Side 1/47

Installation

Manual

PT-Series HD

427-0075-01-12 Version 110 November 2017 2

photocopied, translated, or transmitted to any electronic medium or machine readable form without the prior written

permission of FLIR Systems, Inc.

Names and marks appearing on the products herein are either registered trademarks or trademarks of FLIR Systems,

Inc. and/or its subsidiaries. All other trademarks, trade names, or company names referenced herein are used for

identification only and are the property of their respective owners.

This product is protected by patents, design patents, patents pending, or design patents pending.

The contents of this document are subject to change.

FLIR Systems, Inc.

6769 Hollister Avenue

Goleta, CA 93117

Support: http://www.flir.com/security/display/?id=71083

Important Instructions and Notices to the User:

Modification of this device without the express authorization of FLIR Systems, Inc., may void the user’s authority

under the FCC Rules to operate this device.

Note 1: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense. Shielded cables

must be used to connect this device to other devices.

Note 2: If ferrites are supplied with this equipment, the equipment was tested for compliance with the FCC limits for a

Class A digital device using power cables with the ferrites installed. When connecting one or two power cables to the

equipment, the supplied ferrites must be used with this equipment.

Industry Canada Notice:

This Class A digital apparatus complies with Canadian ICES-003.

Avis d’Industrie Canada:

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Proper Disposal of Electrical and Electronic Equipment (EEE)

The European Union (EU) has enacted Waste Electrical and Electronic Equipment Directive 2002/96/

EC (WEEE), which aims to prevent EEE waste from arising; to encourage reuse, recycling, and

recovery of EEE waste; and to promote environmental responsibility.

In accordance with these regulations, all EEE products labeled with the crossed out wheeled bin

either on the product itself or in the product literature must not be disposed of in regular rubbish bins,

mixed with regular household or other commercial waste, or by other regular municipal waste

collection means. Instead, and in order to prevent possible harm to the environment or human health,

all EEE products (including any cables that came with the product) should be responsibly discarded or recycled.

To identify a responsible disposal method nearby, please contact a local waste collection or recycling service, the

original place of purchase or product supplier, or the responsible government authority in the area. Business users

should contact their supplier or refer to their purchase contract.

427-0075-01-12, Version 110 November 2017 3

Table of Contents

Ta b l e of C o n t e nts

PT-Series HD Camera Installation

1.1 Camera Overview ......................................................................................................................5

1.2 Installation Overview ..................................................................................................................5

1.2.1 Camera Connection Options ............................................................................................5

1.2.2 Serial Communications Overview ....................................................................................6

1.2.3 Supplied Components ......................................................................................................6

1.2.4 Required Components .....................................................................................................6

1.3 Location Considerations ............................................................................................................7

1.4 Bench Testing ............................................................................................................................7

1.5 Camera Mounting ......................................................................................................................7

1.5.1 Galvanic Isolation .............................................................................................................7

1.5.2 Earth Ground Connection .................................................................................................8

1.5.3 Installation of Camera and Galvanic Isolation Kit .............................................................9

1.6 Camera Connections ...............................................................................................................11

1.6.1 Remove the Back Cover ................................................................................................11

1.6.2 Connecting power ..........................................................................................................12

1.6.3 Video Connections .........................................................................................................13

1.6.4 Ethernet Connection .......................................................................................................13

1.6.5 Serial Connection ...........................................................................................................13

1.6.6 Serial Communications Settings - Hardware DIP Switches ...........................................14

1.6.7 Cable Gland Sealing ......................................................................................................16

1.7 PT-Series HD Camera Specifications ......................................................................................17

Basic Operation and Configuration

2.1 IP Camera, ONVIF Profile S Compliant ...................................................................................19

2.1.1 Serial and/or IP Communications ...................................................................................19

2.1.2 Server Configuration ......................................................................................................19

2.2 Camera Bench Test .................................................................................................................19

2.2.1 Set IP Address using the FLIR Discovery Network Assistant (DNA) .............................20

2.3 Log into the Camera Web Page ...............................................................................................21

2.3.1 Live Video Page .............................................................................................................22

2.3.2 Camera Control and Status ............................................................................................23

2.3.3 Web Control Panel .........................................................................................................23

2.4 Camera Configuration ..............................................................................................................25

2.4.1 Expert and Admin Accounts ...........................................................................................25

2.4.2 Setup Menu ....................................................................................................................26

2.4.3 Maintenance Menu .........................................................................................................32

2.5 Thermal Imaging Overview ......................................................................................................42

2.6 Troubleshooting Tips ...............................................................................................................43

Serial Address: Decimal To Binary Conversion

3.1 Address Conversion Table .......................................................................................................45

Produkspesifikasjoner

Merke:	Flir
Kategori:	Sikkerhetskamera
Modell:	PT-625 HD
Vekt:	16400 g
Bredde:	467 mm
Dybde:	348 mm
Høyde:	326 mm
Bluetooth:	Nei
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	640 x 480 piksler
Videokomprimeringsformater:	H.264, M-JPEG
Strømkildetype:	AC, DC
Antall kameraer:	1
Fokus:	Motorisert/manuelt
Strømforbruk (maks.):	195 W
Sertifisering:	MIL-STD-810F\nIEC 60068-2-27\nFCC Part 15 (Subpart B, class A)\nCE, WEEE, ONVIF
Digital zoom:	12 x
Optisk zoom:	30 x
Støyreduksjon:	Ja
Støttede nettverksprotokoller:	IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, SCP
PTZ-kontroll:	Ja
Dag/natt-modus:	Ja
Minimum blenderåpning:	1.6
Antall sensorer:	1
Videostreaming:	Ja
Wide Dynamic Range (WDR):	Ja
AC-inngangsspenning:	24 V
Linsesynsvinkel, horisontal:	25 °
Linsesynsvinkel, vertikal:	18 °
Termisk modul:	Ja
Sensortype:	CMOS
Produktfarge:	Hvit
Vippevinkelområde:	-90 - 90 °
Analogt signalformatsystem:	NTSC, PAL
Pakketype:	Boks
Zoomfunksjon:	Ja
Brennviddeområde:	4.3 - 129 mm
RS-232-port:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-40 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-55 - 85 °C
Bærekraftsertifikater:	RoHS
nattsyn:	Ja
Formfaktor:	Kule
CCD-sensorstørrelse:	1/2.8 "
Signal-til-støy-forhold (SNR):	120 dB
Modell/Type:	IP-sikkerhetskamera
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 360 °
Internasjonal beskyttelses (IP)-kode:	IP66
Panoreringshastighet:	60 °/sek
Minimumsbelysning:	0.01 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	0 - 95
Støttede plasseringer/plasseringer som kan benyttes:	Utendørs
Montasjetype:	Tak/Vegg
Totale megapiksler:	0.3072 MP
Webbasert administrasjon:	Ja
Plugg inn og spill:	Ja
DC-ut, volt:	24
Region of Interest (ROI)-koding:	Ja
Fast fokalobjektiv:	25 mm
Maksimal blenderåpning:	4.7
Panoreringskontroll:	Ja
Vippekontroll:	Ja
Komposittvideo ut:	1
Baklyskompensasjon (BLC):	Ja
Auto-fokus:	Ja
Vippehastighet:	30 °/sek
Forinstilte punkter:	Ja
RS-422-port:	1
Fjerndrevet:	Ja
Termisk rammefrekvens (PAL):	8.3 Hz
Termisk rammefrekvens (NTSC):	30 Hz
