in curved arrays.
These ratings are the limiting factors. Consult the XLC Rigging manual, and/or the rigging label on the
XLC loudspeaker systems for the ratings when used in curved arrays.
X-Line Compact
XLC-BGK Bottom Grid Kit
User Instructions
Figure 1: Attaching Bottom Grid
Kit to Loudspeaker at Bottom of
Array, along with a Secondary
Grid
XLC Loudspeaker at
Bottom of Array
(Loudspeaker Sold
Separately)
Shoulder Bolt for Locking
Button Bar into Bottom
Loudspeaker
(2 Included in Kit)
Rear XLC Swing Arm
(2 Included in Kit)
Front XLC Button Bar
(2 Included in Kit)
Quick-Release Pin
(2 Included in Kit)
XLC Grid
Installed Under Bottom
Enclosure
(Grid Sold Separately)
tsiLstraP)100-820203(KGB-CLX
metI ytitnauQ rebmuNtraP noitpircseD
1 2 000-671065 yssabuSraBnottuB
2 2 000-476005 mrAgniwSr
aeR
3 2 000-443065 niPesaeleR-kciuQ
4 2 000-140185 tloBredluohS
1
1
2
3
3
4
2
4
