Side 1/24
USER GUI D E
NZ AU UK IE S G
GAS-ON-GLASS COOKTOP
CG301D, CG302D, CG451D, CG603D, CG604D, CG762D,
CG903D & CG905D models
3
CONTENTS
SAVE THESE INSTRUCTIONS
The models shown in this User guide may not be
available in all markets and are subject to change
at any time. For current details about model and
specification availability in your country, go to
our website fisherpaykel.com or contact your
local Fisher&Paykel dealer.
Registration
Register your product with us so we can
provide you with the best service possible.
To register your product visit our website:
fisherpaykel.com
Introduction 5
Safety and warnings 6
Before you begin 9
Cooktop use 10
Dual wok burner use 12
Cooking guide 13
Care and cleaning 15
Troubleshooting 18
Energy guidelines 20
Energy guidelines (GB & IE only) 21
Warranty and service 23
5
INTRODUCTION
Congratulations on your new purchase. Your Fisher & Paykel gas cooktop gives the ultimate
experience in gas cooking with speed and precision. You cooktop delivers powerful modern
functionality with a singular aesthetic treatment. Matte black detailing separates the control
panel from the black glass cooking surface, while black burners with anodised black dials
and trim complete the look for a cohesive, beautiful hob.
6
! WARNING!
Electrical Shock Hazard
Failure to follow this advice may result in
electrical shock or death.
• Switch the power to the cooktop off at the wall
before cleaning or maintenance.
• Do not cook on a broken or cracked cooktop. If
the glass should break or crack, turn off the gas
supply and switch the appliance off immediately
at the mains power supply (wall switch) and
contact a qualified technician.
! WARNING!
Fire Hazard
Failure to follow this advice may result in
serious injury.
• Never leave the appliance unattended when
in use. Boilover causes smoking and greasy
spillovers that may ignite.
! WARNING!
Poisoning Hazard
Failure to follow this advice may result in
poisoning or death.
• Never use this appliance as a space heater to
heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of
the appliance.
SAFETY AND WARNINGS
8
SAFETY AND WARNINGS
zIf the electrical supply cord is damaged, it must only be replaced by an
authorised person.
zIf the appliance is connected to the gas supply with a flexible hose, make sure that the
hose cannot come in contact with the bottom of the appliance or any sharp edges.
zEnsure that the electrical connection plug is accessible after installation.
zThis appliance should be connected to a circuit that incorporates an isolating switch
providing full disconnection from the electricity supply.
zDo not use an asbestos mat or decorative covers between the flame and the saucepan
as this may cause serious damage to your cooktop.
zDo not place aluminium foil or plastic dishes on the cooktop burners.
zDo not let large saucepans, frying pans or woks push any other pans aside. This could
make them unstable or deflect heat onto your benchtop and damage the surface.
zDo not use a steam cleaner for cleaning this cooktop.
zSaucepan handles may be hot to touch. Ensure saucepan handles do not overhang
other gas burners that are on. Keep handles out of reach of children.
zDo not stand or place heavy objects on this appliance.
zAfter use, ensure that the burner dials are in the ‘OFF’ (o) position.
zWhere this appliance is installed in marine craft or in caravans, it shall not be used as
a space heater.
zCAUTION: In case the glass surface breaks:
z Immediately shut off all burners and any electrical heating element, and disconnect
the appliance from the power supply.
z Do not touch the appliance surface.
z Do not use the appliance.
zTake care not to drop any heavy or sharp objects on the cooktop. The glass is tough,
but sharp or heavy objects falling on it (e.g. pepper mill, heavy-based frying pan) may
crack or chip it.
zCAUTION: The use of a gas cooking appliance results in the production of heat and
moisture in the room in which it is installed. Ensure the kitchen is well ventilated. Keep
natural ventilation holes open or install a mechanical ventilation device (mechanical
extractor hood). Prolonged intensive use of the appliance may call for additional
ventilation, for example opening of a window, or more effective ventilation, for example
increasing the level of mechanical ventilation where present. Consult a professional
before installation of the additional ventilation.
zAfter having unpacked the appliance, check to ensure that it is not damaged. In case of
doubt, do not use it and consult your supplier or a professionally qualified technician.
zPacking elements (eg plastic bags, polystyrene foam, nails, packing straps, etc.) should
not be left around within easy reach of children, as these may cause serious injuries.
zDo not modify this appliance.
zThis appliance is to be serviced only by Fisher & Paykel trained and supported service
technician or qualified electrician in order to avoid a hazard.
zSome products are supplied with protective film on steel and aluminium parts. This film
must be removed before using the appliance.
zNever leave the cooktop unattended when in use. Boil-over causes smoking and greasy
spills that may ignite.
zNever allow flames to extend beyond cookware or curl up its sides. This could discolor
and damage the utensil and you may get burned touching a hot handle.
zKeep handles out of the way. Turn handles so that they don’t extend over the edge of
the cooktop or another burner that is on.
zTake care when deep-frying. Oil or fat can overheat quickly, particularly on a high.
