LIEBERT® SN™

INTEGRATED SENSORS

Quick Installation Guide

590-1613-501A/SL-20840_REV3_9-17 1

Liebert Sensor, Cable and Mount

The Liebert SN integrated sensors

monitor temperature and humidity

in any area.

These instructions apply to the

following Liebert SN integrated-

sensor models:

• SN-Z01—integrated cable

with 1 temperature probe

• SN-Z02—integrated cable

with 3 temperature probes

• SN-Z03—integrated cable

with 4 probes: 3 temperature

and 1 humidity

SENSOR-STRING

COMPATIBLE

You can attach the sensors in a

string, and the string can be a

combination of integrated and

modular sensors. (Modular sensors

are single probes with a separate

cable.)

A string may include up to 10

probes and be a maximum of

65.6 ft (20 m).

The number of probes that may be

used with Liebert monitoring

products varies. Refer to the

product’s user guide for details.

PREPARE FOR

INSTALLATION

1. Record the address of

each sensor

During configuration, the web

user interface displays the

addresses of all connected

sensors.

Before mounting or connecting,

locate the sensor-address list

on the label near the RJ45-end

of the integrated cable (see the

picture on the following page).

An address is listed for each

temperature and humidity

sensor

Included Parts Quantity by Model Number

Part SN-Z01 SN-Z02 SN-Z03

Temperature sensor 1 3

Humidity sensor — — 1

Total number of probes 1 3 4

Sensor-bracket base 1 3 3

Sensor-bracket support 1 3 3

Screws, 8-32 x 7/16 2 6 6

Dual Lock™ fastener, 0.5 ft (0.15 m) 1 1 1

Cable ties 2 6 6

Alcohol pads 1 3 3

Quarter-turn High Pro fastener 1 3 3
