Side 1/32

USER MANUAL

True RMS Digital MultiMeter Series

Models DM62, DM64, and DM66

FLIR DM6x USER MANUAL                                                                                    Document Identifier: DM6x-en-US_AB

 Table of Contents
ADVISORIES  4
1 Copyright  4
2 Quality Assurance  4
3 Documentation  4
4 Disposal of Electronic Waste  4
SAFETY  5
INTRODUCTION  7
METER AND DISPLAY DESCRIPTIONS  8
1 Front and Back Meter Descriptions  8
2 Rotary Function Selector  9
3 Control Buttons  9
4 Display Description  10
BASIC OPERATION AND FEATURES  11
1 Powering the Meter  11
2 Intelligent Auto Power OFF (APO)  11
3 LCD Backlight  11
4 Auto/Manual Range Mode  11
5 True RMS Response  11
6 Crest Factor  11
7 Out-of-range Warning (O.L)  11
8 Data Hold  12
9 Relative Zero Mode  12
10 VFD Mode (Low Pass Filter) Models DM64/DM66 only  12
11 MAX-MIN-AVG Record Mode  12
12 Test Lead Input Warning  12
13 Auto Voltage AC/DC Detection in ‘Lo Z’ mode (DM64/DM66 only)  12
MEASUREMENTS  13
1 AC/DC Voltage Measurements (VFD and Frequency on DM64/DM66)  13
2 Low Impedance (Lo Z) Auto-Voltage Measurements (DM64/66 only)  14
3 Line Frequency Measurements (DM64/DM66 only)  15
4 Resistance and Continuity Measurements  16
5 Capacitance (DM64/DM66) and Diode Measurements  17
6 AC/DC mV and Temperature (DM64/DM66) Measurements  19