9
BEFORE YOU BEGIN
zRead this guide, taking special note of the 'Safety and warnings' section.
zRemove all packaging from the cooktop. Recycle responsibly.
zRemove any adhesive residue using dishwashing liquid on a soft cloth. Do not use any
harsh or abrasive cleaners.
6
4
5
1
8
2
7
3CG905D model illustrated
Cooktop features and accessories
1 Control panel
2 Burner dials
3 Burner indicators
4 Pan supports
5 Dual Wok pan support*
6 Small pan support*
7 Wok stand*
8 Serial label (cooktop base)
CG604D models only: Mini wok pan support
(not illustrated)
*Some models only
10
COOKTOP USE
Selecting and using the burners
Identify the desired burner and the
corresponding dial.
Turn the dial to any heat setting between
HIGH and LOW before releasing.
Do not set or leave the dial between HIGH
and O (OFF).
When you have finished cooking, turn the
dial clockwise back to O (OFF).
1
2
3
4
Push the dial down and turn counterclockwise
to the highest heat setting. Once the burner is
lit, hold the dial down for a further 3 seconds.
Note: a clicking sound should be present
when igniting the burner. If no clicking is
present, turn the dial clockwise back to
O (OFF) and refer to ‘Troubleshooting’.
LOW HIGH OFF
11
COOKTOP USE
Manual lighting
If the burner will not light after several attempts, the burner can be manually lit. If you
have attempted to light the burner with the ignition, allow 1 minute for any accumulated
gas to dissipate before manually lighting.
Wait until the flame is burning evenly before
turning the dial to any heat setting between
HIGH and LOW before releasing.
Do not set or leave the dial between HIGH
and O (OFF).
When you have finished cooking, turn the
dial clockwise back to O (OFF).
1
2
3
4
Carefully hold a lit match near the
desired burner.
Push the dial down and turn counterclockwise
to the highest heat setting. Once the burner is
lit continue to hold the dial down for a further
3 seconds.
12
DUAL WOK BURNER USE
Adjusting the dual wok burner*
When using a dual wok burner, you can
choose to use the inner burner only or both
the inner and outer burners as desired.
Setting both the inner and outer rings
Turn the dial to any heat setting between
MEDIUM HIGH and before releasing.
If the flame on the outer ring appears to
flutter, turn the dial slightly towards HIGH to
stabilise.
Setting the inner ring
Turn the dial to any heat setting between
MEDIUM and LOW before releasing.
When you have finished cooking, turn the
dial clockwise back to O (OFF).
1
2
3
LOW MEDIUM
MEDIUM HIGH
Inner and outer burners Inner burner only
*Some models only
13
COOKING GUIDE
Burner Min. diameter (mm) Max. diameter (mm)
1 Auxiliary 220no minimum
2 Semi-rapid 100 220
3 Rapid 220no minimum
4 Mini wok
without small pan support 150 220
with wok stand no minimum 360
5 Dual wok
without small pan support 200 340
with wok stand no minimum 400
Cookware
2
3
2
2
2 2
11
4
2
2
2
55 5
5 5
55 5
1
CG905D models
CG762D models
CG451D modelsCG603D models
CG302D models
CG301D models
CG604D models
CG903D models
Note: measurements provided from base of pan
For optimal performance, ensure the size of the cookware is suitable for the burner in use.
15
Ensure that all burner parts are correctly fitted. Incorrectly assembled burners may
produce dangerous flames. Flames should be blue with no yellow tipping, and burn without
fluttering around the burner cap.
CARE AND CLEANING
Replacing burner parts
Semi-rapid, rapid and auxiliary burners
Dual wok and mini wok burners
Burner cap
Burner skirt
do not remove
Burner skirt
do not remove
Burner cap
Burner ring
Flame spreader
Flame spreader
Ignitor
Ignitor
Probe
Probe
Incorrect alignment
Incorrect alignment
Correct alignment
Correct alignment
