Fiio M17 Bruksanvisning

Fiio Hi-fi system M17

Les nedenfor 📖 manual på norsk for Fiio M17 (56 sider) i kategorien Hi-fi system. Denne guiden var nyttig for 2 personer og ble vurdert med 3.6 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/56

All the pictures below are for illustrations only. Specifics are subject to the actual product.

Foreword

Thank you so much for purchasing FiiO's portable high resolution lossless music player M17.

We have prepared this complete user manual for you. We hope this manual can help you get

the hang of the M17 and unleash its full potential.

An introduction to FiiO M17

The smart desktop-class M17 is an entirely new chapter of FiiO digital audio players. Its

desktop-grade DAC, amplification, power supply, etc. give it the output power and sound

quality to rival and perhaps even surpass highly-regarded desktop systems – but in a

portable package.

The left and right audio channels each contain a desktop-class, 8-channel ES9038PRO

flagship DAC. This means that each audio channel has 8 parallel outputs summed together

for superior resolution and minimal distortion for extremely pure audio reproduction.

The desktop-class THX 788+ headphone amp has an output power of up to 3000mW per

channel with a lower output impedance – allowing it to more effortlessly power all kinds of

headphones.

Desktop-grade power supply and gain: the M17 contains two power supplies – a battery

power supply and a power supply powered by external DC power. Under battery power,

there are 4 gain levels: low, medium, high, and headphone mode. When under DC mode,

the enhanced over-ear headphone mode gain is unlocked which can go as high as 16dB in

balanced output.

Desktop-caliber internals: high-end TI OPA2211 op-amp, supercapacitor, ultra-low noise

LT3045 LDO, NDK femtosecond crystal oscillator, etc.

Desktop-level connectivity: not only supports commonly used 2.5mm/3.5mm/4.4mm

headphone outputs, but also adds6.35mm output, RCA coaxial port, USB3.0 and USB2.0

ports.

With desktop-grade configurations, the M17 will be your great partner on the road of music.

Produkspesifikasjoner

Merke:	Fiio
Kategori:	Hi-fi system
Modell:	M17
Vekt:	610 g
Bredde:	28 mm
Dybde:	156.4 mm
Høyde:	88.5 mm
Batterikapasitet:	9200 mAh
Bluetooth:	Ja
Berøringsskjerm:	Ja
Wi-Fi:	Ja
Bluetooth-versjon:	5.0
Bluetooth-profiler:	AAC, LDAC, SBC
USB-kontakttype:	USB Type-C
Innebygde høyttalere:	Nei
Innebygd kamera:	Nei
Total lagringskapasitet:	64 GB
Oppladbar:	Ja
Andre kamera:	Nei
Skjermoppløsning:	1080 x 2160 piksler
Batteriladetid:	4.5 timer
Støttede lydformater:	AAC, AIFF, APE, DSD, FLAC, MP3, OGG, WAV, WMA
Produktfarge:	Sort
Antall støttede batterier:	1
Minnekortenhet:	MicroSD (TransFlash)
Skjermdiagonal:	5.99 "
Hodetelefontilkobling:	3.5 mm/6.35 mm
Innebygd kortleser:	Ja
Modell/Type:	MP3-spiller
Prosessormodell:	Snapdragon 660
Videoopptaksgrensesnitt:	USB 3.2 Gen 1 (3.1 Gen 1)
Maksimal størrelse på hukommelseskort:	2000 GB
Dvalefunksjon:	Ja
Line-out:	Ja
Kontinuerlig lyd-playbacktid:	- timer
Spiller, medietype:	Flashminne
Stemmeinnspilling:	Nei
