TECHNE SERIESCOMO WALL
Dimensions | Models
LED light with dimmer
30”W x 19 11/16”D x 1 15/16”H | ECM630S3
COMO 30”
36”W x 19 11/16”D x 1 15/16”H | ECM636S3
COMO 36”
Elica Design Center
Como combines arched glass wings and stainless
steel to create a light and airy environment…
the perfect centerpiece for any contemporary kitchen.
This gently flowing design is powered by a 600 CFM
blower that can handle the demands generated by
today's cooktops. Como is equipped with glass touch
controls, LED dimmable lighting and
dishwasher-safe stainless steel microhole filter.
Designed for standard ducted installation, Como can
also be installed as a recirculating system using the
Recirculating Kit, available as an accessory.
DIM-LIGHT
TO P
PERF ORMANCE
LED
LI GHT
AMBIENT
LI GHT
COMO
FEATURES
Elica Design Center
Size (in) & Type 30” or 36” wide Wall Chimney
Finish
Controls
Illumination
Installation Type
Blower Type
Filter Type
Noise (sones):
Electrical
Ducted, Recirculating Kit sold seperatly
Speed 1, 160 CFMs
Speed 2, 280 CFMs
Speed 3, 470 CFMs
Speed 4, 600 CFMs
Duct Transition
Round 6"/150cms
Dishwasher- Safe, Staineless Steel Microhole Filter
Min: 2.36, Max: 6 Sones
120 Volts, 60 Hertz, 394 Watts, 3.27 Amps
Stainless Steel + Black Glass
Touch Control 3S + Booster
2 Premium LED Dimmable Lights
PLUS
CFM REDUCTION
CFM Reduction System (CRS), is an exclusive feature to Elica hoods, which enables the
installer to reduce the maximum blower CFM, to meet local code requirements.
HUSH SYSTEM
35%, compared to typical range hoods.
DIM-LIGHT
The Dimmer allows you to adjust the brightness of the light as you wish. With Elica,
lighting is customized in a discreet, personal and practical way, in order to contribute in
creating the perfect kitchen atmosphere.
TOP PERFORMANCE
with an average aspiration range of 600 CFM's. With a noise level between 60-65 db(A)
at maximum speed (reference point varies based on the hood category).
LED LIGHT
LED lighting is undoubtedly the smartest solution in terms of energy saving. Expected life
time of over 20.000 hours, represents the most remarkable advantage of LED light bulbs.
AMBIENT LIGHT
Elica studies on hood lighting leaves no stone unturned. Here we have thought about
products not only able to light the cooktop, but the entire kitchen space. And so the
hood is transformed: from a kitchen appliance to a true lighting element. Considering the
design of Elica hoods, it is not hard to imagine how this option is unique, and represents
one extraordinary point of strength for us.
Accessories
Optional Recirculating Kit
CODE: KIT02721 / (30”, 36”)
Optional Long Chimney Extension
CODE: KIT0100315 / (30”, 36”)
Line Dr
a
wing
Models
ECM630S3 ECM636S3
A
30” (76.2 cm) 36” (91.4 cm)
B
19
11
⁄16” (50 cm)
C*
Max: 54
11
⁄64 ” (137.6 cm)
Min: 33
11
⁄32 ” (84.7 cm)
D**
Max: 50
5
⁄16” (127.8 cm)
Min: 29
11
⁄16” (75.4 cm)
E
6” (15.24 cm)
F
10
3
⁄
4
” (27.3 cm)
G
13
1
⁄32
” (33.1 cm)
* Ductless (Recirculating) version
** Ducted version
A
B
C
D
E
G
F
