Side 1/44

Instructions Manual

Руководство по эксплуатации

Brugsvejledning

Manual de instrucciones

INDEX

RECOMMENDATIONS AND SUGGESTIONS ..................................................................................................................... 3

CHARACTERISTICS ............................................................................................................................................................. 4

INSTALLATION...................................................................................................................................................................... 6

USE...................................................................................................................................................................................... 10

MAINTENANCE................................................................................................................................................................... 11

УКАЗАТЕЛЬ

СОВЕТЫ И РЕКОМЕНДАЦИИ .......................................................................................................................................... 13

ХАРАКТЕРИСТИКИ............................................................................................................................................................ 14

УСТАНОВКА........................................................................................................................................................................ 16

ЭКСПЛУАТАЦИЯ................................................................................................................................................................ 20

УХОД.................................................................................................................................................................................... 21

INDHOLD

RÅD OG ANVISNINGER ..................................................................................................................................................... 23

APPARATBESKRIVELSE ................................................................................................................................................... 24

INSTALLATION.................................................................................................................................................................... 26

BRUG................................................................................................................................................................................... 30

VEDLIGEHOLDELSE .......................................................................................................................................................... 31

ÍNDICE

CONSEJOS Y SUGERENCIAS........................................................................................................................................... 33

CARACTERÍSTICAS ........................................................................................................................................................... 34

INSTALACIÓN ..................................................................................................................................................................... 36

USO...................................................................................................................................................................................... 40

MANTENIMIENTO............................................................................................................................................................... 41

RECOMMENDATIONS AND SUGGESTIONS

The Instructions for Use apply to several versions of this appliance. Accordingly, you may

find descriptions of individual features that do not apply to your specific appliance.

INSTALLATION

• The manufacturer will not be held liable for any damages resulting from incorrect or im-

proper installation.

• The minimum safety distance between the cooker top and the extractor hood is 650 mm

(some models can be installed at a lower height, please refer to the paragraphs on work-

ing dimensions and installation).

• Check that the mains voltage corresponds to that indicated on the rating plate fixed to the

inside of the hood.

• For Class I appliances, check that the domestic power supply guarantees adequate

earthing.

Connect the extractor to the exhaust flue through a pipe of minimum diameter 120 mm.

The route of the flue must be as short as possible.

• Do not connect the extractor hood to exhaust ducts carrying combustion fumes (boilers,

fireplaces, etc.).

• If the extractor is used in conjunction with non-electrical appliances (e.g. gas burning appli-

ances), a sufficient degree of aeration must be guaranteed in the room in order to prevent

the backflow of exhaust gas. The kitchen must have an opening communicating directly

with the open air in order to guarantee the entry of clean air. When the cooker hood is

used in conjunction with appliances supplied with energy other than electric, the negative

pressure in the room must not exceed 0,04 mbar to prevent fumes being drawn back into

the room by the cooker hood.

• In the event of damage to the power cable, it must be replaced by the manufacturer or by

the technical service department, in order to prevent any risks.

USE

• The extractor hood has been designed exclusively for domestic use to eliminate kitchen

smells.

• Never use the hood for purposes other than for which it has been designed.

• Never leave high naked flames under the hood when it is in operation.

• Adjust the flame intensity to direct it onto the bottom of the pan only, making sure that it

does not engulf the sides.

• Deep fat fryers must be continuously monitored during use: overheated oil can burst into

flames.

• Do not flambè under the range hood; risk of fire

• This appliance is not intended for use by persons (including children) with reduced physi-

cal, sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the appliance by a person respon-

sible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• “ CAUTION: Accessible parts may become hot when used with cooking appliances.”.

MAINTENANCE

• Switch off or unplug the appliance from the mains supply before carrying out any mainte-

nance work.

• Clean and/or replace the Filters after the specified time period (Fire hazard).

• Clean the hood using a damp cloth and a neutral liquid detergent.

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be

handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of

correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your

household waste disposal service or the shop where you purchased the product
