EMBARGO DATE June 18th 2020
LISTING NAME Elgato Wave:1
Premium USB Condenser Microphone and Digital Mixing Solution, Anti-Clipping Technology, Tactile
Mute, Streaming and Podcasting
MSRP US$129.99 | CA$189.99 | €139.99 | £129.99
MARKETING ASSETS https://corsair.sharefile.com/d-s95b45347f34484b8
PRODUCT DESCRIPTION
LONG:
Wave:1 is your gateway to microphone and digital mixing mastery, fusing plug and play conve-
nience with broadcast-grade circuitry. Never clip again thanks to proprietary anti-distortion technol-
ogy. Connect headphones for zero-latency monitoring. Turn the dial to adjust monitor volume, press
to mute your mic feed, and see mute status at a glance. Plus combine all your audio sources and
create two independent mixes — one for you, one for your audience — with the Wave Link app.
Wave:1 doesn’t just give your stream or podcast a professional sonic signature. It gives you control
of your entire audio workflow.
MEDIUM:
Wave:1 is your gateway to microphone and digital mixing mastery, fusing plug and play convenience
with broadcast-grade circuitry. Never clip again thanks to proprietary anti-distortion technology. And
combine all your audio sources, plus create two independent mixes — one for you, one for your
audience — with the Wave Link app.
SHORT:
Wave:1 is your gateway to microphone and digital mixing mastery, fusing plug and play conve-
nience with broadcast-grade circuitry.
1/3 Version 1 May 5th 2020
PREMIUM MICROPHONE & DIGITAL MIXING SOLUTION
FEATURES • Condenser capsule with a tight cardioid polar pattern captures speech with precision
• Use the Wave Link app to control Wave:1 and up to seven other audio sources, plus create two
independent mixes
• Up to 24-bit / 48kHz analog to digital conversion delivers lush detail
• Proprietary Clipguard technology makes distortion virtually impossible
• Superior circuitry ensures seamless audio signal transmission
• Switchable low-cut filter removes unwanted low-frequency noise
• 3.5 mm headphone jack for zero-latency monitoring
• Control dial to adjust monitor volume and mute mic — with LED mute status ring
• Internal pop filter prevents plosive breath noise
• Adjustable desktop stand with boom arm adapter for ultimate flexibility
• Custom accessories include a shock mount, external pop filter, and desktop stand extension rods
(sold separately)
TECHNICAL SPECIFICATIONS • Capsule: 17 mm Electret
• Polar Pattern: Cardioid
• Resolution: 24-bit
• Sample Rate: 48 kHz
• Frequency Response: 70 - 20000 Hz
• Sensitivity: -25dBFS (min gain) | 15dBFS (max gain)
• Max SPL: 120dB (140dB Clipguard engaged)
• Dynamic Range: 95dB (115dB Clipguard engaged)
• Interface: USB-C
• Dimensions: 141 x 66 x 40 mm / 5.6 x 2.6 x 1.6 in
• Weight: Mic & U-Mount 245 g / 8.64 oz | Base 310 g / 10.93 oz
SYSTEM REQUIREMENTS • Windows 10 (64-bit) / macOS 10.15 or newer
• USB 2.0 port
• 4GB RAM
2/3 Version 1 May 5th 2020
PREMIUM MICROPHONE & DIGITAL MIXING SOLUTION
BOX CONTENTS Wave:1, USB-C Cable, Desktop Stand, Boom Arm Adapter, Quick Start Guide
PRODUCT DIMENSIONS 1.57 x 2.60 x 5.55 in / 40 x 66 x 141 mm (depth x width x height)
PRODUCT WEIGHT 0.47 lb / 215 g
PACKAGING DIMENSIONS 4.88 x 5.79 x 9.92 in / 124 x 147 x 252 mm (depth x width x height)
PACKAGING WEIGHT 2.18 lb / 990 g
MASTER PACK QUANTITY 16
MASTER PACK DIMENSIONS 12.01 x 20.47 x 20.67 in / 305 x 520 x 525 mm (depth x width x height)
MASTER PACK SHIPPING WEIGHT NW: 39.02 lb / 17.70 kg
|
GW: 34.83 lb / 15.80 kg
PALLET QUANTITY 256
WARRANTY 2 years
HARMONIZED TARIFF CODE 8518.10.8030
COUNTRY OF ORIGIN CHINA
PART NUMBER
|
UPC
|
EAN Part number: 10MAA9901
|
UPC: 840006618065
|
EAN: 0840006618065
3/3 Version 1 May 5th 2020
PREMIUM MICROPHONE & DIGITAL MIXING SOLUTION
